Summary of Contents for STOVES Precision 1100DFa
- Page 1 Stoves Precision 1100DFa Stoves 1100DFa Stoves Heritage 1100DF Dual Fuel Range Cookers For Natural Gas models & LP Gas models User & Installation Instructions...
- Page 2 STOVES CUSTOMER CARE In case of difficulty within the UK and Northern Ireland, please call STOVES Customer Care Centre Helpline on 0151 432 7838 When you dial this number you will hear a recorded message and be given a number of options. This indicates that your call has been accepted and is being held in a queue.
-
Page 3: Table Of Contents
Technical Data ........25 Stoves Customer Care ........28 Please keep this handbook for future reference, or for anyone else who may use the appliance. -
Page 4: User's Section
INTRODUCTION Thank you for choosing Ventilation British built appliance by Stoves The use of a gas cooking appliance We hope the following information will results in the production of heat and help you to quickly familiarise yourself moisture in the room in which it is with the features of the appliance, and installed. -
Page 5: Moving The Cooker
DO NOT USE THE the cooker for cleaning. APPLIANCE UNTIL IT HAS BEEN SER- VICED. Switch the appliance off at the mains and contact Stoves Customer Care Centre. - Page 6 INTRODUCTION Storage drawer To replace an oven light bulb Your appliance has a generous Caution: Switch off the electricity storage drawer, located beneath the supply to the appliance at the socket, right-hand side oven. to avoid the risk of electric shock. The storage drawer should only be Wait until the oven is cool, then used to store oven furniture.
-
Page 7: Be Safe - Not Sorry
BE SAFE - NOT SORRY When you are cooking, keep • Do not use aluminium foil to cover children away from the vicinity the grill pan, or put items wrapped of the appliance. in foil under the grill, as this creates a fire hazard. -
Page 8: Using The Hob
USING THE HOB Ignition The fold down lid (if fitted) Open the metal hotplate lid. Caution: Glass lids may shatter when Push in and turn the selected hotplate heated. Turn off all the burners before control knob anticlockwise to the large shutting the lid. - Page 9 USING THE HOB Pans For optimum safety and performance, we recommend the use of flat bottomed Turn pan handles to a safe position pans with a base diameter of minimum so they are out of reach of children, 100mm (4”) and maximum 250mm (10”). not overhanging the appliance, and cannot be caught accidentally.
-
Page 10: Using The Griddle (If Supplied)
USING THE GRIDDLE (if supplied) Caution: Accessible parts may To season; be hot when the griddle is used. • After cleaning, dry the griddle Young children should be kept thoroughly. away. • Rub the cooking side of the griddle sparingly with a minimum amount Please read these... -
Page 11: Using The Grill
USING THE GRILL Caution: Accessible parts may Detachable grill pan handle be hot when the grill is used. trivet Young children should be kept away. The grill is a variable electric dual grill. To switch on the grill Open the grill door. Turn the grill control knob either clock- grill pan wise to use the full grill settings, or anti-... - Page 12 USING THE GRILL Caution: Accessible parts may Grilling can also be adjusted by be hot when the grill is used. adjusting the trivet position, as detailed Young children should be kept b e l o w ; away. • The grill trivet inside the grill pan can be inverted to give a high or low position, or it may be removed Using the grill...
-
Page 13: Using The Ovens
USING THE OVENS Caution: Accessible parts may Red thermostat indicator neon be hot when the appliance is in (if fitted) use. Young children should be The red thermostat indicator neon will kept away. come on until the selected temperature is reached, and then go off. It will turn on and off periodically as the thermostat The cooker has two electric ovens. - Page 14 USING THE OVENS Oven furniture Oven shelves The oven shelf must be positioned with the upstand at the rear of the oven and facing upwards. Position baking trays and roasting tins on the middle of the shelves, and leave one clear shelf position between shelves, to allow for circulation of heat.
-
Page 15: Programmer / Clock
PROGRAMMER / CLOCK The Programmer Buttons Manual operation minute minder cook time ready time minus plus To set the programmer to manual To set the “Time of Day” operation at any time (cancelling any automatic setting), press the cook time a n d ready time buttons simultaneously. - Page 16 PROGRAMMER / CLOCK Semi-automatic cooking ( e x a m p l e ) 1. A (Auto) symbol appears. You have started cooking a meal or dish in the oven, and want to set the time for the oven to switch off. Press the cook time button, then use the p l u s and m i n u s buttons to set the display to show the length of cooking...
