Pellet Grill
Pellet Grill
Assembly and Operating
Instructions for Model:
470430
VER. 1, 9/11/2019
WARNING:
FUELS USED IN WOOD OR CHARCOAL BURNING
!
APPLIANCES, AND THE PRODUCTS OF COMBUSTION OF SUCH FUELS,
CAN EXPOSE YOU TO CHEMICALS INCLUDING CARBON BLACK, WHICH IS
KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER, AND CARBON
MONOXIDE, WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE
BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.
For more information go to: www.P65Warnings.ca.gov
ADVERTENCIA:
LOS COMBUSTIBLES USADOS EN EQUIPOS PARA
!
QUEMAR MADERA O CARBÓN, ASÍ COMO LOS PRODUCTOS DE TAL
COMBUSTIÓN, PUEDEN EXPONERTE A SUSTANCIAS QUIMICAS, ENTRE
ELLAS EL NEGRO DE HUMO Y EL MONÓXIDO DE CARBONO, QUE EL
ESTADO DE CALIFORNIA RECONOCE COMO CAUSA, RESPECTIVAMENTE,
DE CANCER Y DE MALFORMACIONES CONGENITAS Y OTROS DAÑOS AL
SISTEMA REPRODUCTOR.
Para más información, viste www.P65Warnings.ca.gov
WARNING:
THIS PRODUCT CAN EXPOSE YOU TO CHEMICALS,
!
INCLUDING WOOD DUST, WHICH ARE KNOWN TO THE STATE OF
CALIFORNIA TO CAUSE CANCER.
For more information go to: www.P65Warnings.ca.gov
ADVERTENCIA:
ESTO PUEDE EXPONERTE A PRODUCTOS
!
QUÍMICOS EN ESTE PRODUCTO, INCLUYENDO POLVO DE MADERA,
QUE SON CONOCIDOS POR EL ESTADO DE CALIFORNIA COMO
CAUSANTES DE CÁNCER.
Para más información, viste www.P65Warnings.ca.gov
Appliance Type: Pellet Fuel
Burning Cooking Appliance
Test Standards
Certified To:
UL Subject 2728
Certified To:
5010242
ULC/ORD STD C2728

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 470430 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Landmann 470430

  • Page 1 Appliance Type: Pellet Fuel Pellet Grill Burning Cooking Appliance Test Standards Assembly and Operating Instructions for Model: Certified To: 470430 UL Subject 2728 Certified To: VER. 1, 9/11/2019 5010242 ULC/ORD STD C2728 A MAJOR CAUSE OF FIRES IS FAILURE TO MAINTAIN REQUIRED CLEARANCES (AIR SPACES) TO COMBUSTIBLE MATERIALS.
  • Page 2 PAGE Pellet Grill READ FIRST! RULES FOR PELLET GRILL SAFE OPERATION. • ALWAYS UNPLUG GRILL AFTER USING. WIND CORD AROUND THE CORD WRAP SO IT IS OUT OF THE WAY. • DURING USE, THE PLUG WIRING SHOULD BE SORTED SO IT DOES NOT IMPOSE A TRIPPING HAZARD. PLEASE READ THIS ENTIRE MANUAL BEFORE ASSEMBLING AND •...
  • Page 3: Outdoor Use Only

    MANUFACTURER. DO NOT USE PELLET FUEL LABELED AS CAN CAUSE DEATH IF BURNED IN ENCLOSED HAVING ADDITIVES AREAS. NEVER BURN WOOD OR CHARCOAL INSIDE MANUFACTURER: LANDMANN HOMES, VEHICLES, TENTS OR ANY OTHER THE GRADE DESIGNATION IS: PREMIUM HARDWOOD ENCLOSED AREAS.
  • Page 4 PAGE Pellet Grill HARDWARE AND SMALL PART LISTING Item Qty. Part name Item Qty. Part name Chamber Lock Serving Tray Handle Base Hopper Chute Lid Handle Hopper Assembly Front Shelf Cooking Grate Grease Tray Warming Rack(Small) Bottom Shelf Warming Rack(Large) Flame Baffle Left Shelf Bracket Cooking Bracket/right...
  • Page 5 PAGE Pellet Grill EXPLODED VIEW FOR ASSEMBLED PARTS...
  • Page 6 PAGE Pellet Grill Assembly Instructions...
  • Page 7 PAGE Pellet Grill...
  • Page 8 PAGE Pellet Grill...
  • Page 9 PAGE Pellet Grill...
  • Page 10 PAGE Pellet Grill...
  • Page 11 PAGE Pellet Grill...
  • Page 12 PAGE Pellet Grill...
  • Page 13 PAGE Pellet Grill...
  • Page 14: Controller Instructions

    PAGE Pellet Grill Controller Instructions NOTE: • The maximum temperature that the pellet grill can achieve is influenced by the ambient temperature. In colder weather, the grill may not be able to achieve the highest set temperature and it will continually feed pellets into the fire pot at- tempting to reach the set temperature.
  • Page 15: Preparation For Use & Lighting Instructions

