Have product questions? Need technical support? Please feel free to contact us:
1-800-232-1195 (M-F 8AM-5PM CST)
IMPORTANT: Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use
your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
For replacement parts and the most up-to-date instruction manuals, visit
10-INCH BAND SAW
NEED HELP? CONTACT US!
MODEL 3962, 3962T
WITH STAND
Instruction Manual
TECHSUPPORT@WENPRODUCTS.COM
WENPRODUCTS.COM
Advertisement
Table of Contents
Related Manuals for Wen 3962T
Summary of Contents for Wen 3962T
- Page 1 1-800-232-1195 (M-F 8AM-5PM CST) TECHSUPPORT@WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
-
Page 2: Table Of Contents
CONTENTS WELCOME Introduction ......................3 Specifications ....................3 SAFETY General Safety Rules ..................4 Specific Rules for Your Band Saw ..............6 Electrical Information ..................8 BEFORE OPERATING Unpacking & Transportation ................9 Know Your Band Saw ..................10 Assembly & Adjustments ................11 OPERATION &... -
Page 3: Welcome
INTRODUCTION Thanks for purchasing the WEN Band Saw. We know you are excited to put your tool to work, but first, please take a moment to read through the manual. Safe operation of this tool requires that you read and understand this operator’s manual and all the labels affixed to the tool. -
Page 4: Safety
GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 5 GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
-
Page 6: Specific Rules For Your Band Saw
SPECIFIC RULES FOR YOUR BAND SAW WARNING! Do not operate the power tool until you have read and understood the following instructions and the warning labels. SAW BLADE SAFETY 4. Wear work gloves when handling saw blades. DO NOT wear gloves, neckties, jewelry, or loose clothing 1. - Page 7 SPECIFIC RULES FOR YOUR BAND SAW WARNING! Do not operate the power tool until you have read and understood the following instructions and the warning labels. 5. Never hand-hold a workpiece that is too small to be 7. Blade guide, supports, bearings, and blade tension clamped, as it can be launched away and cause inju- must be properly adjusted to avoid accidental blade ry.
-
Page 8: Electrical Information
ELECTRICAL INFORMATION GROUNDING INSTRUCTIONS In the event of a malfunction or breakdown, grounding provides the path of least resistance for an electric current and reduces the risk of electric shock. This tool is equipped with an electric cord that has an equipment grounding conductor and a grounding plug. -
Page 9: Before Operating
UNPACKING & TRANSPORTATION WARNING! Do not plug in or turn on the tool until it is fully assembled according to the instructions. Failure to follow the safety instructions may result in serious personal injury. UNPACKING With the help of a friend or trustworthy foe, carefully remove the band saw from the packaging. Make sure to take out all contents and accessories. -
Page 10: Know Your Band Saw
KNOW YOUR BAND SAW TOOL PURPOSE Band saws are used to cut wood. Refer to the following diagrams to become familiarized with all the parts and controls of your band saw. The components will be referred to later in the manual for assembly and operation instructions. -
Page 11: Assembly & Adjustments
ASSEMBLY & ADJUSTMENTS WARNING! Do not plug in or turn on the tool until it is fully assembled according to the instructions. Read through and become familiarized with the following procedures of handling and adjusting your tool. Failure to follow the safety instructions may result in serious personal injury. ASSEMBLING THE STAND (FIG. - Page 12 ASSEMBLY & ADJUSTMENTS INSTALLING THE GUIDE RAIL (FIG. 5) Fig. 5 1. Install the 4 guide rail lock knobs (A) into the underside of the table. Do not tighten them yet – just seat them in the holes. 2. With the ruler-side up, slide the slots on the guide rail (B) over the threaded shafts of the knobs.
- Page 13 ASSEMBLY & ADJUSTMENTS SETTING THE 0° / 45° STOPS (FIG. 10 & 11) Fig. 9 1. To adjust the 0° positive stop, loosen the nut (A) on the stop. Turn the stop (B) with a wrench to adjust it upwards or downwards.
