Daedong KIOTI DK35SE Manual

Daedong KIOTI DK35SE Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

CHECK PERIOD
(Run Hours)
Engine oil level, Transmission oil level, Front axle oil level. Coolant level
Radiator grill cleaning, Engine air filter, Seat belt
Every 10 hours
Tire inflation pressure and damage, Parking brake condition
PTO shaft and Guard condition, 3 point hitch and Draw-bar condition, Pin assembly
Engine oil and Engine oil filter, Transmission oil filter, HST filter, Fuel filter
Initial 50 hours
Clutch pedal play, Brake pedal play, Fan belt tension
Engine oil and Engine oil filter
Every 100 hours
Clutch pedal play, Brake pedal paly, Fan belt tension and condition, Engine air hose and clamp
Transmission oil filter, HST filter, Fuel filter
Every 200 hours
Radiator hose line and clamp, Fuel line and clamp, Toe-in, Air cleaner filter
Every 400 hours
Transmission oil, Front axle oil
Every 800 hours
Engine intake, exhaust valve
Every 1,000 hours
Coolant
Every 1 year
Air-con filter, Engine air filter
Every 2 years
Coolant
Using unspecified parts or oil and fuel with poor quality can damage the tractor seriously.
For detailed maintenance interval and procedures, refer to "Service" in chapter 7.
MAJOR MAINTENANCE ITEMS
CHECK AND MAINTENANCE ITEMS
REMARKS
Check
Check
Check
Check
Replace
Check
Replace
Check
Replace
Check
Replace
Adjust
Replace
Replace
Replace

Advertisement

Table of Contents
loading

Related Manuals for Daedong KIOTI DK35SE

Summary of Contents for Daedong KIOTI DK35SE

  • Page 1 MAJOR MAINTENANCE ITEMS CHECK PERIOD CHECK AND MAINTENANCE ITEMS REMARKS (Run Hours) Engine oil level, Transmission oil level, Front axle oil level. Coolant level Check Check Radiator grill cleaning, Engine air filter, Seat belt Every 10 hours Tire inflation pressure and damage, Parking brake condition Check PTO shaft and Guard condition, 3 point hitch and Draw-bar condition, Pin assembly Check...
  • Page 2 This versatile tractor is a culmination of the entire tractor and diesel knowledge gained by the Daedong Indus- trial Co.,LTD over the years since 1947 and has been designed with the finest materials and under rigid quality control standards set forth by the KIOTI Engineering Department.
  • Page 4 SAFETY PRECAUTIONS ....... PRECAUTIONS BEFORE OPERATION ..SPECIFICATIONS .......... DESCRIPTION OF OPERATING SYSTEM ..SECTION OPERATION ............ 3-POINT HITCH IMPLEMENT OPERATION . MAINTENANCE ..........STROAGE AND DISPOSAL ......TROUBLESHOOTING ........INDEX ..............

  • Page 5: Table Of Contents

    TABLE OF CONTENTS SAFETY PRECAUTIONS ....... 1-1 VEHICLE IDENTIFICATION NUMBER ..2-2 PRECAUTIONS BEFORE OPERATION ..1-2 PRECAUTIONS DURING OPERATION ..1-5 ESSENTIAL REPLACEMENT PART .... 2-4 SPECIFICATIONS .......... 3-1 SAFETY PRECAUTIONS DURING SERVICING ..........1-11 EXTERNAL DIMENSIONS ......3-2 SAFETY PRECAUTIONS WHEN USING THE LOADER ..........
  • Page 6 TABLE OF CONTENTS SWITCH ............4-5 OPERATING THE CONTROLS ....4-21 INSTRUMENT PANEL ........ 4-13...
  • Page 7 TABLE OF CONTENTS TIRES, WHEELS AND BALLAST ....4-51 OPERATION ........... 5-1 PRE-OPERATION ........5-2 CABIN SYSTEM ......... 4-38 INITIAL OPERATION ........5-3 OPERATING THE ENGINE ......5-3 OPERATING THE TRACTOR ....5-10...
  • Page 8 TABLE OF CONTENTS REMOVAL AND INSTALLATION OF 3-POINT HITCH IMPLEMENT ........6-6 HANDLING LOADER ........6-10 MAINTENANCE ..........7-1 MAINTENANCE CHECK LIST ...... 7-3 3-POINT HITCH IMPLEMENT OPERATION .. 6-1 HANDLING 3-POINT HITCH IMPLEMENT ..6-2 LUBRICANTS ..........7-6 MAINTENANCE CODE ........ 7-7 ATTACHING DEVICES FOR AN IMPLEMENT6-4 ADJUSTMENT OF LIFT ROD ...........
  • Page 9 TABLE OF CONTENTS...
  • Page 10 STROAGE AND DISPOSAL ......8-1 TRACTOR STORAGE ......... 8-2 USAGE AND DISPOSAL ......8-5 TROUBLESHOOTING ........9-1 ENGINE TROUBLESHOOTING ....9-2 TRACTOR TROUBLESHOOTING....9-4...
  • Page 11 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as WARNING, CAUTION, IMPORTANT and NOTE. These titles indicate the following: ! ! ! ! ! This indicates that a condition may result in harm, serious injury or death to you or other persons if the warning is not heeded. Follow the advice provided with the warning.
  • Page 12 UNIVERSAL SYMBOLS Various universal symbols have been used on the instruments and controls of your KIOTI tractor. Below is a list of the universal symbols and their meanings. Fuel-Level Position Control-Lowered Position Low Range Engine Coolant-Temperature Hazard Warning Lights Coolant Parking Brake Headlight-Low Beam Preheat...

