Summary of Contents for STOVES Richmond 600 Gas
- Page 1 U S E R G U I D E A commitment to: Stoves Richmond 600 Gas Part Number: 083690600 Date: 02/02/18...
- Page 2 PL - Poland NZ - New Zealand NL - Netherlands AU - Australia ES - Spain To contact Stoves about your appliance, please call: Warranty Registration Customer Care Helpline 0800 952 1065 0344 815 3740 *Please call our Customer Care team for extended...
- Page 3 Hereby, Glen Dimplex Home Appliances Ltd. declares that the radio equipment types ST RICH 600G is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.stoves.co.uk in the online user manual for this appliance. Disposal of Packaging Material The packaging materials used with this appliance can be recycled.
- Page 4 SAFETY WARNING • During use the appliance becomes hot. Care should be taken to avoid touching heating elements. • Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction...
- Page 5 prevent the appliance slipping from the base. • Never put items directly on the base of the oven or cover the oven with foil, as this can cause the base element to overheat. • Accessible parts may become hot when the grill is in use. Children should be kept away.
- Page 6 • Other Safety Advice • Servicing should be carried out only by authorised personnel. • Do not operate the appliance without the glass panel correctly fitted. • There is a risk of electric shock, so always make sure you have turned off and unplugged your appliance before starting.
-
Page 7: Using Your Appliance
USING YOUR APPLIANCE Getting to know your product Note: Your appliance layout may differ depending on the model. Medium Medium Left hand rear Right hand rear Small Large Right hand front Left hand front Control Panel Top Oven/Elec Grill Main Oven Cook zones Cook zones Ignition Switch... -
Page 8: Appliance Functions
Appliance functions Note: Your oven may not have all of the functions shown here. We recommend for best cooking results, please preheat your oven for 15 minutes and 3-5 minutes for grilling. Do not try to slow cook using any of the other oven functions. Intense Baking Defrost Base Heat with fan... - Page 9 Oven/Grill Some appliances are automatic ignition and do not have an ignition switch fitted. When the grill is switched on, the cooling fans switch on after a few minutes to keep the fascia and control knobs cool during cooking/grilling. The cooling fans may operate when the main ovens are in use, depending on the temperature setting. The fans may continue to operate for a period after the oven/grill has been switched off.
- Page 10 Grill THE DOOR MUST BE OPEN WHEN THE GRILL IS USED FOR CONVENTIONAL GRILLING. Grill pan and trivet The grill trivet (inside the grill pan) can be inverted to give a high or low position, or it may be removed. The speed of grilling can be controlled by selecting a higher or lower shelf position, or adjusting the grill setting.
-
Page 11: Pan Placement
Fitting burner caps and heads (Gas Hobs) angled burner cap parallel burner head burner cap not central Pan placement Always make sure that your pans are placed centrally on the burners and do not allow the flame to extend over the base of the pan. Pan sizes required Minimum Pan Sizes Maximum Pan Sizes... -
Page 12: Using The Touch Controls
Please be aware that only the main oven is controlled by the programmer. Clock / Programmer Note: Your clock / programmer may not have all these functions Minus Menu Plus Minute minder Manual mode Volume level Cooking time / Duration 7-segment display End of cooking time Max. -
Page 13: Setting The Minute Minder
Setting the time of day By pressing menu, scroll through the functions until you reach ‘time of day’. Press the function button until the ‘time of day’ Press the plus or minus buttons to set a time symbol appears Setting the minute minder The maximum cooking time that can be set is 99 minutes. - Page 14 To modify or cancel the minute minder Return to the minute minder function and use either the plus or minus buttons to adjust the time. By setting the time to ‘0.00’, this will cancel the countdown. Setting the cooking time (the duration of time the oven will operate for) Semi Auto- matic cooking The maximum cooking time that can be set is 2 hours and 59 minutes.
-
Page 15: Setting The Volume
Setting the volume Press the menu button until “LX” (X = 1, 2 or 3) flashes on the display. Use the plus or minus buttons to select a tone. Note: Default tone is L3 Activating / deactivating Key lock Press and hold the plus button for 3-5 seconds Once the Key lock is active, the buttons will be inactive. -
Page 16: Bluetooth Connectivity
Bluetooth Connectivity State of Connectivity Symbol • When the connectivity symbol is not present, the appliance cannot be connected to. • When the connectivity symbol is blinking, the appliance is ready to be paired with a smart device us- ing the Zeus App. •... -
Page 17: Clear Memory
Clear Memory Press the menu and plus button at the same time until a beep is heard. Once the beep is heard, any paired data will be cleared. Delete pairing information in the Bluetooth Settings of your smartphone or tablet. How to read the 6-digit pairing code 1. - Page 18 Removing Shelf Runners Telescopic positions Telescopic positions (if fitted) (if fitted) Standard shelves Slightly raise the shelf and insert in the chosen shelf position Ensure the shelf is fully pushed back towards the back of the oven, until the shelf stopper is reached.
-
Page 19: Changing The Light Bulb
Removing Telescopic shelves (if fitted) Grasp and lift shelf Lift shelf from the retaining tabs. Front of appliance Before removing the shelves completely, please make sure that the shelf is unclipped from the retaining tabs. Changing the light bulb Not all appliances have the same number and type of bulbs. Before you replace your bulb, check to see what type you have. - Page 20 If required, the wok ring should be located on top of the pan supports. The locating cutouts on the bot- tom of the wok ring engage with the four fingers of the pan supports around the centre burner location. Ensure the wok ring is located correctly, is fully engaged with the pan support fingers and is not able to rotate or slide across the pan supports before use.
-
Page 21: Cleaning Your Appliance
CLEANING YOUR APPLIANCE Do’s Note: Always switch off your appliance and allow it to cool down before you clean any part of it. Note: Please take extra care when cleaning over the symbols on the control panel, as this can lead to them fading. - Page 22 Please keep this handbook for future reference, or for anyone else who may use the appliance.
-
Page 23: Technical Data
TECHNICAL DATA Gas freestanding Databadge Lower part of the front frame Electric supply 220V - 240V ~ 50Hz (models with ignition) Gas connection The inlet connection is at the rear right-hand side - ISO7 - Rp1/2” (1/2” BSP) Appliance class Class 1 freestanding Gas category Natural Gas I2H LPG only I3+... - Page 24 Burner Nat Gas Nominal rate Injector Nominal rate Injector Qn (kW) Qn (kW) Double oven appliance without a wok (load W) - 1600 - 1900 Left hand front 1.00 1.00 Left hand rear 2.00 2.00 Right hand front (rapid) 3.00 3.00 Right hand rear 2.00...
