HAMPTON BAY Cunningham Use And Care Manual

3 person cushioned swing
Hide thumbs
Table of Contents

Advertisement

Quick Links

Item #0000 000 000
Model #GSS00132D
USE AND CARE GUIDE
Cunningham 3 Person Cushioned Swing
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this swing. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cunningham and is the answer not in the manual?

Questions and answers

Becky Wood
June 22, 2025

Is it possible to order a replacement top?

0

Subscribe to Our Youtube Channel

Related Manuals for HAMPTON BAY Cunningham

Summary of Contents for HAMPTON BAY Cunningham

  • Page 1 THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this swing. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Planning Assembly ..............3 Important Safety Instructions ........2 Hardware Included..............3 Save These Instructions ............2 Package Contents..............4 Read All Instructions Before Use ..........2 Assembly.................

  • Page 3: Warranty

    Warranty 1 YEAR FRAME AND 1 Y EAR FABRIC LIM ITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for one year, and a one year limited warranty for the fabric. WHAT IS NOT COVERED Its remains the customer’s responsibility for freight and packaging charges to and from our service center.

  • Page 4: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Top bar Side bar Seat Long swing pipe Short swing pipe Curved bar Support bar Canopy Back cushion Seat cushion...

  • Page 5: Assembly

    Assembly Assembling the swing frame Attach two sets of the legs (B) to the top bar (A) using M8x100 combination bolts, washers and nuts (AA). Attach the support bars (JJ) to the legs (B) and the top bar (A) using M8x50 combination bolts, washers and nuts (CC) and M8x45 combination bolts, washers and nuts (DD).
  • Page 6 Assembly (continued) Attaching the arms to the seat Attach the arms (E) to the seat (D) using M8x90 combination bolts, washers and nuts (BB) and M6x85 combination bolts, washers and nuts (EE). Once all of the bolts are in place, fully tighten the bolts.
  • Page 7 Assembly (continued) Attaching the long swing pipes and the short swing pipes to the arms Attach the long swing pipes (F) and the short swing pipes (G) to the arms (E) using M6x60 combination bolts, washers and nuts (FF). Connect the top of the two swing pipes (F and G) using the hooks (II). Once all of the bolts are in place, fully tighten the bolts.
  • Page 8 Assembly (continued) Attaching the seat to the swing frame Attach the assembled seat to the swing frame using the hooks (II).
  • Page 9 Assembly (continued) Assembling the top frame Attach the support bars (I) to the curved bars (H) using M6x30 bolts (HH). Fully tighten all of the bolts on the top frame using the hex wrench (LL) before placing the canopy. Place the canopy (J) on the assembled top frame and tie the canopy (J) to the curved bars (H) by affixing the Velcro. NOTE: Pay attention to the direction of the curved bars (H).
  • Page 10 Assembly (continued) Attaching the top frame to the top bar Attach the top frame to the top bar (A) using the screw knobs (KK) on both sides. Adjust the angle of the top frame and fully tighten the screw knobs (KK) in the clockwise direction. Place the back cushions (K) and the seat cushion (L) on the seat.

  • Page 11: Care And Cleaning

    Assembly (continued) Tightening the bolts Ensure the swing is tightly assembled and stable before use. Care and Cleaning For best results, clean the swing with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. Do not clean with abrasive materials, bleach, or solvents.
  • Page 12 1-855-HD-HAMPTON HOMEDEPOT.CA For certi cation use only Factory ID # GSS00132D...
