ASSEMBLY, CARE AND USE INSTRUCTIONS

Household use only.

READ CAREFULLY

This is not a

IMPORTANT:

commercial appliance.

RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Ardor Built in Gas Grill

MODELS: 43100, 43101, 43102, 43103, 43104 & 43105

Questions, problems, missing parts? Before returning to your retailer, call our customer

service department at: 1-800-321-3473 8:00 AM - 5:00 PM (EST) English Only,

or Email CustomerService@landmann-usa.com

Table of Contents

Need help?

Do you have a question about the 43100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Landmann 43100

Page 1 RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE Ardor Built in Gas Grill MODELS: 43100, 43101, 43102, 43103, 43104 & 43105 Questions, problems, missing parts? Before returning to your retailer, call our customer service department at: 1-800-321-3473 8:00 AM - 5:00 PM (EST) English Only,...
Page 2: Table Of Contents
Table of Contents Important Safety Information ........2 Main Burner Lighting Instrustions ......22 General Safety Requirements........4 Care and Maintenance.......... .23 Liquid Propane (LP) Safety Information....5 Cooking Methods and Grilling Tips......24 Package Contents ............ 6 Using the Rotisserie Burner........25 BBQ Specifications............9 Maintenance &...
Page 3 Any requirements for cap on cylinder valve outlet that is a replacement regulator and hose provided with the cylinder valve. assembly must be made through the Other types of caps or plugs may manufacturer, LANDMANN-USA. result in leakage of propane.
Page 4: General Safety Requirements
13. The pressure regulator and hose maintained. This outdoor cooking gas assembly supplied with the Landmann Gas appliance shall not be located under Grill must be used. overhead-unprotected combustible Replacement pressure regulators and hose construction.
Page 5: Liquid Propane (Lp) Safety Information
Liquid Propane (LP) Safety Information Please review the below guidelines and safety information when using Liquid Propane (LP) gas. General Information Important • This grill is designed to be used with a standard 20 The United States LP gas appliance installation must lb.
Page 6: Package Contents
Package Contents Models: 43100 & 43101 Part Quantity Description Rubber Bumper 3B Grill lid & firebox assembly LP hose & regulator (LP model 43100 only) Drip Tray Lower heat shield Flame tamers Cooking Grate Warming Rack...
Page 7 Package Contents Model: 43102 & 43103 Part Quantity Description Rubber Bumper 4B Grill lid & firebox assembly LP hose & regulator (LP model 43102 only) Drip Tray Lower heat shield Flame tamers Cooking Grate Warming Rack...
Page 8 Package Contents Model: 43102 & 43103 Model: 43104 & 43105 Part Quantity Description Rubber Bumper 5B Grill lid & firebox assembly LP hose & regulator (LP model 43104 only) Drip Tray Lower heat shield Flame tamers Cooking Grate Warming Rack...
Page 9: Bbq Specifications
BBQ Specifications NOTE: “ALWAYS” have equipment measured by Contractor before constructing any island or enclosure. Built in 3 Burner 24-3/8 " 3/8" male flare inlet fitting 27 7/8" 5 3/4" Built in 4 Burner 30-3/8" 3/8" male flare inlet fitting 27 7/8"...
Page 10 BBQ Specifications Get familiar with the knobs and which burners they control. 4 Burner 3 Burner Grill Grill Rotisserie Grill Burner Burner Burner Burner 5 Burner Grill Rotisserie Grill Burner Burner Burner...
Page 11: Assembly Instructions
Assembly Instructions 1. Parts needed - W Lower Pin Lower Pin 2 Parts needed - X 3 Parts needed - A, Y Flame viewing hole...
Page 12 Assembly Instructions 4 Parts needed - Z 6 Parts needed - K Included with LP models only 5 Parts needed - V...
Page 13: Location Of Appliance
Location of Appliance  Most importantly, this is an outdoor Partial Enclosures: appliance. Ensure your appliance is Many backyards have areas that are positioned safely away from anything that partially closed off, such as balconies and can catch fire. pergolas. In some cases, it is hard to Under no circumstance is this appliance to decide whether these partially enclosed be used indoors.
Page 14: Grilling In Windy Conditions
Grilling in Windy Conditions Outdoor grills produces more heat than interior kitchen ranges. That is how they sear and grill steaks and other food. These high performance burners requires a constant steady supply of fresh air to mix with fuel. The grill is designed to pull air in through the front and vents hot gases out through the rear.
Page 15: Installing The Appliance In A Bbq Island
Always check with local building codes, fire Built in Installations inspectors, neighborhood association and NOTE: Landmann built in grills are intended local contractors before constructing an either for installation in a built in enclosure island. A permit may be required for building constructed of non-combustible materials or any outdoor kitchen.
Page 16 Installing the Appliance in a BBQ Island Overhead Protection & Exhaust Removal Do not install this appliance under any unprotected overhead combustible construction. If installed under any combustible construction the cooking area over the grill must be covered with an exhaust hood. The hood must provide 3 to 6 inches of overhang on all exposed sides.
Page 17: Gas Connections
(Canada) label which is located underneath the control NATURAL GAS panel. LANDMANN recommends that only qualified professionals perform the required plumbing on The Rating plate lists serial number, model this product. number and gas type of your appliance. To ensure satisfactory performance, the gas...
Page 18 • A gas shut-off valve must be installed in an easily accessible location by a qualified plumber. For freestanding units using natural gas, LANDMANN strongly recommends using a • Keep threading compound off of the first two flexible NG gas hose w/ quick connect kit that is pipe threads to avoid having any small pieces of available from your local dealer.
