Item # 0000 000 000
Model # GCS09189A
USE AND CARE GUIDE
KIKO STEEL EGG SWING OPEN WEAVE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this egg swing. We strive continually to create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY KIKO GCS09189A
Summary of Contents for HAMPTON BAY KIKO GCS09189A
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this egg swing. We strive continually to create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents........2 Pre-Assembly. -
Page 3: Warranty
Warranty 3-YEAR FRAME LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for three (3) years. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover s warranty. -
Page 4: Hardware Included
Pre-assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity M8x55 Combination Bolt M8x30 Combination Bolt M8x25 Combination Bolt M8x15 Combination Bolt M6x75 Combination Bolt Hook Connecting Ring Plastic Muf er Hex Wrench Wrench... -
Page 5: Package Contents
Pre-assembly (continued) PACKAGE CONTENTS Part Description Quantity Left Base Right Base Lower Hanging Bar Upper Hanging Bar Base Connecting Tube Upper Frame Lower Frame Seat Cushion Back Cushion HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. -
Page 6: Assembly
Assembly Connecting the Right Base to the Left Base Place the left base (A) and the right base (B) on a soft surface. Attach the left base (A) to the right base (B) using base connecting tube (E) and connecting Ring (GG), locked by M8x15 combination bolt (DD). - Page 7 Assembly Attaching the Upper Frame to the Lower Frame Attach the upper frame (F) to the lower frame (G) using M6x75 combination bolt (EE). NOTE: Loosely tighten all the bolts rst, then tighten all the bolts using the hex wrench (II) and wrench (JJ). Hanging the Hook on the Upper Hanging Bar Put the plastic muf er (HH) on the upper frame (F).
- Page 8 Assembly Attach the Safety Rope Take down the safety rope which is on the lower frame (G). Use the safety rope through the lower hanging bar (C) and relock, as shown below. Checking the Egg Chair Put the seat cushion (H) and the back cushion (I) on the basket. Ensure that all connections are secure before use.
-
Page 9: Care And Cleaning
Care Care and Cleaning For best results, clean the frame with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. Do not clean with abrasive materials, bleach or solvents. Store the egg swing in a dry sheltered place when not in use. Keep the egg swing from re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind. - Page 10 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. For certification use only...
