Congratulations, and welcome to the fabulous world of CK3520 / CK4020 / CK4220 ownership, where seri-
ous work is made fun again!
This versatile tractor is a culmination of the entire tractor and diesel engine knowledge gained by the Dae-
dong Industrial Co.,LTD over the years since 1947. The CK3520 / CK4020 / CK4220 and has been de-
signed with the finest materials and under rigid quality control standards set forth by the KIOTI Engineering
Department.
Knowledge of tractor operation is essential for many years of dependable service and reliability. To help new
owner's familiarize themselves with the KIOTI CK3520 / CK4020 / CK4220, it is the policy of KIOTI tractor
to provide an owner's manual which includes helpful information about tractor safety, operation and mainte-
nance. If the information you seek is not found in this manual, your KIOTI tractor dealer will be happy to help
you.
Please feel free to contact DAEDONG IND. CO.,LTD with your questions/concerns.
< NOTE >
Make sure to read this manual carefully and keep it handy for future reference.
When leasing or transferring this tractor, deliver this manual together with the tractor.
The specifications in this manual are subject to change without notice.
TC220-영문-유럽,호주향-OM-00.indd 1
FOREWORD
2018-01-15 오후 1:12:16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CK3520 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daedong CK3520

Summary of Contents for Daedong CK3520

  • Page 1 This versatile tractor is a culmination of the entire tractor and diesel engine knowledge gained by the Dae- dong Industrial Co.,LTD over the years since 1947. The CK3520 / CK4020 / CK4220 and has been de- signed with the finest materials and under rigid quality control standards set forth by the KIOTI Engineering Department.
  • Page 2 ISO 3600 EU STANDARDS This manual was compiled in compliance with the ISO 3600, standards and the instructions contained here comply with the requirements of the Machinery Directive 2010/52/EU in force in the European Community. For tractors sold or used outside the European Community, local laws will prevail.
  • Page 3 TABLE OF CONTENTS FOR SAFE OPERATION ......... BEFORE OPERATION ........SPECIFICATIONS ..........FUNCTION DESCRIPTION AND OPERATING TIPS ..SECTION OPERATION ............ 3-POINT HITCH IMPLEMENT AND LOADER OPERATION .. MAINTENANCE ..........STORAGE AND DISPOSAL ......TROUBLESHOOTING ........INDEX............... TC220-영문-유럽,호주향-OM-00.indd 3 2018-01-15 오후 1:12:16...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS FOR SAFE OPERATION ........1-1 BEFORE OPERATION ........2-1 PRECAUTIONS BEFORE OPERATION ....1-2 vEHICLE IDENTIFICATION NUMBER ..... 2-2 GEnEral PrECaUTiOnS ..........1-2 PrODUCTiOn SErial nUMbEr ........2-2 riSK OF OvErTUrninG ..........1-6 EnGinE SErial nUMbEr ..........2-2 TranSMiSSiOn nUMbEr ..........2-2 PRECAUTIONS DURING OPERATION ....