  • Page 14: Safety Precautions

    SAFETY PRECAUTIONS PRECAUTIONS BEFORE OPERATION ....1-2 GENERAL PRECAUTIONS ............1-2 PRECAUTIONS DURING OPERATION ..... 1-5 WHEN STARTING THE ENGINE ..........WHEN DRIVING THE TRACTOR ..........WHEN PARKING THE TRACTOR ..........WHEN PARKING THE TRACTOR .......... WHEN USING THE 3-POINT HITCH ........SAFETY PRECAUTIONS DURING SERVICING ..

  • Page 15: Precautions Before Operation

    DK35(CH)SE/DK40(CH)SE/DK45(C)HSE PRECAUTIONS BEFORE OPERATION GENERAL PRECAUTIONS A careful operator is the best operator. Most accidents can be avoided by ob- serving certain precautions. To help pre- vent accidents, use these safety precautions, and pay attention to the job at hand. If you can prevent an accident, your time will have been well spent.
  • Page 16 SAFETY PRECAUTIONS T66O103A T66O104A T66O105A 9. Never operate this tractor or any 12. Never start the engine while stand- 16. All persons using the tractor should other agricultural equipment while ing on the ground. have knowledge of its proper opera- under the influence of alcohol, tion and should read this manual 13.
  • Page 17 DK35(CH)SE/DK40(CH)SE/DK45(C)HSE 20. For your safety ROPS with a seat belt is recommended for all applications. NOTE Always use seat belt when the trac- tor is equipped with a ROPSand CAB. Never use the seat belt when tractor is not equipped with a ROPS.

  • Page 18: Precautions During Operation

    SAFETY PRECAUTIONS PRECAUTIONS DURING OPERATION WHEN STARTING THE ENGINE T66O108A T66O109A T66O110A 1. Avoid accidental contact with gear 2. Do not park your tractor on a steep 3. Do not operate your tractor in an en- shift levers while the engine is incline, and remember to shut off the closed building without the proper running.
  • Page 19 DK35(CH)SE/DK40(CH)SE/DK45(C)HSE H23O111A T66O112A T66O113A (1) Drawbar 4. Make sure that all pressure lines are 6. If the front of the tractor tends to rise 7. Always use the proper ballast weight tight before starting the tractor. up when heavy implements are at- on your tractor when using rear tached to the three point hitch, implements.
  • Page 20 SAFETY PRECAUTIONS 9. Do not leave equipment in the raised position when the vehicle is stopped or unattended. 10. When using implements or attach- ments with your tractor you should first read their respective owner's manual. You should always keep their safe operation procedures in mind.

  • Page 21: When Driving The Tractor

    DK35(CH)SE/DK40(CH)SE/DK45(C)HSE WHEN DRIVING THE TRACTOR MANUAL type HST type H23116A H23O117A T66O118A (1) Brake Pedal Lock (2) Brake Pedal (L) (1) Brake Pedal Lock (2) Brake Pedal (L) (3) Brake Pedal (R) (3) Brake Pedal (R) 1. Lock the brake pedals together when 2.

  • Page 22: When Parking The Tractor

    SAFETY PRECAUTIONS WHEN PARKING THE TRACTOR 4. Observe all local traffic and safety regulations. 5. Turn the headlights on. Dim them when meeting another vehicle. 6. Drive at speeds that allow you to maintain control at all times. 7. Do not apply the differential lock while traveling at road speeds.

