Your new tool has been engineered and manufactured to WEN's highest standards for dependability, ease
of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.
If you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
NOTICE: Please refer to wenproducts.com for the most up-to-date instruction manual.
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
4-1/2" MINI
CIRCULAR SAW
(M-F 8am-5pm CST)
MODEL 3625
766B
5005389
Advertisement
Table of Contents
Related Manuals for Wen 3625
Summary of Contents for Wen 3625
- Page 1 5005389 IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.
-
Page 2: Table Of Contents
Operation ..................15 Maintenance .................. 16 Troubleshooting Guide ..............17 Exploded View & Parts List ............18 Warranty Statement ............... 21 SPECIFICATIONS Model Number 3625 Motor 120V AC, 60 Hz, 5A Motor Speed (No-Load) 3500 RPM Blade Diameter 4-1/2" (115 mm) Arbor Size 3/8"... -
Page 3: Introduction
INTRODUCTION Thanks for purchasing the WEN Mini Circular Saw. We know you are excited to put your tool to work, but first, please take a moment to read through the manual. Safe operation of this tool requires that you read and understand this operator’s manual and all the labels affixed to the tool. -
Page 4: General Safety Rules
GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: Read and understand all warnings, cautions and operating instructions before using this tool. Failure to follow all instructions listed below may result in personal injury, electric shock, fire and/or tool damage. - Page 5 GENERAL SAFETY RULES 5. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. 6. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
-
Page 6: Specific Safety Rules For The Mini Circular Saw
SPECIFIC RULES FOR THE MINI CIRCULAR SAW WARNING: Do not let comfort or familiarity with the product replace strict adherence to product safety rules. Failure to follow the safety instructions may result in serious personal injury. 1. TOOL PURPOSE. This circular saw is designed to cut through softwood only. Cutting other materials could result in fire, injury, or damage to the workpiece. - Page 7 SPECIFIC RULES FOR THE MINI CIRCULAR SAW full stop before reaching for loose materials or setting the tool down. 12. REPLACING THE SAW BLADE. Check the blade for chipped or broken teeth. Do not use dull or dam- aged blades. Unshaped or improperly set blades produce narrow kerf, causing excessive friction, blade binding, and kickback.
- Page 8 SPECIFIC RULES FOR THE MINI CIRCULAR SAW LASER SAFETY ATTENTION: LASER RADIATION. CLASS 2 LASER. DO NOT STARE INTO THE BEAM. 1. Do not look directly into the laser beam with unprotected eyes. Never look into the path of the beam. 2.
-
Page 9: Electrical Information
ELECTRICAL INFORMATION DOUBLE-INSULATED TOOLS The tool’s electrical system is double insulated where two systems of insulation are provided. This eliminates the need for the usual three-wire grounded power cord. Double insulated tools do not need to be grounded, nor should a means for grounding be added to the product. All exposed metal parts are isolated from the internal metal motor components with protecting insulation. -
Page 10: Know Your Mini Circular Saw
KNOW YOUR MINI CIRCULAR SAW UNPACKING With the help of a friend or trustworthy foe, carefully remove the saw from the packaging. Make sure to take out all contents and accessories. Do not discard the packaging until the saw is completely assembled. TOOL PURPOSE This circular saw is designed to make quick, versatile cuts through soft wood. -
Page 11: Assembly & Adjustments
ASSEMBLY & ADJUSTMENTS INSTALLING/REPLACING THE SAW BLADE (FIGS. 1 & 2) Use saw blades with 4-1/2 inch (115 mm) diameter and 3/8 inch (10 mm) arbor. Do not use a blade that does not match the diameter or arbor size. The pre-installed blade has a body that is 1.2 mm thick and theeth that are 1.8 mm thick . - Page 12 ASSEMBLY & ADJUSTMENTS SETTING THE DEPTH OF CUT (FIG. 4) Before making a cut, it is important to set the correct cutting depth. The saw’s maximum cutting depth at 90° is 1-11/16 inch (43 mm), at 45° it is 1-1/8" (28 mm). We recommend adjusting the cutting depth about 1/16 inch (2 mm) deeper than the thickness of the material.
- Page 13 ASSEMBLY & ADJUSTMENTS USING THE LASER (FIG. 6) Laser Switch The laser located on the top of your saw can also be used to in- dicate the line of cut. Unscrew the laser cover and install the two Laser AG13 batteries. Securely replace the laser cover. Switch the laser ON and align the laser line with your cutting guideline.
- Page 14 ASSEMBLY & ADJUSTMENTS ADJUSTING THE BLADE BEVEL (FIG. 10) Bevel your mini circular saw blade from 45° to 90° to cut your workpiece on an angle. The saw’s maximum cutting depth at 90° is 1-11/16 inch (43 mm), at 45° it is 1-1/8" (28 mm). Be sure to set your saw to the proper depth for the angle you are using Bevel Scale (see Page.
-
Page 15: Operation
OPERATION PREPARING FOR OPERATION 1. Prepare the work space and position power cords away from the cutting area. Connect your saw to a dust extraction system (see Page. 13). 2. Ensure that the saw blade is sharp. Set the correct depth of cut for your workpiece (see Page. 12). 3. -
Page 16: Maintenance
Any attempt to repair or replace electrical parts on this tool may be hazardous. Servicing of the tool must be performed by a qualified technician. When servicing, use only identical WEN replacement parts. Use of other parts may be hazardous or induce product failure. ROUTINE INSPECTION Before each use, inspect the general condition of the tool. -
Page 17: Troubleshooting Guide
TROUBLESHOOTING GUIDE WARNING: Stop using the tool immediately if any of the following problems occur. Repairs and replacements should only be performed by an authorized technician. For any questions, please contact our customer service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com. -
Page 18: Exploded View & Parts List
EXPLODED VIEW & PARTS LIST... - Page 19 EXPLODED VIEW & PARTS LIST Part No. Description Qty. Part No. Description Qty. Screw With Washer 3625-039 Blade Arbor 3625-001 M4x14 3625-040 Fixed Blade Guard 3625-002 Spindle Lock Button Screw With Washer 3625-041 3625-003 Spindle Lock Spring M4x12 Cross-Shaped Screw...
- Page 20 EXPLODED VIEW & PARTS LIST Part No. Description Qty. Part No. Description Qty. 3625-049 Blade Arbor Screw 3620-046 Lower Brush Holder 3625-050 Outer Flange 3620-045 Carbon Brush 3625-051 Screw St4.2x12 3620-048 Bearing 606-2z 3625-052 Lever For Blade Cover 3620-049 Bearing Sleeve...
-
Page 21: Warranty Statement
(2) years from date of purchase. Ninety days for all WEN products if the tool is used for professional or commercial use. SELLER’S SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under this Limited Warranty and, to the ex-... - Page 22 THANKS FOR REMEMBERING...
