Original Instructions
Enabling switch (left), and
Enabling switch with integral momentary
pushbutton
Model
ED1G-L21SM-1N
2 N.O. + 1 N.C. Aux
ED1G-L21SMB-1N
2 N.O. + 1 N.C. Aux + 1 N.O. Momentary pushbutton
ED1G-L20MB-1N
2 N.O. + 2 N.O. Momentary pushbutton
WARNING: Not a Safeguarding Device
An Enabling Device is not considered a safeguarding device, because it requires an overt action
by an individual to stop machine motion. (A safeguarding device limits or eliminates an individual's ex-
posure to a hazard, without action by the individual or others.)
Because an individual must actuate the device for it to function, these devices do not fit the definition of a
safeguarding device and cannot be substituted for required safeguarding. Refer to the relevant standards
to determine those requirements.
P/N 151822 Rev. B
ED1G Grip-Style Enabling Devices
Three-position switches for enabling and hold-to-run applications
• Three-position functionality (OFF-ON-OFF) as required for man-
ual control of a machine
• Provides safety function when user either squeezes or releases
the handlegrip switch
• Ergonomic design with a detented enable position (position 2)
• Terminal 1-2 and 3-4 contacts will not re-close when released
from fully squeezed (position 3)
• Ideally suited for use as an enabling device for robotic cells
• Optional momentary pushbutton switch (depending on model)
that can provide hold-to-run, reset, or jogging/inching functions
• Built-in strain relief and M20x1.5 conduit connection
• Meets IP65 or IP66, depending on model
•
Insulated device (IEC 60947-5-1) on all models
• Design meets or exceeds:
ANSI RIA R15.06 and ISO 10218 Robot safety standard
ANSI B11.19 Performance Criteria for Safeguards
ANSI NFPA 79 (2007) and IEC 60204-1 (2000) Electrical Re-
quirements for Industrial Machines
Models
Contact Configuration
10/19/2011
Environmental
Additional Switch
—
Momentary pushbutton
Rating
IP66
IP65
0 151822
5
Advertisement
Table of Contents
Related Manuals for Banner ED1G
Summary of Contents for Banner ED1G
- Page 1 ED1G Grip-Style Enabling Devices Three-position switches for enabling and hold-to-run applications • Three-position functionality (OFF-ON-OFF) as required for man- Original Instructions ual control of a machine • Provides safety function when user either squeezes or releases the handlegrip switch • Ergonomic design with a detented enable position (position 2) •...
-
Page 2: International/European Standards
This manual attempts to provide complete installation, opera- tional, and maintenance instruction. Reading the manual completely is highly recommended. Please direct any questions regarding the application or use of the product to a Banner Engineering Applications Engineer at the locations listed in this document. WARNING: User Responsibility The user is responsible for ensuring that all local, state, and national laws, rules, codes, and regulations relating to the use of this product in any particular application are satisfied. - Page 3 In addition, the reset switch operator must have full view of the entire guarded area and verify that the area is clear of individuals during the reset procedure. Models ED1G-L21SM-1N and ED1G-L21SMB-1N Model ED1G-L20MB-1N Figure 1. Contact status when grip switch is operated P/N 151822 Rev.
- Page 4 ED1G Enabling Switch WARNING: Qualified Personnel Only qualified and authorized personnel who have been trained in the use of the device, and hazards as- sociated with the task that requires the use of the device, may be allowed to operate the enabling device and must follow safe work procedures.
-
Page 5: Mechanical Installation
ED1G Enabling Switch Lockout/Tagout In machine maintenance and servicing situations in which the unexpected energization, start up, or release of stored energy could cause injury, OSHA 29CFR1910.147 “The control of hazardous energy (lockout/tagout)” or ANSI 2244.1 “Lockout/Tagout of Energy Sources”... - Page 6 ED1G Enabling Switch • Allow only one actuating control to initiate a machine cycle or function when the enabling device is in use, in order to prevent unex- pected machine function. • Require each selected enabling device to concurrently operate before a machine cycle or function can be initiated.
- Page 7 ED1G Enabling Switch Making the Connections: Accessing the Wiring Chamber To ensure the highest level of reliability, connect both contacts to a monitoring device, such as a safety module. ED1G-L21SM-1N ED1G-L20MB-1N ED1G-L21SMB-1N Figure 2. Terminal assignments (dependent on model) 1. Remove the cover from the switch by loosening the three M4 Phillips-head screws on the back of the housing.
- Page 8 ED1G Enabling Switch Wiring Example; Gate Monitoring and Speed Monitoring Applications See notes following figure. Enabli ng Device #1 Enabli ng Device #2 .. #n +24Vdc ED1G-L21SMB-1N ED1G-L21SM-1N Bypass Mode Select Switch To Machine Control “Bypass Mode” Bypass Indicator 1 3 5 6 4 2...
-
Page 9: Checkout Procedures
ED1G Enabling Switch • The momentary N.O. button on the enabling device initiates the machine function. 4. Additional logic, such as a safe speed / zero speed signal, may be required to ensure that the operator(s) are not exposed to hazards generated from automatic machine operation. -
Page 10: Specifications
Recommended Wire/Cable Size Polyamide housing and cable gland, NBR/PVC poly- Wire: 0.14 to 1.5 mm² (25 AWG to 16 AWG) blend rubber grip switch boot; model ED1G-L21SM Cable: ø 7 to 13 mm -1N meets IP66; other models meet IP65... - Page 11 Resistive load (DC-12) 0.2 A — L21SMB-1N); 5-6 and 7-8 Inductive load (DC-13) 0.7 A 0.1 A — (model ED1G-L20MB-1N) Dimensions All dimensions in mm Model ED1G-L21SM-1N Models ED1G-L21SMB-1N and ED1G-L20MB-1N Momentary Pushbutton P/N 151822 Rev. B www.bannerengineering.com - tel: 763-544-3164...
-
Page 12: Accessory And Replacement Parts
EC Declaration of Conformity Banner Engineering Corp. herewith declares that the ED1G Series Enabling Device is in conformity with the provisions of the Machinery Directive (Directive 2006/42/EC), and all essential Health and Safety Requirements have been met. Download the complete EC Declara- tion of Conformity as a PDF file at www.bannerengineering.com/Enable_Device...
