1. Set up for the Day

Use the following instructions to get started each time you go out on the water .
1
Power On
|
1 . Press the POWER key .
2 . Choose your startup mode .
If you are on the water with GPS reception, select Normal mode . (Normal mode is required for on-the-water use .)
If you are off the water and don't have GPS reception, select Simulator mode .
2
Display a Chart View
|
SOLIX
1 . Press the HOME key .
2 . Select Chart View from the Favorites bar .
Chart View with CoastMaster Chart Card Installed (SOLIX)
Automatic Display: The map displayed on the Chart View is based on your latitude/longitude position and the chart card installed
in the control head, so your current position will be displayed automatically . GPS reception is required for the correct position to
be displayed .
If your current position is not displayed, confirm you have GPS reception and that your CoastMaster Chart Card is installed . Also,
review the Chart Source:
SOLIX
1 . Press the HOME key .
2 . Select Settings .
3 . Select Chart .
4 . Select a Chart Source .
Global: Turn Global on to share the map source with
the other control heads in a network .
HELIX
1 . Press the VIEW key until a Chart View is displayed on-
screen .
OR
1 . Press and hold the VIEW key to open the Views X-Press
Menu .
2 . Select Chart > Chart View .
Chart View with CoastMaster Chart Card Installed (HELIX)
HELIX
1 . Main Menu: Press the MENU key twice .
2 . Select the Chart tab .
3 . Select Map Source .
4 . Select the installed chart card .
Auto: The best available map will be selected automatically .
7
Set up for the Day