Page 19 Do not use any replacement regulator other than that specified by Landmann. Use only pipe sealants that are approved for use with Natural and LP gases. An installer-supplied gas shutoff valve must be...
Page 20 Gas Connections CSA Approved Gas Regulator Semi-rigid gas Gas Supply Shutoff connector Valve...
Page 21: Checking For Gas Leaks
Checking for Gas Leaks LEAK TEST 1. Prepare a leak testing solution of soapy water by mixing in a spray bottle with one part liquid soap to three parts water 2. Confirm that all control knobs are in the OFF position. 3.
Page 22: Main Burner Lighting Instrustions
Main burner Lighting Instructions Prior to the ﬁrst use, it is important to clean your grill Match Lighting with heat. This will clean the internal parts by burning off any residue and odor from the manufacturing process. To perform this cleaning, operate the grill for approximately 15-20 minutes at the highest heat setting with the lid closed.
Page 23: Care And Maintenance
Care and Maintenance Please use the following guidelines to keep your grill Checking the Flame clean and looking new. Before any cleaning, make The ﬂame coming out of the burners should be a sure all the burners are in the OFF position and grill blue/yellow combination and between one to two and is cool to the touch.
Page 24: Cooking Methods And Grilling Tips
Cooking Methods And Grilling Tips Direct Heat During Grilling Direct heat cooking means that the food is placed on • The temperature gauge on the lid indicates the grill grates directly over the lighted burners. approximate cooking temperature inside the grill. •...
Page 25: Using The Rotisserie Burner
Using the Rotisserie Burner (4 & 5 Burner Models Only) The rear infrared rotisserie burner allows for Lighting the Rotisserie Burner slow rotisserie cooking of meats & poultry. Prior to the ﬁrst use, it is important to clean your grill The infrared rotisserie burner radiates heat with heat.
Page 26 Using the Rotisserie Burner (4 & 5 Burner Models Only) Match Lighting Note: Match lighting tool is located on the inside of the door. 1. Turn all gas control knobs to the OFF position. 2. Turn on gas valve from gas source. 3.
Page 27: Maintenance & Cleaning
The 304 stainless steel material used in the • Use a commercially available Stainless construction of a Landmann Grill is highly rust Steel cleaner to clean and polish the exterior resistant, however, chlorine in the air from surfaces.
Page 28 Maintenance & Cleaning Slide the tray out and wipe it clean. Make sure the THE LANDMANN LIMITED LIFETIME drip tray is fully inserted back into the grill. It is WARRANTY PROVIDES PROTECTION highly recommended to clean the tray after every AGAINST RUST THROUGH OF PARTS use to avoid any possibility of a grease fire.
Page 29: Troubleshooting
Troubleshooting Problem Cause Solution Grill will not light. 1. Main gas valve is closed. 1. Turn ON Main gas valve. 2. LP cylinder gas level is low. 2. Replace or refill LP cylinder. “Match lighting” may be “Match lighting” light grill per this necessary.
Page 30: Grilling Guidelines
Grilling Guidelines Cooking Burner Type Description Method setting Thickness Total time Instructions BEEF Steaks NY Strip, Rib eye, Direct High 1 in / 10-15 min Turn meat only once, Porterhouse, T-Bone, 2.5 cm halfway through the Sirloin, Filets grilling time NY Strip, Rib eye, Direct High...
Page 31 Grilling Guidelines Cooking Burner Type Description Method setting Thickness Total time Instructions Shrimp 18-20 oz / 510-566 g Direct High 3-6 min VEGETABLES Corn on the In Husk Direct Medium 20-30 min Husked Direct Medium 12-15 min Potatoes Baking, whole Direct High 45-90 min Individually wrapped in...
Page 32: Gas Conversion
Gas Conversion Installation Safety Precautions Natural Gas Connections and Service Regulators This appliance is set to Above 1/2 psi. operate at 1/2psi water Prior to 1998, all residual gas service regulators column supply pressure. were set with an outlet pressure of 7 inches water Verify supply pressure with column.
Page 33 Gas Conversion Using pliers remove R pins from above flame crossers Orifices - See chart on next page for your model number and specific Flame crossers orifices supplied. 1 Orifice Removal Tool R-pin Conversion label Tools required for assembly: 7mm wrench Adjustable wrench Pliers Flame crossers...
Page 34 Gas Conversion - Insert Orifice Removal Tool into Firebox Burner opening and unnscrew Orifies from ends of Valves. Save removed Orifices for later if converting back to original gas type. - Install new orifices. -Be sure to use orifice size chart below to install the proper orifice on each burner for your specific model .
Page 35 Gas Conversion For 4 & 5 burner models only - Use Phillips head screw driver to remove cover from back panel - Remove Infrared Orifice with 7mm wrench - Install new orifice Cover 7mm Wrench Infrared Orifice...
Page 36 Gas Conversion Convert regulator: Convert Valves: - Use adjustable wrench to remove regulator cap. - Remove control knobs. - Unscrew regulator stem, turn over and then reinstall. - Using small flat head screw driver adjust the minimum rate screw as - See diagram below for correct assembly of conversion follows: gas type.
Page 37: Replacement Parts
Replacement Parts Models: 43100 & 43101...
Page 38 Replacement Parts Models: 43100 & 43101...
Page 39 Replacement Parts Models: 43102 & 43103...
Page 40 Replacement Parts Models: 43102 & 43103...
Page 41 Replacement Parts Models: 43104 & 43105...
Page 42 Replacement Parts Models: 43104 & 43105...
Page 43: Warranty
Our customer service department can be reached at 1-800-321-3473 8:00 AM - 5:00 PM (EST) English Only, or Email CustomerService@landmann-usa.com Please note for the United States, that some state states do not allow the exclusion or limitation of incident or consequential damages or limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.