  • Page 5 TABLE OF CONTENTS IMPLEMENT LIMITATIONS ........3-14 WaTEr-in-FUEl WarninG laMP ......4-16 TUrn SiGnal laMP ............ 4-16 STaNDaRD IMPlEMENT DIMENSIONS ..... 3-14 PTO INDICaTOR ............4-16 FUNCTION DESCRIPTION AND OPERAT- SinGlE braKE liGhT ..........4-17 ING TIPS ............4-1 EnGinE Oil PrESSUrE WarninG laMP ....4-17 EXTERIOR vIEW ............
  • Page 6 TABLE OF CONTENTS DiFFErEnTial lOCK PEDal ........4-28 SUn viSOr ..............4-41 SEaT aDjUSTMEnT ............. 4-29 air rECirCUlaTiOn anD FrESh air MODE ..4-42 POSiTiOn COnTrOl lEvEr ........4-31 DEFOGGEr SWiTCh (iF EqUiPPED) ......4-42 DraFT COnTrOl lEvEr (iF EqUiPPED) ....4-32 hEaTER aND aIR CONDITIONER .......
  • Page 7 TABLE OF CONTENTS hOW TO DrivE .............. 5-9 aDjUSTMEnT OF liFT rOD ......... 6-4 hOW TO FOlD rOPS ..........5-13 aDjUSTMEnT OF TOP linK ......... 6-5 hOW TO raiSE rOPS TO UPriGhT POSiTiOn ..5-15 aDjUSTMEnT OF ChECK linK ........6-5 PaRkINg ...............
  • Page 8 TABLE OF CONTENTS hOW TO OPEN ThE hOOD (a) ........7-9 aDjUSTinG Fan bElT TEnSiOn (v) ......7-26 ChECKinG anD aDDinG FUEl (C) ......7-10 baTTEry (W) ..............7-26 ChECKinG TranSMiSSiOn FlUiD lEvEl (D) ...7-11 ChECkINg INTakE aIR lINE (x) ........ 7-29 ChECKinG EnGinE Oil lEvEl (E) ......
  • Page 9 TABLE OF CONTENTS TRACTOR STORAGE ..........8-2 DaIlY STORagE ............8-2 lONg-TERM STORagE ..........8-2 USinG TraCTOr aFTEr lOnGTErM STOraGE ..8-4 USAGE AND DISPOSAL .......... 8-4 TROUBLESHOOTING .........9-1 ENGINE TROUBLESHOOTING ....... 9-2 TRACTOR TROUBLESHOOTING ......9-4 INDEX..............10-1 TC220-영문-유럽,호주향-OM-00.indd 9 2018-01-15 오후...
  • Page 10 SAFETy AND vEHICLE DAMAGE WARNING This manual includes information titled as WARNING, CAUTION, IMPORTANT and NOTE. These titles indicate the following: This indicates that a condition may result in harm, serious injury or death to you or other persons if the warning is not heeded.
  • Page 11 UNIvERSAL SyMBOLS various universal symbols have been used on the instruments and controls of your KIOTI tractor. below is a list of the universal symbols and their meanings. low Fuel Warning light qT lamp high Temperature Coolant Temperature Preheat low Temperature Warning light Water-in-Fuel Warning Parking brake...
  • Page 12 TC220-영문-유럽,호주향-OM-00.indd 12 2018-01-15 오후 1:12:16...
  • Page 13 FOR SAFE OPERATION PREcAuTIONS bEFORE OPERATION ...... 1-2 General precautions ............1-2 risk of overturninG ..............1-6 PREcAuTIONS duRINg OPERATION ....... 1-9 When drivinG the tractor ..........1-13 When parkinG the tractor ..........1-15 When operatinG the p.t.o ............1-15 When usinG the 3-point hitch ...........1-17 SAFETy PREcAuTIONS duRINg SERvIcINg ..

