OBSIDIAN CONTROL SYSTEMS NETRON RDM10 User Manual page 16

M E N U : R E M O T E I N P U T S
The device supports ten remote assignments that can trigger
specific actions like recalling a cue or preset. These events are
recalled using local contact closures, DMX In, or a specific
EtherDMX Universe / Address.
SUB MENU
DMX Map for Remote Trigger
Inputs can be remotely activated over DMX, Art-Net, or sACN. The input is activated as long
as the DMX value is at the value shown below.
Value Action
0 – 10 Idle
11 – 20 Input 1
21 – 30 Input 2
31 – 40 Input 3
41 – 50 Input 4
51 – 60 Input 5
61 – 70 Input 6
71 – 80 Input 7
81 – 90 Input 8
91 – 100 Input 9
101 – 110 Input 10
111 – 255 Idle
16
OPTIONS / VALUES
Disable DMX
Cue
Cue
Mode
1:Splitter AB
2:Splitter A
3:HTP Merge
ACT
4:LTP Merge
5:Backup
Netron Preset
6:Toggle
7:ArtNet 2.x
8:Dual ArtNet 2,
9:sACN DHCP
10:Dual sACN DHC
User Preset 1-10
Send Value 0-255
Disable
Contact
Source Port A
DMX Port
Port B
ArtNet
sACN
Stops all DMX output for as long as contact is
closed
1-99 Recall a specific cue number
The cue is activated, and all times and links are
Trigger
processed even if the contact is opened again
The cue is activated, and all times and links are
Toggle
processed only as long as the contact is closed.
Recalls this Netron preset when the contact is
closed
Recalls this user preset when contact is closed
Sends specific DMX value on all ports for as
long as contact is closed
Input is disabled
Use local contact closure on the back of the
device
Use DMX Input Values
Art-Net Trigger
sACN Trigger
DESCRIPTION