- Page 14 ASSEMBLY & ADJUSTMENTS ADJUSTING THE BLADE TENSION (FIG. 13) Fig. 13 WARNING! If the blade tension is too high, the blade may break. If the tension is too low, the blade may slip, stall, or wander during a cut. 1. Raise the upper blade guide (see section below). 2.
- Page 15 ASSEMBLY & ADJUSTMENTS CONTINUED - ADJUSTING THE UPPER GUIDE Fig. 17 BEARINGS (FIG. 15 - 17) 3. Loosen the knob (Fig. 15 - B) on the left side of the upper guide bearing assembly. Position the thrust bearing so that it is as close to the spine of the blade as possible, without touching it.
-
Page 16: Operation & Maintenance
ASSEMBLY & ADJUSTMENTS ADJUSTING THE CUTTING SPEED (FIG. 19) Fig. 19 Your band saw can cut at 1520 or 2620 FPM. The higher setting is generally appropriate for soft woods; the lower setting is generally appropriate for hard woods. Make test cuts on scrap pieces before beginning, in order to deter- mine what setting will work best for your particular cut. - Page 17 OPERATION GENERAL CUTTING GUIDELINES CAUTION! Always be sure that the band saw 1. Make a test cut on scrap wood to test the settings and is turned OFF and unplugged before making any get the hang of operating the band saw. adjustments.
-
Page 18: Maintenance
WARNING! Any attempt to repair or replace electrical parts on this tool may be hazardous. Servicing of the tool must be performed by a qualified technician. When servicing, use only identical WEN replacement parts. Use of other parts may be hazardous or induce product failure. -
Page 19: Troubleshooting Guide
TROUBLESHOOTING GUIDE WARNING! Stop using the tool immediately if any of the following problems occur. Repairs and replacements should only be performed by an authorized technician. For any questions, please contact our customer service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com. PROBLEM POSSIBLE CAUSE SOLUTION... - Page 20 TROUBLESHOOTING GUIDE WARNING! Stop using the tool immediately if any of the following problems occur. Repairs and replacements should only be performed by an authorized technician. For any questions, please contact our customer service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com. PROBLEM POSSIBLE CAUSE SOLUTION...
-
Page 21: Exploded View & Parts List
EXPLODED VIEW & PARTS LIST... - Page 22 EXPLODED VIEW & PARTS LIST Part No. Description Qty. Part No. Description Qty. M5-0.8x12mm Pan 3962-001 Blade Tension Knob 3962-033 Head Screw 3962-002 Bushing 3962-034 Switch Box 3962-003 15mm Retaining Ring 3962-035 Connecting Terminal 3962-004 Frame Cap 3962-036 Switch Cover 3962-005 Spring 3962-037...
- Page 23 EXPLODED VIEW & PARTS LIST Part No. Description Qty. Part No. Description Qty. Upper Guide 3962-091 M6-1.0mm Hex Nut 3962-063 Adjusting Knob 3962-092 626ZZ Ball Bearing 3962-064 Spring M6-1.0x16mm 3962-093 3962-065 Lock Knob Socket Head Bolt M6-1.0mm Square 3962-066 Lower Guard 3962-094 M6-1.0x10mm 3962-067...
- Page 24 EXPLODED VIEW & PARTS LIST EXPLODED VIEW & PARTS LIST Part No. Description Qty. Part No. Description Qty. 3962-119 Table 3962-150 Guide Rail Cap 3962-120 Miter Gauge 3962-151 Guide Rail M4-0.7x12mm Pan 3962-152 Guide Rail Cap 3962-121 Head Screw 2.9-1.1x9.5mm 3962-122 4mm Flat Washer 3962-153...
-
Page 25: Warranty Statement
(2) years from date of purchase or 500 hours of use; whichever comes first. Ninety days for all WEN products if the tool is used for pro- fessional or commercial use. - Page 26 NOTES...
- Page 27 NOTES...
- Page 28 THANKS FOR REMEMBERING V. 2021.01.07...
