Banner EZ-SCREEN Instruction Manual

14/30 mm safety light screen
Hide thumbs Also See for EZ-SCREEN:
Table of Contents

Advertisement

Quick Links

®
EZ-SCREEN
14/30 mm Safety Light
Screen
Instruction Manual
Original Instructions
112852 Rev. J
8 May 2019
©
Banner Engineering Corp. All rights reserved
112852

Advertisement

Table of Contents
loading

Related Manuals for Banner EZ-SCREEN

Summary of Contents for Banner EZ-SCREEN

  • Page 1 ® EZ-SCREEN 14/30 mm Safety Light Screen Instruction Manual Original Instructions 112852 Rev. J 8 May 2019 © Banner Engineering Corp. All rights reserved 112852...

  • Page 2: Table Of Contents

    ® EZ-SCREEN 14/30 mm Safety Light Screen Contents 1 About This Document ..............................5 1.1 Important . . . Read This Before Proceeding! ..........................5 1.2 Use of Warnings and Cautions ................................ 5 1.3 EU Declaration of Conformity (DoC) ............................... 5 2 Standards and Regulations .............................
  • Page 3 7.2 Commissioning Checkout ................................59 7.3 Shift/Daily Checkout ..................................61 7.4 Semi-Annual (Six-Month) Checkout ............................. 61 8 Cascadeable EZ-SCREEN Safety Light Screen ......................62 8.1 Overview of Cascading .................................62 8.2 System Components and Specifications ............................. 62 8.2.1 Cascadeable Emitter and Receiver Models with 14 mm Resolution ..................
  • Page 4 ..................................90 12.9 MSA Series Stands ..................................90 12.10 MSM Series Corner Mirrors ..............................91 12.11 SSM Series Corner Mirrors ............................... 91 12.12 Mounting Brackets ..................................92 12.13 Alignment Aids ..................................93 12.14 EZ-LIGHT ® for EZ-SCREEN ® ..............................93 13 Glossary ..................................95...

  • Page 5: About This Document

    The precautions and statements used throughout this document are indicated by alert symbols and must be followed for the safe use of the EZ-SCREEN 14/30mm Safety Light Screen. Failure to follow all precautions and alerts may result in unsafe use or operation. The following signal words and alert symbols are defined as follows:...

  • Page 6: Standards And Regulations

    2 Standards and Regulations The list of standards below is included as a convenience for users of this Banner device. Inclusion of the standards below does not imply that the device complies specifically with any standard, other than those specified in the Specifications section of this manual.

  • Page 7: International/European Standards

    ® EZ-SCREEN 14/30 mm Safety Light Screen 2.3 International/European Standards EN ISO 12100 Safety of Machinery – General Principles for EN 60204-1 Electrical Equipment of Machines Part 1: Design — Risk Assessment and Risk Reduction General Requirements ISO 13857 Safety Distances . . . Upper and Lower Limbs...

  • Page 8: Introduction

    Note: This manual refers to an emitter, its receiver, and their cabling as "a System". Banner EZ-SCREEN emitters and receivers provide a redundant, microprocessor-controlled, opposed-mode optoelectronic "curtain of light", or "safety light screen". EZ-SCREEN typically is used for point-of-operation safeguarding, and is suited to safeguard a variety of machinery.

  • Page 9: Appropriate Applications And Limitations

    Ensure that all legal requirements have been met and that all technical installation and maintenance instructions contained in this manual are followed. The user has the sole responsibility to ensure that this Banner device is installed and interfaced to the guarded machine by Qualified Persons , in accordance with this manual and applicable safety regulations.

  • Page 10: Examples: Appropriate Applications

    3.4 Control Reliability: Redundancy and Self-Checking Redundancy requires that EZ-SCREEN circuit components be backed up to the extent that, if the failure of a single component will prevent effective machine stopping action when needed, that component must have a redundant counterpart which will perform the same function.
  • Page 11 • External Device Monitoring (EDM) ( • Cascading (available on SLPC.. models) Monitoring on page 40) Cascadeable EZ-SCREEN Safety Light Screen Auxiliary (Aux.) Output • Auxiliary Output ( on page page 62) These functions are configured via DIP switches (behind the access door on the front of each sensor) and/or the sensor wiring configuration.

