C2210C EZ-FIT
1. CUT HOLE IN COUNTER SURFACE
HOLE SAW RECOMMENDED
2. REMOVE TRIM RING TURNING
COUNTER CLOCKWISE
3. SECURE CUP DISPENSER TO COUNTER
WITH SUPPLIED SCREWS (#8 SCREWS)
4. SELECT PROPER SIZE GASKET FOR CUP
(SEE TABLE ON BACK)
Replacement paRts & accessoRies
X22mt
Black Mounting Ring (new low profile)
X22tR
Black Trim Ring (new low profile)
c2215
Spring
EURO CUP DISPENSER INSTALLATION INSTRUCTIONS
®
5. INSTALL GASKET OVER POSTS IN
UNDERSIDE OF RING
6. REPLACE COVER RING WITH GASKET BY TURNING
CLOCKWISE OVER MOUNTING RING UNTIL SECURE
7. LOAD CUPS THROUGH GASKET
(see reverse side for replacement gaskets)
c2203BK
End Cap
c3426BK
Cup Pusher
c2202sV
Wire Cage for Surface Mount
c22Xc
Chrome Trim Ring
