Summary of Contents for Electro-Voice EVID-S
- Page 1 EVID-S Surface Mount Loudspeakers en | Installation manual...
-
Page 3: Table Of Contents
Frequency response and impedance EVID-S5.2/EVID-S5.2T speakers 6.2.1 Dimensions 6.2.2 Frequency response and impedance EVID-S8.2/EVID-S8.2T speakers 6.3.1 Dimensions 6.3.2 Frequency response and impedance Wall bracket dimensions EVID-S4.2/EVID-S4.2T wall bracket dimensions EVID-S5.2/EVID-S5.2T/EVID-S8.2/EVID-S8.2T wall bracket dimensions Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.360... -
Page 4: Safety
Suspending any object is potentially dangerous and should only be attempted by individuals who have a thorough knowledge of the techniques and regulations of suspending objects overhead. Electro-Voice strongly recommends all loudspeakers be suspended taking into account all current national, federal, state, and local laws and regulations. It is the responsibility of the installer to ensure all loudspeakers are safely installed in accordance with all such requirements. -
Page 5: Short Information
Speaker 5” cabinet 70/100V white pair EVID-S8.2B Speaker 8” cabinet 8 Ohm black pair EVID-S8.2W Speaker 8” cabinet 8 Ohm white pair EVID-S8.2TB Speaker 8” cabinet 70/100V black pair EVID-S8.2TW Speaker 8” cabinet 70/100V white pair Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.360... -
Page 6: Introduction
EVID-S Surface Mount Loudspeakers Introduction The EVID-S series from Electro-Voice is a line of compact, high-performance, two-way, full- range surface mount loudspeakers with excellent wide and uniform coverage, and outstanding performance. Their design makes these practically invisible for use in background and... -
Page 7: Packing List
Installation manual Table 3.1: Components list for speakers without transformer E (x2) B (x2) C (x2) A (x2) F (x2) G (x2) H (x2) Figure 3.1: Components list for speakers without transformer Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.360... - Page 8 EVID-S Surface Mount Loudspeakers Item Quantity Component Speakers with speaker brackets attached Wall mount brackets Dust covers Allen wrench Grille logos (spare) Safety screws for the mounting brackets Safety screw caps for the mounting brackets Covers for the locking bolt...
-
Page 9: Product Information
Grille Bubble level Wall bracket Safety cable loop Flush input cover Audio wire hole Locking bolt Audio connector Safety screw hole for bracket Speaker bracket Table 3.3: Product information for all models Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.360... -
Page 10: Installation And Wiring
EVID-S Surface Mount Loudspeakers Installation and wiring Installing the speaker For safety, ensure the mounting surface supports more than the weight of the speaker. Use only industry-accepted fasteners and mounting methods when mounting the wall bracket. Consult an expert if you are unsure. - Page 11 If the speaker installation will be delayed cover it with the paint shield/dust shield. Installing the speaker Loosen the locking bolt with the Allen wrench (supplied). Adjust the horizontal and vertical position of the bracket. Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.360...
- Page 12 EVID-S Surface Mount Loudspeakers Tighten the locking bolt with the Allen wrench (supplied). Push the speaker bracket onto the wall bracket. Slide the speaker bracket down to secure bracket to the wall bracket. This secures the bracket and makes electrical connection.
- Page 13 This redundant safety point should have as little slack as possible (less than 1-inch is preferable). Figure 4.1: Redundant safety point - 4" (left), 5" (center), 8" (right) Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.360...