  • Page 14: Precautions Before Operation

    / ck4020 / ck4220 PREcAuTIONS bEFORE OPERATION gENERAl PREcAuTIONS a careful operator is the best opera- tor. most accidents can be avoided safety helmet by observing certain precautions. to help prevent accidents, use these fit clothes safety precautions, and pay attention to the job at hand.
  • Page 15 for safe operation this tractor should be operated, ser- vice and repaired by a well-trained and skilled technician who is also aware of accompanying danger. it is necessary to follow any applicable accident prevention practices, general health and safety standards and traffic regulations.
  • Page 16 / ck4020 / ck4220 T66O103a T66O104a T66O105a 9. never operate this tractor or 12. never start the engine while 16. all persons using the tractor any other agricultural equipment standing on the ground. should have knowledge of its while under the influence of alco- proper operation and should read 13.
  • Page 17 for safe operation 20. for your safety ROPS with a seat belt is recommended for all applications. NOTE • always use seat belt when the tractor is equipped with a ROPS and cAb. never use the seat belt when tractor is not equipped with a ROPS.

  • Page 18: Risk Of Overturning

    / ck4020 / ck4220 RISK OF OvERTuRNINg ImPORTANT • The safe working practices listed hereunder concerns only a few cases of overturn- ing risk. • The list is therefore NOT com- prehensive of all possible cases. T55O116a Tg2O103a 22. this cabin is not certified for...
  • Page 19 for safe operation • reduce your speed before making wide turns. do not let the tractor jump or bounce on rough terrains. You could lose control. • don't pull a load too heavy for your tractor. it could run away on the down slope or the tractor could jack-knife around a towed load.
  • Page 20 / ck4020 / ck4220 Tg2O107a Tg2O108a • if you need cross a steep slope, • When driving across a slope with do not steer uphill, but slow down mounted implements, keep such and take a wide turn. always drive implements on the uphill side.

  • Page 21: Precautions During Operation

    for safe operation PREcAuTIONS duRINg OPERATION Tg2O109a H11O109a T66O108a 1. enter or leave the tractor leftward 2. avoid accidental contact with gear • avoid crossing steep slopes if pos- griping hand rail on a fender. shift levers while the engine is run- sible.
  • Page 22 / ck4020 / ck4220 Td2O110a T66O109a T66O110a (1) height control hitch (2) towing hook 3. do not park your tractor on a steep 4. do not operate your tractor in 5. make sure that all pressure lines incline, and remember to shut off an enclosed building without the are tight before starting the tractor.
  • Page 23 for safe operation 11. a safety chain will help control drawn equipment should it be accidentally separated from the draw-bar while transporting. using the proper adaptor parts, attach the chain to the tractor draw-bar support or other specified anchor locations. provide only enough slack in the chain to permit turn- ing.
  • Page 24 / ck4020 / ck4220 15. do not leave implements and at- tachments in the raised position when the vehicle is stopped or unattended. 16. When using implements or at- tachments with your tractor you should first read their respective owner's manual.

  • Page 25: When Driving The Tractor

    for safe operation whEN dRIvINg ThE TRAcTOR T66O114a T66O115a TE1O481a (1) Brake pedal (l) (2) Brake pedal (r) (3) Brake lock 19. driving forward out of a ditch or 21. When working in groups, always (a) lock (B) unlock up steep inclines can cause the let the others know what you are tractor to tip over backwards.
  • Page 26 / ck4020 / ck4220 4. Observe all local traffic and safe- ty regulations. 5. turn the headlights on. dim them when meeting another ve- hicle. 6. drive at speeds that allow you to maintain control at all times. 7. do not apply the differential lock while traveling at road speeds.

  • Page 27: When Parking The Tractor

    for safe operation whEN PARKINg ThE TRAcTOR whEN OPERATINg ThE P.T.O T66O120a H23O121a M55O107B (1) low speed indicator (1) p.t.o shaft cover (2) p.t.o shaft cap 11. When driving the tractor after 1. disengage the p.t.o, lower all 1. make sure the tractor is completely sunset, be sure to turn on the low implements, place all control le- stopped, gears are in neutral and...
  • Page 28 / ck4020 / ck4220 3. Before installing or using p.t.o wARNINg driven equipment, read the man- Ensure that implements and • ufacturer's manual and review the attachments are properly in- safety labels attached to the equip- stalled and that the tractor and ment.

  • Page 29: When Using The 3-Point Hitch

    for safe operation SAFETy PREcAuTIONS duRINg SERvIcINg whEN uSINg ThE 3-POINT hITch T66O124a T66O125a te1o4c1a (1) 3-point hitch lowering speed knob (a) fast (B) sloW 1. use the 3-point hitch only with in order to service your tractor you 2. allow the tractor time to cool off equipment designed for 3-point must park it on a flat level surface, set before servicing any part that may...
  • Page 30 / ck4020 / ck4220 T66O126a M55O114a M55O115a 6. do not remove the radiator cap 7. if the tractor must be lifted for 10. Use floor jack of suitable capac- while the coolant is hot. When servicing, take it to a suitably...
  • Page 31 for safe operation NOTE • apply the jack lift to the lifting points according to the type of operation and follow the safety procedures given before. T66O127a T66O128a 12. When working with your trac- 14. tire mounting should be done by tors electrical components you qualified professionals, with the must first disconnect the battery...
  • Page 32 / ck4020 / ck4220 Before pressurizing to the hy- draulic system, make sure that all connections are tight and that all line, pipes and hoses are free of damage. T66O129a T66O130a (1) cardboard (2) hydraulic line (3) magnifying Glass 17.