  • Page 12: Components

    4 Components 4.1 System Components An EZ-SCREEN System includes a compatible emitter and receiver (equal length and resolution; available separately or in pairs), and two cables. Mounting hardware is included with each emitter and receiver. Interfacing solutions include IM-T-.. modules, redundant positively guided contactors, safety modules/controllers, or an optional muting module.

  • Page 13: Standard Emitter And Receiver Models (Non-Cascadeable) With 30 Mm Resolution

    ® EZ-SCREEN 14/30 mm Safety Light Screen Standard 14 mm Resolution Models 0.1 m to 6 m (4 in to 20 ft) range Defined Area Height Response Time Emitter (8-pin) Receiver Emitter/Receiver Pair Number of Beams (Tr) 150 mm (5.9 in)

  • Page 14: Cordsets

    ® EZ-SCREEN 14/30 mm Safety Light Screen Standard 30 mm Resolution Models 0.1 m to 18 m (4 in to 60 ft) range Defined Area Height Emitter (8-pin) Receiver Emitter/Receiver Pair Number of Beams Response Time (Tr) 1500 mm (59 in)

  • Page 15: Double-Ended (Sensor Interconnect) Cordsets

    For 5-pin Emitters and Receivers 5-pin EZ-SCREEN emitter, model numbers SLSE..-..Q5 with Test function. One 5-pin and one 8-pin QD cable required for complete system. The European M12 Specification pin assignment and color codes are listed as a customer courtesy. The user must verify suitability of these cables for each application.

  • Page 16: Splitter Cordsets

    5 = Green/Yellow 4.4.3 Splitter Cordsets Model CSB splitter cordsets allow easy interconnection between an EZ-SCREEN 8-pin receiver and its 8-pin emitter, providing a single “homerun” cable for the optional “swapable” wiring. The model DEE2R-.. double-ended cables may be used to extend the lengths of the QD trunk, branch #1, or branch #2. (Branch #1 and branch #2 cable sections are 300 mm/1 ft long.) The model QDE-8..D single-ended cables may be used to extend the QD trunk for cut-to-length applications.

  • Page 17: Bulkhead Connector

    4 = White 43.0 35 [1.38"] 5 = Black [1.69"] 6 = Blue 7 = Gn/Ye 8 = Violet 4.4.4 Bulkhead Connector Connector for panel connection of EZ-SCREEN component cables. Model Connection Dimensions 21.5 mm ø 18.0 mm (9.8') (0.85") (0.71") 13.0 mm...

  • Page 18: Documentation

    Stainless Steel SMA-MBK-1 SSM Mirror bracket kit. Includes 2 replacement brackets for one mirror. 4.6 Documentation The following documentation is supplied with each EZ-SCREEN receiver. Additional copies are available at no charge. Part Number Description 112852 EZ-SCREEN 14/30mm System Instruction Manual 113361 Checkout Procedure Card (Daily) –...

  • Page 19: Installation Instructions

    The distance is calculated so that when an object or a person is detected (by blocking a sensing beam), the EZ-SCREEN sends a stop signal to the machine, causing it to stop by the time the object or person can reach any machine hazard point.
  • Page 20 ® EZ-SCREEN 14/30 mm Safety Light Screen WARNING: • Calculate the Safety Distance (Minimum Distance) • Failure to establish and maintain the safety distance (minimum distance) could result in serious injury or death. • Mount the components at a distance from the nearest hazard such that an individual cannot reach the hazard before cessation of the hazardous motion or situation.
  • Page 21 (or the hazard removed). This can be broken down into two parts: Ts and Tr where T = Ts + Tr the maximum response time, in seconds, of the EZ-SCREEN emitter/receiver pair (depending on model) the additional distance, in mm, based on intrusion of a hand or object towards the danger zone prior to actuation of a safety device.

  • Page 22: Reducing Or Eliminating Pass-Through Hazards

    This method of safeguarding relies upon the location of the reset switch as well as safe work practices and procedures to prevent an unexpected start or restart of the guarded machine. The EZ-SCREEN 14/30mm Safety Light Screen provides a configurable Manual Start/Restart (Latch Output) function for these applications.

  • Page 23: Reset Switch Location

    ® EZ-SCREEN 14/30 mm Safety Light Screen WARNING: • Perimeter guarding applications • Failure to observe this warning could result in serious injury or death. • Use lockout/tagout procedures per ANSI Z244.1, or use additional safeguarding as described by ANSI B11.19 safety requirements or other applicable standards if a passthrough hazard cannot be eliminated or reduced to an acceptable level of risk.

