- Page 1 OPTIMUM SERIES OWNER’S MANUAL Optimum 2200 Optimum 3300 Optimum 4400 Optimum 8800 Tech Support: 1 (800) 343-9463, ext. 801 Hours: Monday through Friday, 7 AM - 4 PM...
- Page 2 CellarCool. Every effort has been made to ensure that the information in this manual is accurate. CellarCool is not responsible for printing or clerical errors.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction ..........2 Before You Start . -
Page 4: Introduction
INTRODUCTION Customer Service Thank you for purchasing a CellarCool cooling system. We strive to provide the highest-quality products and the best possible customer service. If you have any questions about your system, please call us at 1-800-343-9463 or visit cellarcool.com. -
Page 5: Before You Start
4. For your convenience, the CellarCool unit has two power inlets: one on the side of the unit, and the other on the back. Use the selector switch, located on the right side of the unit, to select the inlet you would like to use. -
Page 6: Receiving & Inspecting The Unit
NOTE: CellarCool units are manufactured in the USA and tested prior to shipment. Please leave the CellarCool unit in its original box until you are ready for installation. If the unit is to be stored for any length of time prior to installation, ensure that the unit is stored on a flat level surface in the upright position. -
Page 7: Quick Reference Guide
OPTIMUM SERIES QUICK REFERENCE GUIDE Front / Side View Controller Probe Input Control panel Bottle probe (see page 10 for details) Rear / Side View Air sensor Drain port www.cellarcool.com | Page 5... -
Page 8: Controller Layout
CONTROLLER LAYOUT Refer to page 18 for complete listing of buttons and symbols. Menu Navigation and Value Increase Power On/Off (Press and hold to manually (hold for approx. 3 seconds) enter Anti-Frost mode.) and Escape Menu Navigation SET (ENTER) and Value Decrease (Press and hold to enter the parameter menu.) -
Page 9: Preparing The Wine Cellar
Insulation Insulation is REQUIRED in order to properly use CellarCool products. It is vital that all walls and ceilings be insulated to keep the cellar temperature as consistent as possible during the summer and winter months. Standard fiberglass or rigid foam insulation is normally used in cellar construction;... - Page 10 If the cellar door does not seal properly, the unit will run continuously. In cases where glass doors are used and the room size is close to the recommended unit size, the next larger size CellarCool should be used. This will compensate for the insulation loss due to the lower insulation rating of glass.
- Page 11 In some cases, it may be advisable to install a vent fan to dissipate heat from within the exhaust area. However, you must have a fresh air inlet as well. If your unit requires ducting, please contact CellarCool to obtain a specially designed ducting plenum for the unit.
-
Page 12: Testing The Unit Prior To Installation
PREPARING THE INSTALLATION LOCATION The CellarCool 2000, 3000, and 4000 unit requires a dedicated 115-volt, 15-amp circuit. The 8000 unit requires a dedicated 115-volt, 20-amp circuit. The unit draws a large amount of amps during its initial startup. By designating a dedicated circuit breaker, you will guarantee the unit has enough power to run effectively. -
Page 13: Preparing The Installation Location
Make sure that the internal height remains at 16 inches (2200/3300/4400) or 22.75 inches (8800) so that the CellarCool unit will fit snugly through the framed cut-out. -
Page 14: Preparing The Unit For Installation
PREPARING THE UNIT FOR INSTALLATION Single-Piece Mounting Bracket The SC Series utilizes a single-piece mounting bracket. This sturdy bracket frames the installation location and secures the unit to the wall. Applying Insulation Tape Locate the six-foot piece of black foam tape included with the unit. -
Page 15: Installing The Unit Through The Wall
Use the six 1/2" pan-head screws to fasten the bracket to the unit. Under no circumstances should you use screws longer than 1/2” in length. Mounting flange 2x4 upper support Wall stud 2x4 lower support Rear power Rear of Unit Drain port www.cellarcool.com | Page 13... -
Page 16: Condensation Drain Line
DRAIN LINE Condensation Drain Line Tube All units come equipped with a drain line for additional removal of excess condensate. This is a backup system to the condensate evaporator. It is mandatory to install the drain line attachment. The condensate evaporator will heat and dissipate the excess moisture through the rear of the unit. -
Page 17: Liquid Measuring Thermostat System
