San Jamar C3400C Manual

STAINLESS STEEL CUP DISPENSER
Thank you for choosing the Stainless Steel Cup Dispenser from San Jamar. We appreciate your business and are
confident that this NSF certified cup dispenser will improve the image and efficiency of your operation. Enjoy!
ADJUSTING THE DISPENSER
1.
Remove dispenser from
mounting flange by rotating
dispenser counter-clockwise.
5.
Rotate adjustment ring in
smaller increments until
one-at-a-time dispensing is
achieved.
DISASSEMBLY
1a.
Remove dispenser from mounting flange by rotating dispenser
counter-clockwise.
3.
Remove the pusher: the
pusher will slide out by tilting
the dispenser.
2.
Loosen the thumbnut using
either a flathead screwdriver
or a dime.
6.
Tighten thumbnut to maintain
dispensing adjustment using
either a flathead screwdriver
or a dime.
1b.
4.
Release locking tabs of trim ring
by applying pressure to tabs
from inside the cup dispenser
with a flathead screwdriver to
disengage
3.
Insert desired cups that fall
within adjustment range.
2a.
Remove the end cap and spring of the dispenser by depressing the
exposed tabs and rotating the cap to pull outward – the spring will
come along with the end cap.
5.
Once all three tabs are
disengaged, lift upward on the
trim ring to remove.
4.
Rotate adjustment ring until
cups are secure.
2b.
Disassembly continued on
reverse side.
