ChECkING TRANsMIssION flUID lEVEl (D)

(1) gauge (2) oil filler plug
(a) oil level is acceptable within range
1. Park the machine on a flat surface,
lower the implement and shut
"off" engine.
2. Depress the brake pedals and ap-
ply the parking brake.
3. set all shift levers into the neutral
position.
4. stop the engine.
M46-EU,AU-EEC인증용-07.indd 10
M46O705A
(1) oil Dipstick
(a) upper limit
5. pull out the oil dipstick, clean it,
and then insert it into its original
position. then, pull it out again and
check if the oil level is within the
specified range.
6. if the oil level is too low, add some
new oil so that the level is within
the allowable range. (refer to
"replacing transmission fluid and
filter" in the chapter "Service")
•
If oil level is low, do not run
engine.
•
Never add the oil over the up-
per limit.
M46O706A
(B) lower limit
IMPORTANT
