OBSIDIAN CONTROL SYSTEMS NETRON RDM10 User Manual page 8

C O N N E C T I O N S : C O N T A C T C L O S U R E S
DO NOT APPLY VOLTAGE TO THE CONTACT! DOING SO WILL DAMAGE THE
INPUT AND IS NOT COVERED UNDER WARRANTY.
The RDM10 is shipped with two terminal blocks that connect to the back ports. Lost or missing blocks
can be purchased from authorized Obsidian Dealers.
8
10 Inputs are provided that can be mapped to various functions of the
RDM10. The inputs are simple dry contact closures and are provided
in ten pairs of trigger and ground connections.
