Instructions/Parts List
ELECTROSTATIC, WATERBORNE, AIR SPRAY
WB100 Isolation System and
™
PRO
Xs3 Spray Gun
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
100 psi (0.7 MPa, 7 bar) Maximum Air Inlet Pressure
100 psi (0.7 MPa, 7 bar) Maximum Working Fluid Pressure
For use when electrostatically spraying conductive,
waterborne fluids that meet at least one of the
following conditions for non-flammability:
FM Approved
•
The fluid has a flash point above 140°F (60°C)
and a maximum organic solvent concentration of
20%, by weight, per ASTM Standard D93. FM
•
The fluid does not sustain burning when tested per
ASTM Standard D4206 Sustained Burn Test.
CE-EN 50059 Compliant
•
Materials which cannot be ignited, in any mixture
with air, by an energy source of less than 500 mJ.
See page 3 for a List of Models
U.S. Patent No. 7,226,004
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2002, Graco Inc. is registered to I.S. EN ISO 9001
PRO Xs3
Smart Gun and
Fluid Hose
309293J
WB 100
Isolation Enclosure
TI1681A
TI2139a