  • Page 33: Safety Precautions When Using The Loader

    for safe operation SAFETy PREcAuTIONS whEN uSINg ThE lOAdER H11O103a T66O131a H11O102a 20. keep environmental pollution in 1. never let anyone get in the loader 2. do not stand under the lifted load- mind. When replacing coolant or and use the loader as a work- er or get close to it.
  • Page 34 / ck4020 / ck4220 H11O104a H11O105a H11O106a 3. the loader can be turned over if a 4. never carry a big object with the 5. When attaching or detaching the draw-bar is improperly loaded. loader unless the correct imple- loader, fit parts which are con- ment is attached.
  • Page 35 for safe operation C56O185a H11O107a H11O108a H11O107a ImPORTANT 6. do not allow loader arms or attach- 7. keep bystanders away. no riders. • ROPS (Roll Over Protective ment to contact electrical power Structure), sun canopy are not lines. electrocution will cause seri- a FOPS (Falling Object Protec- ous injury or death.

  • Page 36: Implements And Attachments

    / ck4020 / ck4220 ImPlEmENTS ANd ATTAchmENTS ImPORTANT WARNING • • use exclusively front loader Keep the loader's operation approved by the tractor's man- manual together with the trac- ufacturer, with cE mark and tor's manual, always at hand parallelogram type.
  • Page 37 for safe operation • three-point hitch and side mounted swinging and shaking during trans- to reduce risks, the following precau- implements make a much larger port and work that could jeopardize tions should be used. arc when turning than towed equip- the stability of the tractor implement - only use loader equipped with a ment.

  • Page 38: Cleaning The Tractor

    / ck4020 / ck4220 clEANINg ThE TRAcTOR • check for correct coupling between • keep work surfaces and engine tow hook and trailer. see the tow- compartments clean. • Before ing attachments section. cleaning the machine, always lower implements to the ground, engage •...

  • Page 39: Safety Decal Maintenance

    for safe operation SAFETy dEcAl mAINTENANcE dEcAl mOuNTINg lOcATION T22O101B TC220-영문-유럽,호주향-OM-01.indd 27 2018-01-15 오후 1:29:55...
  • Page 40 / ck4020 / ck4220 T22O102B TC220-영문-유럽,호주향-OM-01.indd 28 2018-01-15 오후 1:29:57...
  • Page 41 for safe operation [ROPS] T22O103a TC220-영문-유럽,호주향-OM-01.indd 29 2018-01-15 오후 1:29:59...
  • Page 42 / ck4020 / ck4220 T22O104a TC220-영문-유럽,호주향-OM-01.indd 30 2018-01-15 오후 1:30:01...

  • Page 43: Description

    for safe operation dEScRIPTION (1) part no.: t2555-52611 (2) part no.: t4938-53551 (3) part no.: t4938-52351 Avoid flames and sparks. STOP engine while refueling ONLY use diesel. (4) part no.: t2555-52282 WARNING Do not remove the radiator cap when the engine is running or while the engine is hot.
  • Page 44 / ck4020 / ck4220 (5) part no.: t2555-52141 (6) part no.: t4625-52351 (7) part no.: t2615-55112 WARNING WARNING Do NOT run an engine Before starting and operating in an enclosed area. Know the operating and safety instructions Exhaust fumes cause in the operators manual and on the tractor.

  • Page 45: Cautions For Decal Maintenance

    for safe operation cAuTIONS FOR dEcAl mAIN- TENANcE (8) part no.: t2555-52262 (9) part no.: t2615-52131 safety decals are attached to the tractor for safe operation. make sure to follow the instruction on the decals WARNING as well as the following instruction: To prevent severe and deadly injuries during cAuTION...
  • Page 46 / ck4020 / ck4220 ImPORTANT • If a decal is damaged or lost, contact your local dealer im- mediately to install a new de- cal. • make sure to attach the decal to the correct position cleanly without bubbles after cleaning its mounting surface.

