Sonosite PX System Battery Assembly Instructions
Inside the box
System batteries (2)
Installing the system battery
S
TEP
Access the system's battery compartment.
S
TEP
Place the other battery in the compartment as
shown, then plug its cable into the connector.
Make sure the cable is placed fully within the
compartment.
Battery compartment cover (1)
1
3
S
TEP
Place one of the batteries in the compartment as
shown, then plug its cable into the connector. Make
sure the cable is placed fully within the compartment.
S
TEP
Attach the battery compartment cover using a
Phillips screwdriver and the Phillips-head screws.*
*A magnetic bit driver and Phillips #1 bit are
available in the stand assembly kit.
M3 x 8 mm Phillips-
head screws (6)
2
4
1
