- Page 1 SIMP HOME L I F E B Y D E S I G N ARTISAN HOLDEN STRATFORD BEDSIDE TABLE MODEL # 3AXCART-02GR 1/13...
- Page 2 SIMP HOME L I F E B Y D E S I G N Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –...
-
Page 3: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product Keep this manual for future reference. SAFETY INFORMATION Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all of the parts and hardware required. Hardware package may have spare parts. -
Page 4: Care And Maintenance
IMPORTANT : Please read this manual carefully before beginning assembly of this product Keep this manual for future reference. CARE and MAINTENANCE Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. - Page 5 PRE ASSEMBLY INFORMATION MODEL # 3AXCART-02GR PARTS DESCRIPTION SHELF BOTTOM SHELF QTY 1 QTY 1 QTY 1 TOP BACK PANEL LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 LEFT DRAWER SIDE DRAWER FRONT BOTTOM BACK PANEL QTY 1 QTY 1 QTY 1 RIGHT DRAWER SIDE...
-
Page 6: Hardware Description
PRE ASSEMBLY INFORMATION MODEL # 3AXCART-02GR HARDWARE DESCRIPTION ALLEN KEY BOLT ALLEN KEY SCREW CAM LOCK PIN CAM LOCK M6 X 30 mm M6 X 30 mm QTY 8 QTY 4 QTY 4 SETS HANDLE WOOD DOWEL ALLEN KEY M4 X 27 mm Ø8 X 30 mm QTY 1 QTY 1 SET... - Page 7 COMPONENTS – KEY DIAGRAM MODEL # 3AXCART-02GR 7/13...
- Page 8 ASSEMBLY MODEL # 3AXCART-02GR STEP 1 1. Attach 4 Cam Lock Pins 3 to pre-drilled holes at back of Drawer Front F . 2. Align Cam Lock Pins with pre-drilled holes and attach Drawer Sides GL , GR . 3. Insert 2 Cam Locks 3 into pre-drilled holes on each Drawer Side GL , GR . 4.
- Page 9 ASSEMBLY MODEL # 3AXCART-02GR STEP 3 1. Align Drawer Back H with Drawer Bottom I and press firmly into slot . 2. Attach Drawer Back using 2 Allen Key Screws 2 through pre-drilled holes on each Side GL , GR . 3.
- Page 10 ASSEMBLY MODEL # 3AXCART-02GR STEP 5 1. Insert 6 Dowels 5 into pre-drilled holes on Shelf C . 2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. ½ length of Dowels should be exposed. 3. Align pre-drilled holes on Sides DL , DR with Dowels 5 on Shelf C . 4.
- Page 11 ASSEMBLY MODEL # 3AXCART-02GR STEP 6 1. Attach Top A to Sides DL , DR using 4 Allen Key Bolts 1 ( 2 Bolts / each Side ). 2. Use Allen Key 6 to tighten bolts. Do not over-tighten. 11/13...
- Page 12 ASSEMBLY MODEL # 3AXCART-02GR STEP 7 1. Attach Back Panels E1 , E2 to back frame of cabinet using Phillips Screws Round Head 7 through pre-drilled holes. 2. Use Phillips screwdriver to tighten screws. STEP 8 1. Insert assembled drawers into glides on assembled table. 12/13...
-
Page 13: Warranty
SIMP HOME L I F E B Y D E S I G N WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase.