  • Page 24: Supplemental Safeguarding

    Figure 4. An example of supplemental safeguarding Figure 4 on page 24 shows an example of supplemental safeguarding inside a robotic work cell. The EZ-SCREEN, in conjunction with the hard (fixed) guarding, is the primary safeguard. Supplemental safeguarding (such as a horizontal- mounted safety light screen as an area guard) is required in areas that cannot be viewed from the reset switch (for example, behind the robot and the conveyor).

  • Page 25: Adjacent Reflective Surfaces

    ® EZ-SCREEN 14/30 mm Safety Light Screen Receiver Emitter Receiver Receiver Emitter Emitter Both cable ends down Both cable ends up Orientation parallel to floor with both cable ends pointing in the same direction Figure 5. Examples of Correct Emitter/Receiver Orientation...

  • Page 26: Use Of Corner Mirrors

    5.2.7 Use of Corner Mirrors EZ-SCREEN may be used with one or more corner mirrors. Mirrors are not allowed for applications that would allow undetected personnel access into the safeguarded area. The use of glass-surface corner mirrors reduces the maximum...

  • Page 27: Installation Of Multiple Systems

    5.2.8 Installation of Multiple Systems Whenever two or more EZ-SCREEN emitter and receiver pairs are adjacent to one another, optical crosstalk may take place between the systems. To minimize optical crosstalk, alternate the positions of the emitters and receivers (see Figure 9 page 28), or alternate Scan Codes.
  • Page 28 ® EZ-SCREEN 14/30 mm Safety Light Screen Receiver Receiver Scan Code 1 Emitter Scan Code 1 Emitter Receiver Emitter Scan Code 2 Scan Code 2 Receiver Emitter b. Two or three systems stacked (or alternate receiver/ a. Two systems in a horizontal plane...

  • Page 29: Mounting The Emitter And Receiver

    1050 mm and longer) Side-Mounted (two sensor brackets may be substituted) End-Mounted Note: • EZ-SCREEN sensor brackets are designed to mount directly to MSA Series stands, using the Appropriate Applications and Limitations hardware supplied with the stands (see on page 9) Specifications •...

  • Page 30: Sensor Mounting And Mechanical Alignment

    Emitter and receiver wiring is low voltage; routing the sensor wires alongside power wires, motor/servo wires, or other high voltage wiring may inject noise into the EZ-SCREEN System. It is good wiring practice, and sometimes may be required by code, to isolate emitter and receiver cables from high-voltage wires, avoid routing cables close to “noisy” wiring, and provide a good connection to earth ground.

  • Page 31: Initial Electrical Connections

    5.7.1 Emitter Wiring Options An EZ-SCREEN emitter with an 8-pin connector can be connected either to its own power supply or to the receiver cable, color-for-color. The color-for-color connection allows the emitter and receiver positions to be interchanged without rewiring.

  • Page 32: Initial Checkout Procedure

    2. Eliminate the reflective surfaces as much possible by relocating, painting, masking, or roughening them. Remaining problem reflections will become apparent during the trip test. 3. Verify that power is removed from the EZ-SCREEN System and from the guarded machine and that the OSSD safety outputs are not connected.

  • Page 33: Optical Alignment

    ® EZ-SCREEN 14/30 mm Safety Light Screen • A Blocked Condition (receiver)—The red Status indicator is on, the amber Reset indicator is on, one or more red Zone indicator(s) are on, identifying the location of the blocked beams, and the number of blocked Optical Alignment beams is displayed.

  • Page 34: Optical Alignment Procedure With Mirrors

    5.8.4 Optical Alignment Procedure with Mirrors EZ-SCREEN sensors may be used with one or more corner mirrors for guarding more than one side of an area. The MSM-... and SSM-... rear-surface glass mirrors are rated at 85% efficiency. Thus, excess gain and sensing range are reduced when using mirrors;...

  • Page 35: Reduced Resolution/Floating Blanking

    One or multiple areas within an EZ-SCREEN sensor pair may be blanked out. The minimum number of beams between two blanked areas is one. Any beam other than the sync beam may be blanked. All beams of a fixed blanked area must stay blocked at all times (after the fixed blanking configuration mode has been exited), for the OSSDs to stay ON.

