3087464
For replacement parts visit
WENPRODUCTS.COM
Your new tool has been engineered and manufactured to WEN's highest standards for dependability, ease
of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If
you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
NOTICE: Please refer to wenproducts.com for the most up-to-date instruction manual.
CIRCULAR SAW
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
7-1/4-INCH
(M-F 8AM-5PM CST)
Model # 36725
bit.ly/wenvideo
Advertisement
Related Manuals for Wen 36725
Summary of Contents for Wen 36725
- Page 1 WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
- Page 2 Know Your Circular Saw Assembly & Adjustments Operation Maintenance Warranty Statement Exploded View and Parts List TECHNICAL DATA Model Number: 36725 Motor: AC 120V, 60Hz, 12A No-Load Speed: 4500 RPM Bevel Angle: 0° to 45° Right Maximum Cutting Depth at 0°: 2-1/2 in.
- Page 3 SAFETY INTRODUCTION Thanks for purchasing the WEN Circular Saw. If you like sawing things, then this is the right product for you. This manual provides information regarding potential safety concerns, as well as helpful assembly and operating instruc- tions. Safe operation of this tool requires that you read and understand this operator’s manual and all labels affixed to the tool.
- Page 4 GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instruc- tions may result in electric shock, fire and serious injury. To avoid mistakes and serious injury, do not plug in your tool until the following steps have been read and understood.
- Page 5 GENERAL SAFETY RULES POWER TOOL USE AND CARE 1. Avoid accidental start-ups. Make sure the power switch is in the OFF position before connecting the plug to a power source or carrying the tool. 2. Check power tool for damaged parts. Check for misalignment of moving parts, jamming, breakage, improper mounting, or any other conditions that may affect the tool’s operation.
- Page 6 SPECIFIC RULES FOR THE CIRCULAR SAW WARNING: Do not let comfort or familiarity with the product replace strict adherence to product safety rules. If you use this tool unsafe or incorrectly, you can suffer serious personal injury. 1. WORK ENVIRONMENT. Do not operate the tool in wet or damp conditions; doing so significantly increases the risk of electrical shock.
- Page 7 SPECIFIC RULES FOR THE CIRCULAR SAW 9. DURING THE CUT. Keep hands away from the cutting area and the blade. Do not reach underneath the work- piece. The blade guard cannot protect you from the blade protruding from the underside of the workpiece. Do not attempt to remove cut material when the blade is moving.
- Page 8 ELECTRICAL INFORMATION DOUBLE INSULATION Double insulation is a concept in concept in electrical power tool safety, where two systems of insula- tion are provided. This eliminates the need for the usual three-wire grounded power cord. All exposed metal parts are isolated from the internal metal motor components with protecting insulation. Double insulated tools do not need to be grounded.
- Page 9 KNOW YOUR CIRCULAR SAW Carefully unpack the tool from the packaging. Check all components and compare against the graph below. If any part is damaged or missing, please contact our customer service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com.
- Page 10 ASSEMBLY & ADJUSTMENTS WARNING: To avoid injury from accidental startups, be sure that the tool is switched off and discon- nected from the power supply before inspecting the unit, making adjustments or changing accessories. SETTING THE DEPTH OF CUT (Fig. 1 & 2) Before making a cut, it is important to set the correct blade depth.
- Page 11 ASSEMBLY & ADJUSTMENTS LINE-OF-CUT INDICATORS (Fig. 4) 45° 0° A line-of-cut indicator notch can be found at the front of the saw base. This notch helps provide indication of where the cut will be occurring. The right edge of the notch is used to indicate the line when making a 0°...
- Page 12 OPERATION WARNING: To prevent serious injury, make sure all the instructions have been read and understood before operating this tool. Before plugging in the tool, always check to see that the tool is turned off. Accidently starting the saw could result in injury. TYPES OF CUTS •...
- Page 13 OPERATION OPERATING THE SAW 1. Hold the tool firmly with both hands, using both the front grip and the rear handle. Avoid placing your hand on the workpiece while making a cut. If both hands are holding the saw, they cannot be cut by the blade. 2.
- Page 14 OPERATION MAKING PLUNGE CUTS/POCKET CUTS A plunge cut is a cut that must be made inside the area of the workpiece rather than starting from an outside edge and working inward. Plunge cuts can be very dangerous for the novice to attempt because of the need to manually retract the lower guard and perform a plunge cut which is potentially hazardous.
- Page 15 MAINTENANCE WARNING: To avoid injury from accidental startups, be sure that the tool is switched off and discon- nected from the power supply before inspecting the unit, making adjustments or changing accessories. REPLACING THE SAW BLADE The quality of the cut depends on the condition of the saw blade. Never use a dull, rusty, or damaged blade. Before operation, check the blade and replace if the blade is worn-out or damaged.
- Page 16 To maintain maximum motor efficiency, we recommend inspecting the two carbon brushes every 60 hours of operation. NOTE: Replacement carbon brushes (Part No. 36725-018) can be or- dered at wenproducts.com. Only genuine WEN replacement brushes designed specifically for your tool should be used.
- Page 17 LIMITED TWO YEAR WARRANTY WEN Products is committed to build tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
- Page 18 EXPLODED VIEW & PARTS LIST...
- Page 19 EXPLODED VIEW & PARTS LIST Part No. Description Qty. Part No. Description Qty. 36725-001 Right Handle 36725-031 Elastic Cylindrical Pin 36725-002 Line Pressing Board 36725-032 Retaining Ring 36725-003 Screw ST4x16 36725-033 Bearing 6001 36725-004 Switch 36725-034 Bearing Base 36725-006 Power Cord Sheath...
- Page 20 THANKS FOR REMEMBERING...
