CONTROLLER LAYOUT

Refer to page 18 for complete listing of buttons and symbols.
Menu Navigation
and Value Increase
(Press and hold to manually
enter Anti-Frost mode.)
Menu Navigation
and Value Decrease
Fans are On

UNIT SPECIFICATIONS

Dimensions
BTU
(85°F condenser air
intake temperature)
Refrigerant
HP
Voltage Rating
Weight (lb.)
Amps (running)
Drain Line
Installation
Thermostat
Temp. Delta
Warranty
* Sizing the Unit to the Room
The specification chart will provide information on the unit's cooling capacity. There are circumstances in which a cellar design may
require a larger unit due to preexisting design restrictions. Certain building materials such as glass, stone, or concrete may seem
adequate but do not offer the insulation capacity required to maintain the optimum temperature for storing wine. We recommend
purchasing a unit with a larger capacity to compensate for these design limitations. Undersized cooling units can lead to premature
failure and/or prevent the system from reaching the desired set temperature. As a result, they are not covered under warranty.
Page 6
Compressor is On
Unit is in Anti-Frost
Mode
2200
17.5"L x 14.25"W x 15.75"H
1453
1/8
115V (15-amp dedicated circuit required)
60
3.2
Advanced digital controller, liquid-temperature-measuring bottle probe
Can maintain a 55°F cellar temperature with up to 85°F condenser air intake temperature
2 years (parts and labor) / 5 years (compressor)
Alarm is present
Temperature Measurement
3300 4400
2049 2253
R-134a
1/6 1/6+
60 60
3.7 4.7
1/2" ID clear plastic tubing
Through the wall
Power On/Off
(hold for approx. 3 seconds)
and Escape
SET (ENTER)
(Press and hold
to enter the
parameter menu.)
* See note on next page
8800
21.64"L x 14.25"W x 22.56"H
4241
1/2
115V (20-amp dedicated
circuit required)
104
10.9