  • Page 36: Trip Test

    5.8.7 Trip Test After optimizing the optical alignment, perform the trip test to verify the detection capability of the EZ-SCREEN System. This test will also verify correct sensor orientation and identify optical short circuits. Once the installation has passed the trip test, the safety outputs may be connected and the commissioning checkout may be performed (initial installations only).
  • Page 37 Mirror Figure 15. Trip Test with Corner Mirror Electrical Connections to the Guarded 6. If the EZ-SCREEN System passes all checks during the trip test, go on to Machine on page 38. www.bannerengineering.com - Tel: + 1 888 373 6767...

  • Page 38: Electrical Connections To The Guarded Machine

    EZ-SCREEN 14/30 mm Safety Light Screen 5.9 Electrical Connections to the Guarded Machine Verify that power has been removed from the EZ-SCREEN and the guarded machine. Make the permanent electrical OSSD Output Connections FSD Interfacing Connections connections as described in...

  • Page 39: Fsd Interfacing Connections

    Depending on the application, the use of FSDs can facilitate controlling voltage and current that differs from the OSSD outputs of the EZ-SCREEN. FSDs can also be used to control an additional number of hazards by creating multiple safety stop circuits.

  • Page 40: Machine Primary Control Elements And Edm Input

    To ensure an accumulation of failures does not compromise the redundant control scheme (cause a failure to danger), a method to verify the normal functioning of MPCEs or other control devices is required. EZ-SCREEN provides a convenient method for this verification: external device monitoring (EDM).

  • Page 41: Auxiliary (Aux.) Output

    Max. For EZ-SCREEN receivers with a date code prior to 0834, the monitoring contacts must open within 200 milliseconds of the OSSD outputs turning ON (a clear condition) and must close within 200 milliseconds of the OSSD outputs turning OFF (a blocked condition) or a lockout will occur.

  • Page 42: Remote Test Input

    5.11 Remote Test Input The 5-pin EZ-SCREEN emitter models (model numbers SLSE..-..Q5) provide a Test function. A pair of wires is connected from the emitter to an external switch, typically a normally open contact, held closed. Opening the switch “turns off” the emitter, simulating an interruption of one or more light beams;...

  • Page 43: Wiring Diagrams

    ® EZ-SCREEN 14/30 mm Safety Light Screen 5.14 Wiring Diagrams 5.14.1 Generic Emitter Wiring Diagram Emitter (Standard) +24 V dc 0 V dc 8-pin male M12 1 - brown 7 - green/yellow 6 - blue 5 - black 4 - white...
  • Page 44 ® EZ-SCREEN 14/30 mm Safety Light Screen +24V dc 0V dc Receiver Bn (Pin #1) +24V dc 8-pin male Euro-style Gn/Ye (#7) Ground face view † Bu (#6) 0V dc Bk (#5) OSSD1 Wh (#4) OSSD2 Vi (#8) Reset* Or (#3)
  • Page 45 Note: DEE8-..D Adapter Cordsets can be used in a similar manner as the QDE-8..D. EZ-SCREEN receiver DIP switches are configured for “Trip” (T) output and 2-channel EDM (E2). If the Auxiliary output is to be used, configure the EZ-SCREEN receiver for 1-channel EDM (E1) and connect pin #3 (Or) to +24 V dc.
  • Page 46 MPCE1 and MPCE2 is IM-T-9A*** recommended (see Warning). ** Trip (auto reset) – Not connected *** Other interfacing modules and solutions available, see Accessories or the Banner Safety Catalog. See Accessories—Cordsets for further † QDE-8..D cable information. MPCE Machine...
  • Page 47 ® EZ-SCREEN 14/30 mm Safety Light Screen +24V dc 0V dc Receiver 8-pin male Bn (Pin #1) Euro-style face view Gn/Ye (#7) Bu (#6) Bk (#5) Wh (#4) Vi (#8) Reset** Or (#3) Aux. out Or/Bk (#2) IM-T-9A*** MPCE Machine...

  • Page 48: Operating Instructions

    Because it has redundant microprocessors, the receiver has two DIP switch banks (bank A and bank B) that must be set identically. Failure to do so will cause a Lockout condition when power is applied. Power to the EZ-SCREEN receiver should be OFF when changing DIP switch settings or a Lockout will occur.