  • Page 47: Before Operation

    Before operation Vehicle identification numBer ......2-2 Production serial number ..........2-2 engine serial number ............2-2 transmission number ............2-2 essential replacement parts ......2-3 oils and fluids ................2-3 filters ..................2-4 belts and rubber Parts ............2-4 other comPonents ..............2-4 TC220-영문-유럽,호주향-OM-02.indd 1 2018-01-05 오후 1:33:33...

  • Page 48: Vehicle Identification Number

    / cK4020 / cK4220 Vehicle identification numBer production serial numBer engine serial numBer transmission numBer T21O201A T21O202A TC2O203A (1) Production serial number (1) engine serial number (1) transmission number this number is to identify the vehicle, Engine identification plate is installed...

  • Page 49: Essential Replacement Parts

    Specification Capacity [L (U.S.gal.)] transmission number tier2 or 3 (Without dPf) - aPi ch grade above cK3520/4020: 5.5 (1.45) engine oil tier4 (With dPf) - aPi cJ grade above cK4220: 6.0 (1.6) sae 10W30, 10W40, 15W40 date of Purchase...

  • Page 50: Filters

    / cK4020 / cK4220 filters Belts and ruBBer parts other components H11O205A-1 H11O206A H11O207A filters for the engine, transmission, air belts, hoses and boots, which are the battery condition is very impor- cleaner, and a/c are consumables that made of rubber, get weakened and tant for engine start performance purify oil and air.

  • Page 51: Specifications

    SpecificationS SpecificationS............3-2 ExtErnal dimEnsions .............3-2 major spEcifications .............3-4 noisE lEvEls as pErcEivEd by thE opErator ....3-10 vibration lEvEls of thE tractor Exposition to vi- brations ................. 3-11 Driving.SpeeD.table..........3-12 implement.limitationS......... 3-14 standard implEmEnt dimEnsions ........3-14 TC220-영문-유럽,호주향-OM-03.indd 1 2018-01-08 오전...

  • Page 52: External Dimensions

    / cK4020 / cK4220 SpecificationS external.DimenSionS mm (in.) cK4220c. item cK4020c cK4220cH 1. overall length (a1) 3,260 (128.3) 2. overall length (a2) 3,070 (120.9) 3. overall width (b) 1,385 (54.5) 4. overall height (c) 2,350 (92.5) 2,315 (91.1) 5. Wheel base (d) 1,670 (65.7)

  • Page 53: Specifications

    (in.) cK3520 cK3520D item cK4220 cK4020 cK4020D 1. overall length (a1) 3,260 (128.3) 2. overall length (a2) 3,070 (120.9) 3. overall width (b) 1,385 (54.5) 4. overall height (c) 2,500 (98.4) 2,111 (83.1) 2,500 (98.4) 5. Wheel base (d) 1,670 (65.7)

  • Page 54: Major Specifications

    / cK4020 / cK4220 major.SpecificationS [cabin] model item cK3520c cK4020c cK4220c cK4220cH model 3b183lWm-E1 3b183lWm-E 3b183lWm-a 3b183lWm-a no. of cylinders total displacement cc (cu) 1,826 (111.4) Engine bore and stroke mm (in.) 87 × 102.4 (3.4 x 4.03) Engine gross power kW (hp) 26.1 (35)
  • Page 55 spEcifications model item cK3520c cK4020c cK4220c cK4220cH forward 1.65 ~ 24.18 (1.03 ~ 15.02) 0 ~ 24.71 (0 ~ 15.35) Ground speed (tire for agri- cultural) Km/h (mph) reverse 1.61 ~ 23.56 (1.00 ~ 14.63) 0 ~ 14.82 (0 ~ 9.21) driving 4Wd (front Wheel drive) manual...
  • Page 56 / cK4020 / cK4220 model item cK3520c cK4020c cK4220c cK4220cH type independent pto shaft 1 - 3/8" 6 splines rear speed min. turning radius mm(in.) 2,450 (96.46) (With one rear wheel braked) Weight (with cabin) kg.f(lbs.) 1,514 (3,338) 1,506 (3,320) 1,513 (3,336) max.
  • Page 57 [ropS] model item cK3520 cK4020 cK4220 cK3520D cK4020D model 3b183lWm-E1 3b183lWm-E 3b183lWm-a 3b183lWm-E1 3b183lWm-E no. of cylinders total displacement cc (cu) 1,826 (111.4) Engine bore and stroke mm (in.) 87 × 102.4 (3.4 x 4.03) Engine gross power kW (hp) 26.1 (35)
  • Page 58 / cK4020 / cK4220 model item cK3520 cK4020 cK4220 cK3520D cK4020D forward 1.65 ~ 24.18 (1.03 ~ 15.02) Ground speed (tire for agri- cultural) Km/h (mph) reverse 1.61 ~ 23.56 (1.00 ~ 14.63) driving 4Wd (front Wheel drive) manual...
  • Page 59 1 - 3/8" 6 splines rear speed min. turning radius mm(in.) 2,450 (96.46) (With one rear wheel braked) Weight (with cabin) kg.f(lbs.) 1,314 (2,897) 1,290 (2,844) 1,365 (3,009) max.