-
Page 14: Wiring
EVID-S Surface Mount Loudspeakers Wiring 4.2.1 Wall bracket wiring The wall bracket and speaker can be wired using either 2-wires, for input only, or 4-wires, for input and parallel output. Figure 4.2: Wall bracket wiring – 2-wires, for input only Figure 4.3: Wall bracket wiring –... -
Page 15: Alternative Euroblock Connection
Wiring the speaker using the Euroblock connector and weather cover – optional accessory To wire the speaker using Euroblock connector and weather cover, do the following: Push the wire through the gland nut. Wire the Euroblock connector (A). Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.360... -
Page 16: Transformer Taps
EVID-S Surface Mount Loudspeakers Adjust the tap settings, if needed. Mount the speaker. Plug the Euroblock connector into the speaker. Insert the screws into the weather cover (B). Loosely tighten the four screws to keep the weather cover in place. -
Page 17: Evid-S5.2T Speaker 5" Cabinet 70/100V
4.3.2 EVID-S5.2T speaker 5” cabinet 70/100V Configuring the transformer settings To configure the transformer settings, do the following: Select the desired power tap by using the rotary switch on the input panel. Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.360... -
Page 18: Evid-S8.2T Speaker 8" Cabinet 70/100V
EVID-S Surface Mount Loudspeakers If 8 ohm mode is desired, remove the safety screw. Safety screw (A) is shown in the previous step. Attach the flush input cover (B). 4.3.3 EVID-S8.2T speaker 8” cabinet 70/100V Configuring the transformer settings To configure the transformer settings, do the following: Select the desired power tap by using the rotary switch on the input panel. -
Page 19: Replacing The Logo
Remove the existing logo. Clean the surface with alcohol. Align the logo with the logo recess on the grille. Remove the paper backing. Insert the logo. Press firmly to ensure the logo is applied. Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.360... -
Page 20: Troubleshooting
Poor System Check and correct the system grounding, as required. Grounding or Ground Loop If these suggestions do not solve your problem, contact your nearest Electro-Voice dealer or Electro-Voice distributor. 2017.08 | 01 | F.01U.345.360 Installation manual Electro-Voice... -
Page 21: Technical Data
5.4 kg (11.9 lb) (pair) Included hardware: Mounting bracket and 4-mm Allen wrench Packaged quantity: Half space (wall mounting). Half space (on wall) averaged 100 Hz – 10 kHz, 1 W. Without brackets. Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.360... -
Page 22: Dimensions
EVID-S Surface Mount Loudspeakers 6.1.1 Dimensions 140.0 mm [5.51 in] 118.2 mm [4.66 in] 193.0 mm [7.60 in] 184.0 mm [7.24 in] Figure 6.1: EVID-S4.2/EVID-S4.2T dimensions 6.1.2 Frequency response and impedance Figure 6.2: EVID-S4.2/EVID-S4.2T frequency response and impedance 2017.08 | 01 | F.01U.345.360... -
Page 23: Evid-S5.2/Evid-S5.2T Speakers
7.9 kg (17.5 lb) Included hardware: Mounting bracket and 5-mm Allen wrench Packaged quantity: Half space (wall mounting). Half space (on wall) averaged 100 Hz – 10 kHz, 1 W. Without brackets. Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.360... -
Page 24: Dimensions
EVID-S Surface Mount Loudspeakers 6.2.1 Dimensions 180.1 mm [7.09 in] 151.2 mm [5.95 in] 255.0 mm [10.04 in] 240.0 mm [9.45 in] Figure 6.3: EVID-S5.2/EVID-S5.2T dimensions 6.2.2 Frequency response and impedance Figure 6.4: EVID-S5.2/EVID-S5.2T frequency response and impedance 2017.08 | 01 | F.01U.345.360... -
Page 25: Evid-S8.2/Evid-S8.2T Speakers
14.8 kg (32.6 lb) Included hardware: Mounting bracket and 5-mm Allen wrench Packaged quantity: Half space (wall mounting). Half space (on wall) averaged 100 Hz – 10 kHz, 1 W. Without brackets. Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.360... -
Page 26: Dimensions
EVID-S Surface Mount Loudspeakers 6.3.1 Dimensions 250.0 mm [9.84 in] 223.2 mm [8.79 in] 390.2 mm [15.36 in] 311.0 mm [12.24 in] Figure 6.5: EVID-S8.2/EVID-S8.2T dimensions 6.3.2 Frequency response and impedance Figure 6.6: EVID-S8.2/EVID-S8.2T frequency response and impedance 2017.08 | 01 | F.01U.345.360... -
Page 27: Wall Bracket Dimensions
15.9 mm [0.6 in] [0.6 in] 4x ∅4.5 mm [4x ∅0.177 in] 117.0 mm 93.5 mm [4.6 in] [3.7 in] ∅8.0 mm [∅0.315 in] 15.5 mm [0.6 in] 51.8 mm [2.04 in] Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.360... -
Page 28: Evid-S5.2/Evid-S5.2T/Evid-S8.2/Evid-S8.2T Wall Bracket Dimensions
EVID-S Surface Mount Loudspeakers EVID-S5.2/EVID-S5.2T/EVID-S8.2/EVID-S8.2T wall bracket dimensions 19.5 mm 19.5 mm [0.8 in] [0.8 in] 4x ∅4.5 mm [4x ∅0.177 in] 156.0 mm 127.0 mm [6.1 in] [5.0 in] ∅8.0 mm [∅0.315 in] 21.0 mm [0.83 in] 69.1 mm [2.72 in]... - Page 32 Bosch Sicherheitssysteme GmbH Bosch Security Systems, Inc Robert-Bosch-Ring 5 12000 Portland Avenue South 85630 Grasbrunn Burnsville MN 55337 Germany www.boschsecurity.com www.electrovoice.com © Bosch Sicherheitssysteme GmbH, 2017...