  • Page 49: Access The Configuration Panel

    ® EZ-SCREEN 14/30 mm Safety Light Screen Trip or Latch Output operation is selected on two DIP switches in the receiver configuration port. Set both switches to the same setting. If they have different settings, an error code displays. If the switches are set for Trip Output (T), the System will auto-reset.

  • Page 50: Inverted Display

    A Lockout condition causes the EZ-SCREEN OSSD outputs to turn Off. A Lockout condition is indicated by a flashing red emitter or receiver Status indicator and an error number displayed on the Diagnostic Display. Internal Lockout conditions...

  • Page 51: Resetting The Receiver

    6.3.2 Resetting the Receiver The EZ-SCREEN receiver has a Reset input, pin 8 (Violet wire), that allows the System to be manually reset. The EZ-SCREEN requires a manual reset to clear a Latch condition and resume operation following a stop command.

  • Page 52: Emitter

    ® EZ-SCREEN 14/30 mm Safety Light Screen Receiver: Description Reset indicator (Yellow)—shows System status: • Run mode (ON) • Waiting for a reset (flashing) Status indicator (Red/Green)—shows System status: • Reduced Resolution enabled (flashing green) • Outputs are ON or OFF (green ON or red ON) •...
  • Page 53 ® EZ-SCREEN 14/30 mm Safety Light Screen Trip Output Configured Operating Mode Required Reset Status Indicator Zone Indicators Diagnostic Displays OSSD Event Indicator Outputs Scan code flashes 3 times, alternates Apply Single-Flash All Single-Flash then Power-up power then Pass Zone 1 Red 5...

  • Page 54: Status Indicators For Cascaded Applications

    ® EZ-SCREEN 14/30 mm Safety Light Screen Operating Mode Required Reset Status Indicator Zone Indicators Diagnostic Displays OSSD Event Indicator Outputs Alignment Mode - Align all Double-flash Red All on Green All Beams Clear beams Perform On or Flashing Run Mode - Clear...
  • Page 55 ® EZ-SCREEN 14/30 mm Safety Light Screen Receiver #2, 3, or 4 Condition OSSDs Display Reset Indicator Status Indicator Cleared Green www.bannerengineering.com - Tel: + 1 888 373 6767...
  • Page 56 ® EZ-SCREEN 14/30 mm Safety Light Screen Cascade Powered Up Clear Object is Blocking Light Screen #4 Config: Trip Config: Trip Display: — Display: beams blocked OSSDs: On OSSDs: Off Reset: On Reset: On Status: Green Status: Red Config: Trip Config: Trip Display: —...

  • Page 57: Normal Operation

    6.5.1 System Power-Up The EZ-SCREEN powers up in one of two ways, depending on the trip/latch output configuration. If it is set for trip output, it powers up and resets automatically; if it is set for latch output, it requires a manual reset procedure after the power-up and sensor alignment.
  • Page 58 Note: Verify Proper Operation The EZ-SCREEN can operate as it is designed only if it and the guarded machine are operating properly, both separately and together. It is the user’s responsibility to verify this, on a regular basis, as instructed in Checkout Procedures on page 59.

  • Page 59: Checkout Procedures

    To prepare the System for this checkout: 1. Examine the guarded machine to verify that it is of a type and design compatible with the EZ-SCREEN System. See Examples: Inappropriate Applications on page 10 for a list of misapplications.
  • Page 60 15. Remove the test piece from the beam; verify that the machine does not automatically restart, and that the initiation devices must be engaged to restart the machine. 16. Remove electrical power to the EZ-SCREEN. Both OSSD outputs should immediately turn Off, and the machine must not be capable of starting until power is re-applied to the EZ-SCREEN.

  • Page 61: Shift/Daily Checkout

    Refer to the procedure detailed on the Daily Checkout card (Banner p/n 113361 for SLS.. models, P/N 118173 for SLSC.. models) in the documentation packet included with the receiver. If the Daily Checkout card is missing, contact Banner Engineering or download a copy of the card at http://www.bannerengineering.com...

  • Page 62: Cascadeable Ez-Screen Safety Light Screen

    8.1 Overview of Cascading EZ-SCREEN emitters and receivers are also available in cascadable models. These models can be used as stand-alone light screens, or can be cascaded up to four systems. The cascaded sensor pairs can be any length, any number of beams, or have different resolutions (14 mm and 30 mm), as long as each emitter matches its own receiver.

