EVID High Performance Ceiling Speakers
EVID-PC6.2E | EVID-PC8.2E
en | Installation Note

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVID-PC6.2E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Electro-Voice EVID-PC6.2E

  • Page 1 EVID High Performance Ceiling Speakers EVID-PC6.2E | EVID-PC8.2E en | Installation Note...
  • Page 3: Table Of Contents

    Table of contents Safety Notices Introduction Important features System overview Packing list Product feature identification Dimensions Frequency response and impedance Beamwidth Directivity Equalization Installation Troubleshooting Technical data Electro-Voice Installation Note 2017.01 | 02 | F.01U.321.491...
  • Page 4: Safety

    Suspending any object is potentially dangerous and should only be attempted by individuals who have a thorough knowledge of the techniques and regulations of suspending objects overhead. Electro-Voice strongly recommends all loudspeakers be suspended taking into account all current national, federal, state, and local laws and regulations. It is the responsibility of the installer to ensure all loudspeakers are safely installed in accordance with all such requirements.
  • Page 5: Introduction

    Read through this manual to familiarize yourself with the safety information, features, and applications before you use these products. Important features EVID-PC6.2E — 6-inch Premium Ceiling Speaker ▪ High output true compression driver for wide dispersion and superior coverage control out to 20 kHz ▪...
  • Page 6: System Overview

    Terminal connector Cutout template Weatherized terminal cover Gland nut Screws A (x2) B (x4) C (x2) D (x2) J (x2) K (x8) F (x4) G (x2) I (x2) Figure 3.1: Components in kit 2017.01 | 02 | F.01U.321.491 Installation Note Electro-Voice...
  • Page 7: Product Feature Identification

    Ø 294.30 mm [11.59 in] Ø 248 mm [9.76 in] 11.6 mm Ø 327 mm [12.87 in] 10.7 mm Ø 280.5 mm [11.04 in] [0.46 in] [0.42 in] Figure 3.3: EVID-PC6.2E (left) and EVID-PC8.2E (right) dimensions Electro-Voice Installation Note 2017.01 | 02 | F.01U.321.491...
  • Page 8: Frequency Response And Impedance

    20000 3.16 Frequency (Hz) Frequency (Hz) EVID-PC6.2E Frequency Response and Impedance 1 EVID-PC8.2E Frequency Response and Impedance 1 watt / 4 meters / on axis (With EN54 required watt / 4 meters / on axis (With EN54 required equalization applied)
  • Page 9: Equalization

    When used in an EN54 installation the following equalization must be applied to the speakers: EVID PC6.2E EVID PC8.2E PEQ Frequency: 180 Hz PEQ Frequency: 152 Hz PEQ Filter Q: 2.0 PEQ Filter Q: 2.0 PEQ Gain: -6.0 dB PEQ Gain: -8.0 dB Electro-Voice Installation Note 2017.01 | 02 | F.01U.321.491...
  • Page 10: Installation

    A: Speaker ground point Figure 4.3: Secure rails to C-Ring Figure 4.4: Wiring – ground point Figure 4.5: Install the gland nut into the cover Figure 4.6: Run the wire cable through the gland nut. 2017.01 | 02 | F.01U.321.491 Installation Note Electro-Voice...
  • Page 11 Figure 4.9: Wiring single (left) double (right) Figure 4.10: Install the phoenix connector Figure 4.11: Adjust the length of the wire from Figure 4.12: Hold the wire while lowering the cover the gland nut. Electro-Voice Installation Note 2017.01 | 02 | F.01U.321.491...
  • Page 12 The safety cable should be installed with a minimum of 3-inches (76.2 mm) of slack. C: Recommended auxiliary support line slack is 76.2 mm–305 mm (3 in–12 in). Figure 4.15: Attach auxiliary support line Figure 4.16: Install the speaker into the ceiling 2017.01 | 02 | F.01U.321.491 Installation Note Electro-Voice...
  • Page 13 Figure 4.17: Tighten mounting tabs Figure 4.18: Tap selector Figure 4.19: Adjust tap selector Figure 4.20: Insert grille tether Figure 4.21: Attach the grille Figure 4.22: Installation complete Electro-Voice Installation Note 2017.01 | 02 | F.01U.321.491...
  • Page 14: Troubleshooting

    Which ever condition results in greater low-frequency output is the in- polarity condition. If these suggestions do not solve your problem, contact your nearest Electro-Voice dealer or Electro-Voice distributor. 2017.01 | 02 | F.01U.321.491...
  • Page 15: Technical Data

    Technical data EVID-PC6.2E EVID-PC8.2E Frequency Range (-10 db): 50 Hz – 20 kHz 40 Hz – 20 kHz Nominal Coverage 100° 120° (Conical): Power Handling (Direct 200 W Program, 100 W Pink Noise as per EN54-24 standard Coupled): Sensitivity per EN54-24 75 dB 74.5 dB...
  • Page 16 130 Perinton Pkwy, Fairport, NY, 14450, USA 0359-CPR-00615 EN 54-24:2008 Loudspeaker for voice alarm systems for fire detection and fire alarm systems for buildings Ceiling loudspeakers EVID-PC6.2E, EVID-PC8.2E Type A See product manual F.01U.321.491 for further equalization and installation information. Frequency Reproducibility...
  • Page 20 Bosch Sicherheitssysteme GmbH Bosch Security Systems, Inc Robert-Bosch-Ring 5 12000 Portland Avenue South 85630 Grasbrunn Burnsville MN 55337 Germany www.boschsecurity.com www.electrovoice.com © Bosch Sicherheitssysteme GmbH, 2017...
