Instructions/Parts
Automatic Electrostatic
PRO
™
Air Spray Gun
For use with conductive spray materials (waterborne and other materials
less than 1 megohm-cm).
Part No. 24A206
100 psi (0.7 MPa, 7 bar) Maximum Air Inlet Pressure
100 psi (0.7 MPa, 7 bar) Maximum Working Fluid Pressure
For use in Class I, Div. I hazardous locations using Group D spray materials.
For use in Group II, Zone 1 areas using Group IIA spray materials.
2575
For Professional Use ONLY.
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
See page 2 for Table of Contents.
U.S. Patent Pending
Xs Auto Waterborne
II 2 G 0.24 mJ T6
FM08ATEX0075
313227E
ENG
TI13395a