  • Page 23: When Using The 3-Point Hitch

    DK35(CH)SE/DK40(CH)SE/DK45(C)HSE WHEN USING THE 3-POINT WHEN OPERATING THE P.T.O. HITCH H23O121A T66O122A H23O123A (1) P.T.O Shaft Cover (1) 3-point hitch lowering speed knob (2) P.T.O Shaft Cap (A) “FAST” (C) “LOCK” (B) “SLOW” 1. Make sure the tractor is completely 1.

  • Page 24: Safety Precautions During Servicing

    SAFETY PRECAUTIONS SAFETY PRECAUTIONS DURING SERVICING T66O124A T66O125A T66O126A In order to service your tractor you must 2. Allow the tractor time to cool off be- 6. Do not remove the radiator cap while park it on a flat level surface, set the fore servicing any part that may have the coolant is hot.
  • Page 25 DK35(CH)SE/DK40(CH)SE/DK45(C)HSE T66O127A T66O128A T66O129A (1) Cardboard (3) Magnifying Glass (2) Hydraulic Line 7. When working with your tractors 9. Tire mounting should be done by 12. Make sure that wheel bolts have been tightened to the specified electrical components you must first qualified professionals, with the torque.

  • Page 26: Safety Precautions When Using The Loader

    SAFETY PRECAUTIONS SAFETY PRECAUTIONS WHEN USING THE LOADER H11O102A T66O130A T66O131A 14. Fluid escaping from pinholes may 15. Keep environmental pollution in Never let anyone get in the loader and be invisible. Do not use hands to mind. When replacing cooant or oil, use the loader as a workbench.
  • Page 27 DK35(CH)SE/DK40(CH)SE/DK45(C)HSE H11O103A H11O104A H11O105A Do not stand under the lifted loader or The loader can be turned over if a draw- Never carry a big object with the loader get close to it. Also, lower the loader bar is improperly loaded. unless a proper implement is attached.
  • Page 28 SAFETY PRECAUTIONS H11O106A H11O107A H11O108A When attaching or detaching the Do not allow loder arms or attachment Keep bystanders away. No riders. loader, fix all parts which are connected to contact electrical power lines. Elec- to the bucket and boom. The bucket or trocution will cause serious injury or boom can be accidentally dropped death.

  • Page 29: Safety Decal Maintenance

    DK35(CH)SE/DK40(CH)SE/DK45(C)HSE SAFETY DECAL MAINTENANCE DECAL MOUNTING LOCATION T66O132A...

  • Page 30: Decals

    SAFETY PRECAUTIONS DECALS (1) Part No. : T2615-53561 (3) Part No. : T4625-52351 (5) Part No. : T2615-54112 (2) Part No. : T2625-55111 (4) Part No. : T4625-52361 (6) Part No. : T2350-54141...
  • Page 31 DK35(CH)SE/DK40(CH)SE/DK45(C)HSE (7) Part No. : T2325-50512 (9) Part No. : T2181-54121 (8) Part No. : T2445-50724 (10) Part No. : T2325-50743...

  • Page 32: Cautions For Decal Maintenance

    SAFETY PRECAUTIONS CAUTIONS FOR DECAL MAINTENANCE Safety decals are attached to the trac- IMPORTANT tor for safe operation. Make sure to fol- If a decal is damaged or lost, low the instruction on the decals as well contact your local KIOTI dealer as the following instruction: immediately to install a new ! ! ! ! !
  • Page 33 MEMO MEMO...

  • Page 34: Precautions Before Operation

    PRECAUTIONS BEFORE OPERATION VEHICLE IDENTIFICATION NUMBER ....... 2-2 PRODUCTION NUMBER ............2-2 ENGINE NUMBER ..............2-2 TRANSMISSION NUMBER ............2-3 ESSENTIAL REPLACEMENT PART ......2-4 OILS AND FLUIDS ..............2-4 FILTERS ..................2-4 BELTS AND RUBBER PARTS ............ 2-5 OTHER COMPONENTS ............2-5...

  • Page 35: Vehicle Identification Number

    DK35(CH)SE/DK40(CH)SE/DK45(C)HSE VEHICLE IDENTIFICATION NUMBER PRODUCTION NUMBER ENGINE NUMBER TRANSMISSION NUMBER H11O203A H11O201A H11O202A (1) S/N Identification Plate (1) Engine Serial Number (1) Transmission Serial Number This number is to identify the vehicle, The engine serial number is on the in- The transmission number is stamped and its plate is attached on the front take manifold.
  • Page 36 PRECAUTIONS BEFORE OPERATION Your dealer is interested in your new Identification No. tractor and has the desire to help you get the most value from it. After read- ing this manual thoroughly, you will find Engine Serial No. that you can do some of the regular maintenance yourself.
