San Jamar SN30 Manual

Mounting the Dispenser:
1. Remove the cap by pulling the cap upwards
2. Press the tab holding the backplate in place and slide
backplate down and off.
3A. (If using a level to mount the dispenser) Using a level, place
backplate on wall in the area to be mounted and mark the 3
hole locations.
3B. (If no level is available) Place backplate on wall in the area
to be mounted and mark the upper hole location. Hang the
dispenser from this single hole using supplied fasteners. Mark
the other 2 hole locations.
4. Drill holes and insert wall anchors (if used).
5. Mount backplate using the supplied fasteners.
6. Attach dispenser housing to backplate by holding the
dispenser against the wall above the backplate and sliding the
dispenser downward until there is a "click".
7. Install the cap by holding the cap against the wall above the
dispenser housing and sliding down until there is a "click".
Filling:
1. Remove the cap by pulling upwards.
2. Fill the dispenser with liquid soap or sanitizer.
3. Replace cap by holding the cap against the wall above the
dispenser housing and slide the cap downward until there is a
click.
4. It will take 4-8 strokes to prime the pump.
5. The dispenser is now ready for use.
6. DISCLAIMER: Soap containing scrubbers or abrasives will
cause the dispenser to leak or eventually fail. San Jamar is
not responsible for incorrect soap use that leads to faulty
dispenser operation or clogging. Use Liquid/Lotion soap.
Dispenser Activation
1. Push the lever located at the bottom, center of the cover.
Maintenance:
Periodically give the dispenser an overall cleaning – including
internal and external parts.
SN30 Classic Soap Dispenser
San Jamar Canada
555 Koopman Lane 3280 Bloor Street West
Elkhorn, Wisconsin 53121 Suite 1140
USA 11th Floor, Centre Tower
T: +1.262.723.6133 Toronto, ON M8X 2X3
F: +1.262.226.8664 CANADA
info@sanjamar.com T: +1.262.723.6133
www.sanjamar.com F: +1.262.226.8664
canada@sanjamar.com
© Copyright San Jamar, Inc. 2022
1
3B
6
Press with palm facing up
and fingers curled under
the dispenser
1
Europe México
Schoorstraat 26a, bus I Av. Paseo de la Reforma No. 350 - 10
2220 Heist-op-den-Berg Col. Juarez
BELGIUM Deleg. Cuauhtemoc, CP 06600
T: +32 15 22 81 40 MEXICO, D.F.
F: +32 15 22 81 48 T: +52 (55) 3626 0772
emea@sanjamar.com mexico@sanjamar.com
2
4
5
7 7
105026SJ
3A
