Drive Axle Parts List - Bil-Jax ESP 19 Manual

Item No. Part No.
1 0090-0049
2 B30-00-0050
3 0090-0188
4 0090-0065
5 B07-06-5995
6 B01-07-0015
6A B01-07-0012
6B B01-07-0011
6C B01-07-0013
7 B07-07-5022
8 B30-00-0049
9 B07-06-5946
10 B25-00-0073
11 0090-0422
12 0090-1096
13 0090-0367
14 0090-1071
15 B08-02-0015
16 0090-0776
17 0090-0617
SEE APPENDIX B FOR MACHINE CHANGES DUE TO

DRIVE AXLE PARTS LIST

Description
Screw, Cap, 3/8-16 x 2-1/4 in.
Pad Assembly, Torsion
Nut, Nylon Lock, 3/8-16
Screw, Cap, 1/2-13 x 1 in.
Bracket, Torsion
Transaxle Assembly
Transaxle Subassembly
Motor Subassembly
Brake Subassembly, Electric
Key, Square, 1/4 x 2-1/4 in.
Mount, Rubber
Plate, Transaxle Clamp
Pillow Block
Washer, Flat, 3/8 in.
Screw, Cap, 3/8-16 x 2 in. – Grade 8
Screw, Set, 1/4-28 x 1/4 in.
Screw, Set, 5/16-18 x 5/8 in.
Caster, 10 in. Drive
Washer, Flat, 7/16 in.
Screw, Cap, 7/16-14 x 1 in.
REFURBISHMENT
Qty
1
1
2
1
1
1
1
1
1
2
2
2
2
4
4
4
4
2
2
2
69
