Summary of Contents for OBSIDIAN CONTROL SYSTEMS Netron RDM10
- Page 2 ©2019 OBSIDIAN CONTROL SYSTEMS all rights reserved. Information, specifications, diagrams, images, and instructions herein are subject to change without notice. Obsidian Control Systems logo and identifying product names and numbers herein are trademarks of ADJ PRODUCTS LLC. Copyright protection claimed includes all forms and matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted.
-
Page 3: Table Of Contents
C O N T E N T S GENERAL INFORMATION LIMITED WARRANTY SAFETY GUIDELINES OVERVIEW INSTALLATION CONNECTIONS MAINTENANCE SPECIFICATIONS DIMENSIONS... -
Page 4: General Information
G E N E R A L I N F O R M AT I O N INTRODUCTION Please read and understand the instructions in this manual carefully and thoroughly before attempting to operate this device. These instructions contain important safety and use information. UNPACKING Every device has been thoroughly tested and has been shipped in perfect operating condition. -
Page 5: Limited Warranty
The sole responsibility of Obsidian Control Systems under this warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole discretion of Obsidian Control Systems. All products covered by this warranty were manufactured after January 1, 1990, and bare identifying marks to that effect. -
Page 6: Safety Guidelines
This device is a sophisticated piece of electronic equipment. To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual. OBSIDIAN CONTROL SYSTEMS is not responsible for injury and/or damages resulting from the misuse of this device due to the disregard of the information printed in this manual. -
Page 7: Overview
K E Y F E A T U R E S The Netron RDM10 is a universal dual input RDM splitter with an advanced feature set to cover a wide variety of applications. Its combination of a high density ten-port AB splitter with a two port EtherDMX node, DMX cue recording plus contact closures for preset and cue recall make this a truly universal tool for installations and production environments. -
Page 8: Installation
CONSUMPTION OF OTHER MODEL DEVICES MAY EXCEED THE MAXIMUM POWER OUTPUT OF THIS DEVICE. CHECK SILK SCREEN FOR MAXIMUM AMPS. THE NETRON RDM10 IS DESIGNED TO BE RACK-MOUNTED; HOWEVER, IT CAN BE USED STAND-ALONE, WHERE THE DEVICE MUST SIT ON A FIRM FLAT SURFACE. -
Page 9: Connections
A C C O N N E C T I O N S The Obsidian Control Systems Netron RDM10 is rated 100-240V 50/60Hz and accepts AC mains power over a range of 90-264V 50/60Hz. Do not connect it to power outside this range. - Page 10 C O N N E C T I O N S : F R O N T & R E A R P A N E L S F R O N T C O N N E C T I O N S (12) 5pin DMX/RDM optically isolated ports Ports are bidirectional for DMX In and Output Full color OLED display...
- Page 11 C O N N E C T I O N S : C O N T A C T C L O S U R E S 10 Inputs are provided that can be mapped to various functions of the RDM10.
-
Page 12: Maintenance
M A I N T E N A N C E The Obsidian Control Systems Netron RDM10 is designed as a rugged, roadworthy device. The only required service is occasional cleaning. For other service related concerns, please contact your Obsidian Control Systems dealer, or visit www.obsidiancontrol.com. -
Page 13: Specifications
S P E C I F I C A T I O N S Connections Front (2) 5pin DMX Input (10) 5pin Opto-Isolated DMX Outputs Full color OLED display Encoder with Push-to-Select / Exit Button Back (2) 5pin DMX Input (parallel with front) (2) 5pin DMX Through (2) RJ45 Locking RJ45 Ethernet network In (10) Contact Closures (Terminal Block) -
Page 14: Dimensions
D I M E N S I O N S 1.73” [44mm] 6.33” [160.8mm] 5.76” [146.4mm]...
