Appendix A

Appendix A - Physical Specification

Front to Back Depth
Height (from table top inc. feet)
Width
Power
Unboxed Weight
Boxed Size
Boxed Weight
Note: All physical specification values are approximate.

Connector Pinouts

Mono Channels

Microphone Inputs
3-pin XLR Male
Pin Description
1 0V Chassis
2 Signal +ve (Hot)
3 Signal -ve (Cold)

Stereo Channels

Stereo Channel Line Inputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0V Chassis
Talkback Microphone Input
3-pin XLR Female
Pin Description
1 0V Chassis
2 Signal +ve (Hot)
3 Signal -ve (Cold)
26
310 mm / 12.2 inches
120 mm / 4.7 inches
218 mm / 8.6 inches (Excluding Trim)
270 mm / 10.6 inches (Including Trim)
38 Watts
3.5 kg / 7.7 lbs
Depth x Height x Width
325 mm x 155 mm x 360 mm (12.8" x 6.1" x 14.2")
6.0 kg / 13.3 lbs
Line Inputs
Pin
Tip
Ring
Sleeve
External Inputs
Stereo External Line Inputs
Pin
Tip
Ring
Sleeve
Foldback/Stereo Cue Outputs
Pin
Tip
Ring
Sleeve
1/4" TRS Jack Socket
Description
Signal +ve (Hot)
Signal -ve (Cold)
0V Chassis
1/4" TRS Jack Socket
Description
Signal +ve (Hot)
Signal -ve (Cold)
0V Chassis
1/4" TRS Jack Socket
Description
Signal +ve (Hot)
Signal -ve (Cold)
0V Chassis
