San Jamar Venue Instruction Sheet

Venue™ Stand Napkin Dispenser
Thank you for choosing the Venue™ napkin dispenser from San Jamar. We appreciate your business
and are confident that Venue™ will improve the image and efficiency of your operation. Enjoy!
3
2
1

To Load Dispenser

1. Open cover by pressing in on
both sides of cover and swing
cover up and back.

To Remove Face

1. Open cover by pressing in on
both sides of cover and swing
cover up and back.

To Mount Dispenser on Stand

1. Position closed napkin dispenser above the stand with the face oriented downward.
2. Locate lower mounting hook on stand and mate to slot in bottom of dispenser.
3. Once lower front hook of stand is secure in base of dispenser, insert dispenser into top hook on stand and lift
the stand's tab to snap firmly into place. When positioned and locked correctly, dispenser will not separate from
base unless rear locking tab is released.

To Remove Dispenser from Stand

1. Release top locking tab on stand by inserting finger into opening on back of stand and applying pressure
upward until latch releases dispenser from stand.

To Mount Dispenser on Wall

1. Determine position on wall/surface with unit open. Through the holes at back of unit, use pencil to mark spots
where drilling will be necessary. Try to mark spots as close as possible to the outer edges.
2. Drill marked spots on wall/surface with drill bit recommended by anchor manufacturer and wall type.
3. Complete installation using appropriate fasteners (screws, bolts, anchors, washers, etc.) for mounting. The
installation should be done with a flat washer between the head of the fastener and the inside back of the
dispenser. Four fasteners are recommended.
2. Using thumb, hold and move
pressure plate to back of unit
until locking tabs engage.
3. Load dispenser with desired
napkins.
2. Locate 2 tabs under front of face
and depress upward into base
one at a time.
4. Close cover.
NOTE: Pressure plate will
automatically release when cover
is closed.
b
3. Rotate face up and back (a).
Press in on both sides of face at
pivot points until clear of posts
and remove faceplate (b).
a
