Connection Schematic - GE Arize Element Top Light Installation Manual

Connection Schematic

RISK OF ELECTRICAL SHOCK: Turn power OFF before inspection, installation or removal.
RISQUE DE CHOC ELECTRIQUE: Coupez l'alimentation avant l'inspection, l'installation ou la désinstallation.
Ambient temperature surrounding each driver must be lower than 104°F (40°C). / La température ambiante autour de
chaque module d'alimentation ne doit pas excéder 104°F (40°C).
Use proper circuit
protection level
AC line
Driver Input Wire
Colors
Black = Line 1
White = Neutral or Line 2
Yellow/Green = Ground
Plug together
Connect the light engine to driver prior to powering the driver. Plug together cables between light engine and
driver. For longer distances between light engine and driver, use an inter-connection cable (6 or 12 feet long) to
complete connection.
RISK GROUP 2 - CAUTION / ATTENTION - RAYONNEMENT LUMINEUX GROUPE 2
Possibly hazardous optical radiation emitted from this product. Do not stare at operating lamp. May be harmful to the eyes.
Le rayonnement lumineux émis par ce produit est potentiellement dangereux. Ne pas regarder la lumière émise
directement car elle pourrait occasionner des dommages aux yeux.
Electrical products must not be thrown out with domestic waste. They must be taken to
a communal collecting point for environmentally friendly disposal in accordance with
local regulations. Contact your local authorities or stockist for advice on recycling. The
packaging material is recyclable. Dispose of the packaging in an environmentally friendly
manner and make it available for the recyclable material collection-service.
Conforms to the following standards:
WARNING / AVERTISSEMENT
Driver bank plate
Junction box
GE and the GE Monogram are trademarks of the General Electric Company and are used under license. Information provided is subject to
change without notice. All values are design or typical values when measured under laboratory conditions, and GE makes no warranty or
guarantee, express or implied, that such performance will be obtained under end-use conditions. © 2019 GE Current, a Daintree company.
www.LED.com
HORT110 (Rev 11/26/19)
3-Phase Y
* * *
N
L3
L2
L1
Driver Driver Driver
REPEAT FOR ENTIRE CIRCUIT BALANCING OUT EACH PHASE
*White = Neutral or Line 2
6' or 12' inter-connection cable (Maximum cumulative
length of inter-connection cable is 24 feet)
Call us today! 1-888-MY-GE-LED
Email us: horticulture.info@gecurrent.com
3-Phase ∆
Driver Driver Driver
Light engine
Visit www.LED.com