  • Page 63: Cascadeable Emitter And Receiver Models With 14 Mm Resolution

    ® EZ-SCREEN 14/30 mm Safety Light Screen Available single-ended, double-ended, and splitter cables are listed in Cordsets on page 14. Cable lengths are limited – for Determining Interconnect Cable Lengths both the power cables and the interconnect cables; see on page 65 for more information.

  • Page 64: Receiver Display

    ® EZ-SCREEN 14/30 mm Safety Light Screen Machine interface/power cables (one per end sensor, two per pair): Use QDE-..D cables. Sensor interconnect cables (one per cascaded sensor, two per pair): Use DEE2R-..D cables. Number of Response Time Defined Area Height 12...

  • Page 65: Determining Interconnect Cable Lengths

    ® EZ-SCREEN 14/30 mm Safety Light Screen 8.4 Determining Interconnect Cable Lengths The following cable length charts are possible combinations for each side of example cascaded systems. All cables are assumed to be 22 awg wire. Other lengths and combinations are possible; please call factory for assistance.
  • Page 66 (for example, the front and back of a power press) and uses four EZ-SCREEN pairs to create two “L”-shaped sensing fields. Table 6: Cable length options for four cascaded light screens...

  • Page 67: Response Time For Cascaded Light Screens

    ® EZ-SCREEN 14/30 mm Safety Light Screen Example 1: Emitters Receivers Machine Interface Cable (L1): 15 ft Sensor Interconnect Cable (L2): 1 ft EZ-SCREEN Sensor Interconnect Cable (L3): 75 ft Position #4 Sensor Interconnect Cable (L4): 1 ft Example 2:...

  • Page 68: Individual Response Time And Separation Distance

    Properly install the device • Failure to follow the installation instructions can result in ineffective or non-operation of the Banner device, which could create an unsafe condition resulting in serious injury or death. • Follow all installation instructions. 8.5.1 Individual Response Time and Separation Distance When calculating individual separation distance for each emitter/receiver pair, the pair’s position in the cascade affects its...

  • Page 69: Overall Response Time And Safety (Minimum) Distance

    ® EZ-SCREEN 14/30 mm Safety Light Screen 8.5.2 Overall Response Time and Safety (Minimum) Distance The cascaded system’s Overall Response Time (Tr) is equal to the response time of the individual sensor pair with the most beams (the slowest individual response time), plus an adder resulting from the number of systems in the cascade. Tr can be...

  • Page 70: Cascaded Sensor Configuration Settings

    ® EZ-SCREEN 14/30 mm Safety Light Screen Emitters Emitters Receivers Receivers Emitters Emitters Receivers Receivers Emitters Emitters Receivers Receivers EZ-SCREEN EZ-SCREEN Position #3 Position #3 15 + 2 + 2 = 19 15 + 2 + 2 = 19 Individual Response...

  • Page 71: Configure For Cascaded Operation

    The settings on the first receiver then determine trip or latch mode and 1- or 2-channel EDM/aux. output, and this is the only receiver that requires a reset following a latch condition. One or more areas within any cascaded EZ-SCREEN sensor pair can be blanked out, just as with other EZ-SCREEN light Fixed Blanking screens.

  • Page 72: Emergency Stop Buttons And Rope/Cable Pulls

    8.7 Emergency Stop Buttons and Rope/Cable Pulls Cascadeable EZ-SCREEN receivers may be connected to one or more emergency stop buttons. Connect the button(s) to the end of the last receiver in the cascade, in place of the terminator plug. The connected e-stop button(s) will activate/ deactivate the OSSD outputs in all receivers in the cascade.

  • Page 73: E-Stop Switch Requirements (Positive-Opening)

    The Cascade input may be used to monitor interlock safety gates or guards. Requirements vary widely for the level of control reliability or safety category (per ISO 13849-1) in the application of interlocked guards. While Banner Engineering recommends the highest level of safety in any application, the user is responsible to safely install, operate, and maintain each safety system, and comply with all relevant laws and regulations.

  • Page 74: Interlock Guarding Requirements

    ® EZ-SCREEN 14/30 mm Safety Light Screen 8.8.1 Interlock Guarding Requirements The following general requirements and considerations apply to the installation of interlocked gates and guards for the purpose of safeguarding. Refer to the relevant regulations to be sure to comply with all necessary requirements.