    PAGE Pellet Grill Preparation for Use & Lighting Instructions PLACE THE GRILL OUTDOORS ON A HARD, LEVEL, NON-COMBUSTIBLE SURFACE AWAY FROM ROOF, OVERHANG OR ANY COMBUSTIBLE MATERIAL. NEVER USE ON WOODEN OR OTHER SURFACES THAT COULD BURN. PLACE THE GRILL AWAY FROM OPEN WINDOWS OR DOORS TO PREVENT SMOKE FROM ENTERING YOUR HOUSE.
  • Page 16 PAGE Pellet Grill Preparation for Use & Lighting Instructions Step 6 Ensure the contorl knob is in the OFF position. Step 7 Turn the control knob to “High”. Step 8 Observe the auger turning as pellets fill the tube. Once pellets reach the fire pot, turn OFF the grill. DO NOT reach into the fire pot.
  • Page 17: Preheating The Grill

    PAGE Pellet Grill Operating Instructions CURING THE GRILL Before initial use, it is recommended to cure the grill to remove manufacturing oils or residue and minimize smoke odors or unnatural flavors from being added to food. • Follow “Setup Procedure” to ensure the grill is safe for operation. •...
  • Page 18: Cooking Instructions

    PAGE Pellet Grill Operating Instructions COOKING INSTRUCTIONS Set Temperature Once the controller has been set to a desired temperature, the target temperature will be displayed along with “COOK”, which indicates the controller is set to standard cooking mode. ℉ Actual Temperature COOK The internal temperature of the grill, as measured by a seperate thermo- couple, will be displayed in 5 degree increments.
  • Page 19 PAGE Pellet Grill Operating Instructions COOKING INSTRUCTIONS The following table represents the preset smoking modes showing the relation of smoke produced with the cooking tem- perature. A higher preset level will produce more smoke, but a lower cooking temperature. Smoke Mode Smoke Cooking Setting...
  • Page 20: Grill Cooking Tips

    PAGE Pellet Grill Grill Cooking Tips WOOD PELLETS ONLY USE wood pellets made for barbecue, not heat grade pellets. Barbecue wood pellets should be 100% all natural wood and come in a variety of types of wood that will add flavor to whatever food you are grilling or smoking. If possible, always use fresh wood pellets for each cooking session to ensure they burn properly giving off the correct amount of heat and smoke flavor.
  • Page 21: Care And Maintenance

    PAGE Pellet Grill Care and Maintenance A MAJOR CAUSE OF FIRES IS FAILURE TO MAINTAIN REQUIRED CLEARANCES (AIR SPACES) TO COMBUSTIBLE MATERIALS. IT IS OF UTMOST IMPORTANCE THAT THIS PRODUCT BE INSTALLED ONLY IN ACCORDANCE WITH THESE INSTRUCTIONS. GRILLING TIPS & CLEANLINESS •...
  • Page 22 PAGE Pellet Grill Care and Maintenance Paint and Corrosion Never apply paint to interior surfaces. Rust spots on the interior can be buffed, cleaned and then lightly coated with vegeta- ble oil or vegetable oil spray. Maintaining a light coat of oil will help minimize rusting. To protect against excessive rust, keep the grill clean and covered at all times when not in use.
  • Page 23: Troubleshooting

    PAGE Pellet Grill Troubleshooting PROBLEM CAUSE SOLUTION The grill Power. Verify there is power at the outlet. If connected to a GFCI outlet, won’t check and reset if necessary. If there is power but the grill fails to ignite. ignite, contact Customer Service at 1-800-321-3473. Pellets aren’t Pellet Hopper is empty or pellets failed Verify there are pellets in the Pellet Hopper and they are not stuck...
  • Page 24 PAGE Pellet Grill Troubleshooting PROBLEM CAUSE SOLUTION Temperature or digital display Outdoor temperature, lid Close the grill lid and allow up to 15 minutes for the does not match open. temperature to stabilize. Operating the grill in very cold “set” temperature. conditions may affect the performance.
  • Page 25 PAGE Pellet Grill Troubleshooting PROBLEM CAUSE SOLUTION Grill will not start. Power Ensure unit is plugged in. Verify there is power at the GFI outlet. Check and reset the Ground Fault Interrupter if necessary. If igniter not working, check 5 amp fuse found on the back of the control board (See Control Board Back View on Page 26 for information).
  • Page 26 The circuit board is equipped with a 5 amp, 120 volt fuse to help protect against power surges and electrical shorts. When not in use, always unplug and store your grill. This will help prevent electrical damage from power surges or storms. 470430 WIRING DIAGRAM Digital Control Wiring Diagram POWER CORD...
  • Page 27: Replacement Parts

    PAGE Pellet Grill Replacement Parts Part Qty. Part name PG0001 PG0002 Handle Base PG0003 Lid Handle PG0004 Front Shelf PG0005 Grease Tray PG0006 Bottom Shelf PG0007 Flame Baffle PG0008 Left Cooking Bracket PG0009 Wheel with Lock PG0010 Wheel PG0011 Chute Door PG0012 Side Handle PG0013...
  • Page 28: Warranty

    This warranty gives you specific legal rights and you may also have other legal rights which may vary from state to state. Landmann USA, Inc. 7405 Graham Rd Fairburn, Ga 30213...
