ATEN CL1000N Manual

Installation Options

ATEN LCD KVM Switches/LCD Consoles allow you to choose from a host of optional rack mount kits to meet
your needs, including the Single Person Easy Installation Rack Mount Kit, which streamlines the rack mounting
process. Normal rack mounting procedures call for at least two people to rack mount an LCD KVM switch/LCD
Console. The Single Person Easy Installation Rack Mount Kit enables one person to rack mount an LCD KVM
Switch. In just a matter of minutes, your new LCD KVM Switch/LCD Console can go from the box to the rack.

Single Person Installation

The following illustrations demonstrate just how easy it is to install your LCD KVM Switch with the Easy
Installation Rack Mount Kit.
1. Secure the side rails to the rack.

Standard Installation Rack Mount Kit

Standard Installation - Short
(Standard)

Easy Installation Rack Mount Kit

Easy Installation - Short
(2X-011G)
1
2. Slide the LCD KVM Switch
onto the rails and secure it
to the rack.
Standard Installation - Long
(2X-010G)
Easy Installation - Long
(2X-012G)
3. Now slide it out and you are
ready to work.
Standard Installation - Long
(2X-023G)
Easy Installation - Short
(2X-024G)
SOHO & SMB Solutions
Easy Installation - Long
(2X-025G)