  • Page 75: Monitoring Series-Connected Positive-Opening Safety Switches

    74), a faulty switch will be detected if it fails to switch as the guard opens. In this case, the EZ-SCREEN de-energizes its OSSD output and disables its reset function until the input requirements are met (i.e., the faulty switch is replaced). However, when a series of interlocking safety switches is monitored by the EZ-SCREEN, the failure of one switch in the system may be masked or not detected at all .
  • Page 76 EZ-SCREEN considers the failure to be corrected. With the input requirements apparently satisfied, the EZ-SCREEN allows a reset. This system is no longer redundant and, if the second switch fails, may result in an unsafe condition (i.e., the accumulation of faults results in the loss of the safety function).

  • Page 77: Troubleshooting

    51. A Lockout condition causes all of the EZ-SCREEN OSSD outputs to turn or remain OFF, sending a stop signal to the guarded machine. Each sensor provides diagnostic error codes to assist in the identification of the cause(s) of lockouts (see...

  • Page 78: Advanced Diagnostics

    14/30 mm Safety Light Screen 9.2.2 Advanced Diagnostics In addition to the standard error codes, the EZ-SCREEN can display advanced diagnostic codes for factory troubleshooting and repair functions. These codes are generally not intended for field troubleshooting by the EZ-SCREEN user.
  • Page 79 ® EZ-SCREEN 14/30 mm Safety Light Screen Diagnostic Error Descriptions and Causes Appropriate Action Display EDM 1 Error Verify that the EDM wiring is correct and that the external devices meet the requirements Machine Primary Control Elements and EDM Input described in on page 40.

  • Page 80: Emitter Error Codes

    However, serious electrical and/or optical noise may cause a random Trip. In very extreme electrical noise cases, a Lockout is possible. To minimize the effects of transitory noise, the EZ-SCREEN responds to noise only if the noise is detected on multiple consecutive scans.

  • Page 81: Check For Sources Of Electrical Noise

    All EZ-SCREEN wiring is low voltage; running these wires alongside power wires, motor/servo wires, or other high-voltage wiring can inject noise into the EZ-SCREEN System. It is good wiring practice (and may be required by code) to isolate EZ- SCREEN wires from high-voltage wires.

  • Page 82: Product Support And Maintenance

    10 Product Support and Maintenance 10.1 Cleaning EZ-SCREEN components are constructed of aluminum with a yellow painted finish and are rated IEC IP65. Lens covers are acrylic. Components are best cleaned using mild detergent or window cleaner and a soft cloth. Avoid cleaners containing alcohol, as they may damage the acrylic lens covers.
  • Page 83 WHETHER ARISING IN CONTRACT OR WARRANTY, STATUTE, TORT, STRICT LIABILITY, NEGLIGENCE, OR OTHERWISE. Banner Engineering Corp. reserves the right to change, modify or improve the design of the product without assuming any obligations or liabilities relating to any product previously manufactured by Banner Engineering Corp. Any misuse, abuse, or improper application or installation of this product or use of the product for personal protection applications when the product is identified as not intended for such purposes will void the product warranty.

  • Page 84: Specifications

    ® EZ-SCREEN 14/30 mm Safety Light Screen 11 Specifications 11.1 General Specifications Short Circuit Protection Enclosure All inputs and outputs are protected from short circuits to +24 V dc or Extruded aluminum housing with yellow polyester powder finish dc common...

  • Page 85: Receiver Specifications

    60950). The external voltage supply must be capable of buffering brief (Output Signal Switching Device) safety outputs. (Use optional mains interruptions of 20 ms, as specified in IEC/EN 60204-1. interface modules for ac or larger dc loads.) Capable of the Banner "Safety Handshake". Residual Ripple ON-State voltage: ≥...

  • Page 86: Center Bracket

    ® EZ-SCREEN 14/30 mm Safety Light Screen 11.5 Center Bracket Model EZA-MBK-12: The center bracket is supplied with emitters and receivers over 1050 mm (3.4 ft) and longer. Dimensions are identical for stainless steel model EZA-MBK-12N for ESD model emitters and receivers.
  • Page 87 ® EZ-SCREEN 14/30 mm Safety Light Screen 36.0 mm (1.42") 45.2 mm 12 mm* (1.78") (0.47") 56.0 mm (2.20") 4.2 mm (0.17") R13 mm (0.5") 65 mm minimum bend (2.6") *For SLS..-150 models, this distance is 52 mm (2") Defined Area 20 Y...