- Page 17 PROGRAMMER / CLOCK Fully automatic cooking ( e x a m p l e ) 5. A (Auto) symbol appears. For use when a delayed start time is required. You want to set the length of cooking t i m e, and the time for the oven to switch o f f.
- Page 18 PROGRAMMER / CLOCK The oven will automatically switch off 9. A (Auto) symbol will flash. at 18.00 hours (6.00 pm) and the alarm will sound (9). To switch off the alarm press the minute minder button (10). When the oven has switched off, return the oven control knob to the “off”...
-
Page 19: Cleaning
CLEANING C a u t i o n : Any cleaning agent Easy care surfaces used incorrectly may damage OVEN SIDES AND BACK the appliance. We recommend that the appliance is Always let the cooker cool cleaned after open roasting, and also before cleaning. - Page 20 CLEANING Burner caps & heads Painted, plastic & metal finish parts (where fitted) Important: Allow the burners to cool before cleaning. & CONTROL KNOBS PROGRAMMER BUTTONS SIDE PANELS HANDLES Caution: Hotplate burners can be damaged by soaking, automatic Only use a clean cloth wrung out in dishwashers (or dishwasher powders hot soapy water.
- Page 21 CLEANING Glass parts Stainless steel surfaces (Stainless steel finish models only) GLASS DOOR PANELS GLASS LID IF FITTED FASCIA PANEL DOOR HANDLES DOORS Only use a clean cloth wrung out in hot soapy water. Rinse away excess Only use a clean cloth wrung out cleaner and dry with a soft cloth.
-
Page 22: Installation Instructions
INSTALLATION INSTRUCTIONS Before start: Please read For installation in countries other than the instructions. Planning your installation will UK, the appliance must be connected in save you time and effort. accordance with all local gas and electrical regulations. In the Republic of Ireland, Prior to installation, ensure that the local Installers should refer to IS813 Domestic distribution conditions (nature of the gas and... -
Page 23: Installation
INSTALLATION INSTRUCTIONS Before you start, please read the Whilst every care is taken to eliminate instructions. Planning your installation burrs and raw edges from this product, will save you time and effort. please take care when handling - we recommend the use of protective Moving the cooker gloves during installation. - Page 24 INSTALLATION INSTRUCTIONS Stability bracket 4. Fix the bracket to the floor. If the cooker is fitted with a flexible Measure from floor level to connection, a stability bracket should engagement edge in the back of be fitted to engage in the back of the the cooker and add 3mm.
-
Page 25: Connect To Electricity Supply
INSTALLATION INSTRUCTIONS Connect to the electricity supply Warning: This appliance must be Live (Red or Brown) earthed. The appliance must be installed by a Neutral competent electrician using a double (Black or Blue) pole control unit of 3 0 ampere minimum Earth capacity with 3mm minimum contact (Green / Yellow... -
Page 26: Connect To The Gas Supply
INSTALLATION INSTRUCTIONS Connect to the gas supply Commissioning The inlet to the cooker is ” RP internal ⁄ situated at the rear centre. Burner aeration Fit the bayonet connection. This All burners have fixed aeration and no should be located so as to ensure the adjustment is possible. -
Page 27: Technical Data
This information is relevent to the Aeration - Fixed following appliances: Appliance class - Class 1, freestanding Stoves 1100DFa cooker Stoves Precision 1100DFa Stoves Heritage 1100DF Electrical supply Data badge - Located on the lower part 220 - 240V ~ 50Hz of the front frame. - Page 28 NOTES...
- Page 29 NOTES...
-
Page 30: Stoves Customer Care
Model No Serial No Please ensure you have the above details (Model No and Serial No) to hand when calling Stoves Customer Care. They are essential to booking your call. Outside the UK and Northern Ireland, refer to your local supplier. - Page 32 Stoney Lane, Prescot, Merseyside, L35 2XW 08 25211 03 © 2.2004...