OPTIMUM SERIES LIQUID-MEASURING THERMOSTAT SYSTEM (BOTTLE PROBE) CellarCool cooling units come with a liquid-temperature-measuring thermostat. The self-calibrating bottle probe contains a sensor chip, which communicates back and forth with the thermostat. This results in a consistent temperature setting and accuracy. Wine should be kept at a very precise, controlled temperature and humidity. By measuring the liquid temperature rather than air, the unit will operate 75–80% of the time. -
Page 18: System Operation
40°F (defrost end temperature). If the Setpoint evaporator is above 40°F, the display will blink three times and The setpoint is preset at the factory (CellarCool) to 55°F. It continue normal operation. can be adjusted by the customer between 50°F and 70°F (in 1°F increments). -
Page 19: Functions
ALARM The alarm symbol is shown and an audible buzzer will sound when the unit encounters an issue that needs attention. The displayed alarm codes are explained on the next page. To silence the buzzer, press any button. The alarm code will remain displayed until corrected. www.cellarcool.com | Page 17... -
Page 20: Alarm Codes
Management/ back into the cellar. (The CellarCool unit, however, cannot increase the humidity of the cellar.) This parameter Enhancement should not be adjusted below 1. Adjustments should be made in increments of 5, with a maximum of 15 and a minimum of 1. -
Page 21: Optimum 2200 & 3300
OPTIMUM SERIES OPTIMUM 2200 & 3300 CONTROLLER WIRING SCHEMATIC OPTIMUM 2200 & 3300 www.cellarcool.com | Page 19... -
Page 22: Optimum 4400
OPTIMUM 4400 CONTROLLER WIRING SCHEMATIC OPTIMUM 4400 011420 Page 20... -
Page 23: Optimum 8800
Wiring Diagram BLACK BLACK BLACK WHITE WHITE SNAP DISK POWER SUPPLY 115 VAC-60 Hz, 20A HEATING POWER CORD ELEMENT REAR FRONT 133mm 133mm WHITE Compressor Blower Blower BROWN BROWN BLUE GREY GREY GREEN EVAPORATOR CONDENSER Capacitor Capacitor www.cellarcool.com | Page 21... - Page 24 NOTES 011420 Page 22...
-
Page 25: Troubleshooting Guide
If so, call Customer Service at 1-800-343-9463. System runs constantly Possible cause Solution Leaky door seal or poorly insulated cellar Fix leaky door seal and insulate cellar in accordance with this manual (page 8) www.cellarcool.com | Page 23... - Page 26 TROUBLESHOOTING GUIDE Unit leaks water Possible cause Solution Unit is not level Unit should be level in wall to prevent leaking Drain line clogged or kinked Check drain line to make sure water can flow freely Drain is clogged, preventing water from escaping 1.
-
Page 27: Maintenance Schedule
Use a vacuum with brush attachment to clean coils; be careful not to crush coil fins when cleaning Annually 1. Inspect for corrosion 2. Check wiring connections and integrity of cords 3. Pour a 50/50 bleach solution into the drain line every spring www.cellarcool.com | Page 25... -
Page 28: Technical Assistance & Accessories
TECHNICAL ASSISTANCE CellarCool Customer Service is available Monday through Friday from 6:00 a.m. to 4:00 p.m. Pacific Standard Time. The appointed customer service representative will be able to assist you with your questions and warranty information more effectively if you provide them with the following: •... -
Page 29: Installation Terms & Conditions
A. Two (2) Year Limited Warranty. For the period of TWO (2) YEARS (the “Limited Warranty Period”) from the date of original sale of a Product by CellarCool, if a CellarCool Product is found to be defective in material or workmanship after undergoing CellarCool’s customer service troubleshooting, then, subject to the CellarCool... - Page 30 15. No one has any authority to add to or vary the limited warranty on this Product. 3. Product Installation Requirements: A. Prior to installing a CellarCool Product, the End User must read the CellarCool Owner’s Manual and thereafter the End User must follow the required installation, use and maintenance procedures set forth by CellarCool in CellarCool’s Owner’s Manual.
- Page 31 D. End User is responsible for all costs incurred for the installation and/or removal of the Product, or any part thereof, unless such cost has been agreed by CellarCool to be a warranty repair prior to the work being performed.
- Page 32 Web: www.cellarcool.com B. Technical Assistance. CellarCool Customer Service is available Monday through Friday from 6:30 a.m. to 4:00 p.m. PST. The Customer Service representative will be able to assist you with your questions and warranty information more effectively if you provide them with the following: 1.
- Page 33 CellarCool 1738 E. Alpine Ave. Stockton, CA 95205 1(800) 343-9463 www.cellarcool.com...
