Graco PRO 247936 Instructions Manual

Manual electrostatic waterborne air spray gun 100 psi (0.7 mpa, 7 bar) maximum air inlet pressure 100 psi (0.7 mpa, 7 bar) maximum working fluid pressure
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instructions
Manual Electrostatic
PRO
Xs Waterborne
™
Air Spray Gun
For use with conductive spray materials (waterborne and other materials
less than 1 megohm-cm). For professional use ONLY.
For use in Class I, Div. I hazardous locations using Group D spray materials.
For use in Group II, Zone 1 areas using Group IIA spray materials.
II 2 G EEx 0.24 mJ
247936 Standard Model
247937 Smart Model
100 psi (0.7 MPa, 7 bar) Maximum Air Inlet Pressure
100 psi (0.7 MPa, 7 bar) Maximum Working Fluid Pressure
Important Safety Instructions:
Read all warnings and instructions in this manual.
Save these instructions.
See page 2 for Table of Contents.
U.S. Patent Pending
Standard Model
247936
312900C
Smart Model
247937
ENG
