PCISA Intel Pentium-M/Celeron-M CPU Card with LCD/CRT
Quick Installation Guide
Package Contents
PCISA-6770-RS package includes the following items:
1x PCISA-6770-RS single board computer
1x ATA66/100 HDD cable P/N: 32200-000052-RS
1x KB/PS2 Mouse Y cable P/N: 32000-000138-RS
1x RS232 cable P/N: 19800-000027-RS
1x RS232/422/485 cable P/N:32200-000077-RS
1x USB cable P/N: CB-USB02A-RS
1x Audio cable P/N:19800-000044-RS
1 x mini jumper pack
1 x Utility CD
1 x QIG (quick installation guide)
VGA,Dual LAN,USB2.0 and Audio
PCISA-6770-RS
Version 2.0
May. 4, 2007
©2006 Copyright by IEI Technology corp.
All rights reserved.
1
Advertisement
Table of Contents
Related Manuals for IEI Technology PCISA-6770-RS
Summary of Contents for IEI Technology PCISA-6770-RS
-
Page 1: Quick Installation Guide
PCISA-6770-RS Quick Installation Guide Version 2.0 May. 4, 2007 Package Contents PCISA-6770-RS package includes the following items: 1x PCISA-6770-RS single board computer 1x ATA66/100 HDD cable P/N: 32200-000052-RS 1x KB/PS2 Mouse Y cable P/N: 32000-000138-RS 1x RS232 cable P/N: 19800-000027-RS... -
Page 2: Specifications
Specifications CPU: Intel Pentium M/Celeron M Socket 479 up to 400MHz FSB/Onboard Celeron M 800MHz zero cache System Chipset: Intel 852GM+ICH4 BIOS: AMI BIOS Label System memory: DDR266 SDRAM socket support up to 1GB Ethernet: 2x 10/100 Mbps Intel 82562ET/82551ER fast Ethernet controller onboard I/O Interface: 1 x RS-232... -
Page 3: Jumpers Setting And Connectors
Ordering Information Standard PCISA-6770E2-RS-R20 PCISA Intel Pentium-M/Celeron-M CPU Card with LCD/CRT VGA,Dual LAN,USB2.0 and Audio PCISA-6770E2-RS-800Z-R20 PCISA Intel Celeron-M 800MHz Zero Cache CPU Card with LCD/CRT VGA,Dual LAN,USB2.0 and Audio Optional: 1. FDD cable P/N:32200-000058-RS 2. RS232/LPT cable P/N: 19800-000027-RS Jumpers setting and Connectors LABEL FUNCTION... - Page 4 Label Function IDE1 Ultra ATA100 Primary (40 Pin) IDE2 Secondary IDE connectors (44 PIN ) FDD1 Floppy connector LPT1 Parallel port connector DIO1 Digital I/O COM1 Serial port connector(10 Pin) COM2 RS-232/422/485 connector(14 PIN) Compact Flash Storage Card Type II connector IRDA infrared interface port USB1 USB port connector...
- Page 5 CN3 : External Switches and Indicators PIN DESCRIPTION PIN DESCRIPTION Power LED Speaker + Speaker ATX POWER BUTTON PIN1 BUTTON BUTTON PIN2 Speaker - HDD LED HDD LED + 10 Reset PIN1 Reset Button 11 HDD LED - 12 Reset PIN2 KB1 : 5-pin Header CN4 : Backplane to CPU Keyboard Connector...
- Page 6 DIO1: Digital I/O DESCRIPTION DESCRIPTION OUT0 OUT1 OUT2 OUT3 DVI1 : DVI Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATA2- DATA2+ HP_DET DATA0- DATA0+ DDCCLK DDCDATA DATA1- GND- DATA1+ CLK+ CLK- CN1: backlight inverter connector DESCRIPTION GROUND BKL_POWER GROUND J3:External Power Connector DESCRIPTION GROUND GROUND...
- Page 7 LVDS1 : LVDS Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LVDSB_Y3- LVDSB_CLK+ LVDS_Y3+ LVDSB_CLK- LVDS_Y3- LVDSB_Y2+ LVDS_CLK+ LVDSB_Y2- LVDS_CLK- LVDSB_Y1+ LVDS_Y2+ LVDSB_Y1- LVDS_Y2- LVDSB_Y0+ LVDS_Y1+ LVDSB_Y0- LVDS_Y1- LVDS_Y0+ LVDS_Y0- VCC_LCD VCC_LCD VCC_LCD LVDSB_Y3+ VCC_LCD AUDIO1 PIN NO. DESCRIPTION PIN NO. DESCRIPTION SPEAK(L) SPEEAK(R)
-
Page 8: Board Layout: Jumper And Connector Locations
Board Layout: Jumper and Connector Locations...