  • Page 60: Noise Levels As Perceived By The Operator

    / cK4020 / cK4220 noiSe.levelS.aS.perceiveD.by.tHe.operator the following tables give the noise level values, measured from the driver’s seat in instantaneous conditions in compli- ance with standards no.1322/2014(rvcr) annexxiii and when driving by in compliance with standard 2015/96(rEp- pr) annexiii.

  • Page 61: Vibration.levels.of.the.tractor.exposition.to.vibrations

    spEcifications vibration.levelS.of.tHe.tractor.expoSition.to.vibrationS Warning • the.vibration.level.transmitted.to.the.body.as.a.whole.depend.on.different.parameters,.some.of.them.relat- ing to the machine, others to the terrain and many specific for the operator. The prevailing parameters are the.type.of.terrain.or.work.surface.and.the.ground.speed. • vibrations.cause.discomfort.for.the.operator.and.in.some.cases.put.his/her.health.and.safety.at.risk.. • make.sure.that.the.tractor.is.in.good.condition.and.that.all.routine.servicing.is.correctly.and.regularly.car- ried.out. • check.tire.pressure.and.the.steering.and.braking.systems. • check.that.the.operator's.seat.and.adjustment.systems.are.in.good.condition,.then.adjust.the.seat.to.the. operator's.weight.and.size. important • More information on Whole Body Vibration (WBV) on agricultural tractors can be found in more specific publications.and.the.relative.risks.can.be.taken.into.account.following.the.laws.of.the.country..in.order.to.

  • Page 62: Driving.speed.table

    / cK4020 / cK4220 Driving.SpeeD.table [manUal] Km/h (mph) tire.Size 11.2-24.4pr.(agricultural.tire) 1.65 (1.02) 1.61 (1.00) 2.12 (1.32) 2.06 (1.28) speed speed 2.68 (1.67) 2.61 (1.62) 3.37 (2.09) 3.28 (2.04) 5.22 (3.24) 5.08 (3.16) 6.70 (4.16) 6.52 (4.05) medium medium speed speed 8.47 (5.26)
  • Page 63 spEcifications [HSt] Km/h (mph) tire.size.11.2-24.(ag) range.shift forward reverse low speed 6.3 (3.91) 4.4 (2.73) medium speed 12.2 (7.58) 8.6 (5.34) high speed 24.3 (15.10) 16.7 (10.38) ※ these speed values are based on the technical design and can be different from the actual values. TC220-영문-유럽,호주향-OM-03.indd 13 2018-01-08 오전...

  • Page 64: Implement Limitations

    / cK4020 / cK4220 implement.limitationS StanDarD.implement.DimenSionS this Kioti tractor has been thoroughly tested for proper performance with implements sold or approved by Kioti. Use with implements which are not sold or approved by Kioti and which exceed the maximum specifications listed below, or which are otherwise unfit for use with this Kioti tractor may result in malfunctions or failures to the tractor, damage to other property and injury to the operator or others.
  • Page 65 spEcifications Actual figures trailer.loading.weight item implement weight W and / model max. drawbar load W max..capacity or size as in the following list 650 kg (1,433 lbs.) 3,000 kg (6,614 lbs.) (shown on the next page) lifting capacity max. loading weight ..... the max. allowable load which can be put on the 24 in. aft of hitch : W implement weight ..........