  • Page 88: Accessories

    12.5 AC Boxes AC power supply for use with EZ-SCREEN emitters and/or receivers. Models EZAC-R.. can be interfaced with up to three receivers or two cascaded emitter/receiver pairs; models EZAC-E.. can power up to four emitters. Box supplies +24V dc power at 0.7 amps (16.8 W max.

  • Page 89: Remote Reset Switch

    21 Polycarbonate shield guards against weld splatter and weld flash with an adhesive-backed neoprene gasket (see data sheet p/n 61960). 22 Copolyester shield provides heavy-duty, impact-resistant protection from many types of cutting fluids (see data sheet p/n 127944). 23 Contact Banner Engineering for lens shield availability for longer sensor lengths. www.bannerengineering.com - Tel: + 1 888 373 6767...

  • Page 90: Tubular Enclosures

    22 Copolyester shield provides heavy-duty, impact-resistant protection from many types of cutting fluids (see data sheet p/n 127944). 23 Contact Banner Engineering for lens shield availability for longer sensor lengths. 24 Contact Banner Engineering for enclosure availability for longer sensor lengths.

  • Page 91: Msm Series Corner Mirrors

    ® EZ-SCREEN 14/30 mm Safety Light Screen 12.10 MSM Series Corner Mirrors • Compact for light-duty applications • Rear-surface glass mirrors are rated at 85% efficiency. The total sensing range decreases by approximately 8% per mirror. See mirror data sheet p/n 43685 or http://www.bannerengineering.com...

  • Page 92: Mounting Brackets

    1900 mm (74.8 in) 2011 mm (79.2 in) 1978 mm (77.9 in) 12.12 Mounting Brackets Replacement Parts on page 17 for standard brackets. Contact Banner Engineering for more information. Order one EZA-MBK-.. bracket per sensor, two per pair. EZA-MBK-2 EZA-MBK-15 •...

  • Page 93: Alignment Aids

    12.14 EZ-LIGHT for EZ-SCREEN Provides clear, 360° indication of the of the EZ-SCREEN receiver's output status. Use with a CSB splitter cable and optional DEE2R double-ended cables. See data sheet p/n 121901 for more information. www.bannerengineering.com - Tel: + 1 888 373 6767...
  • Page 94 Thermoplastic polyester housing, thermoplastic lens Fully encapsulated IP67 8-pin Euro-style Integral QD Red/Green indication follows OSSD output T30RGX8PQ8 of the EZ-SCREEN receiver ON Red:—Power ON Beam Blocked or Lockout Polycarbonate housing, 30 mm thermoplastic dome, ON Green:—Power ON Beam Clear...

  • Page 95: Glossary

    ® EZ-SCREEN 14/30 mm Safety Light Screen 13 Glossary ANSI (American National Standards Institute) Auto Power-Up Acronym for the American National Standards A safety light screen system feature that enables the Institute, an association of industry representatives system to be powered up into Run mode (or recover...
  • Page 96 Lockout condition are machine primary control element (MPCE) when the permitted; failures which cause an unsafe condition output signal switching device (OSSD) goes to the (a failure to danger) are not. Banner safety products OFF-state. are extensively FMEA tested. Fixed Blanking...
  • Page 97 ® EZ-SCREEN 14/30 mm Safety Light Screen Internal Lockout A Lockout condition that is due to an internal safety system problem. Generally, indicated by the red Status indicator LED (only) flashing. Requires the attention of a Qualified Person. Key Reset (Manual Reset)
  • Page 98 (after the operation) by the operator. PSDI is commonly confused with "Trip Initiate." PSDI is defined in OSHA CFR1910.217. Banner safety light screen systems may not be used as PSDI devices on mechanical power presses, per OSHA regulation 29 CFR 1910.217.
  • Page 99 When inserted into the defined area Banner safety light screen systems and safety and placed in front of a beam, the test piece causes modules are self-checking.
  • Page 100 Index applications Final Switching Device (FSD) 8 suitable 10 suitable applications 10 indicator Emitter Power/Fault 52 initial power-up 32 DIP Switches 10 Trip or Latch Output 10 trip/latch output 50 Machine Primary Control Elements (MPCEs) 8 Emitter Power/Fault indicator 52 External Device Monitoring (EDM) Output Signal Switching Device (OSSD) 8...
