Module: 5 digital inputs, 2 relay outputs,
modbus communication on RS485/USB
E
E
Headquarters: Via Austria, 26 – 35127 – PADOVA – ITALY
Phone +39.049.8705355 - 8705359 - Fax +39.049.8706287
This document is property of SENECA rl. Duplication and reproduction are forbidden, if not authorized.
Contents of the present documentation refers to products and technologies described in it.
This informations may be modified or integrated for technical and / or commercial requirements.
MI004950-E
INSTALLATION MANUAL
Z-5DI-2DO
Manuals and configuration software are available at website:
www.seneca.it/products/
S
THE ORIGINAL VERSION IS IN ITALIAN LANGUAGE
SENECA s.r.l.
z-5di-2do
ENGLISH - 1/8
Advertisement
Table of Contents
Related Manuals for Seneca Z-5DI-2DO
Summary of Contents for Seneca Z-5DI-2DO
- Page 1 This document is property of SENECA rl. Duplication and reproduction are forbidden, if not authorized. Contents of the present documentation refers to products and technologies described in it. This informations may be modified or integrated for technical and / or commercial requirements.
-
Page 2: General Specifications
Module can be fitted on and removed from bus without interrupting communication or power supply to the system. MODULE LAYOUT 17,5 mm 11 12 1 2 3 4 5 6 FAIL Z-5DI-2DO 7 8 9 10 11 12 Dimension (L×H×W) 17,5 x 102,5 x 111 mm Weight 140 g. Material PA6, Black color. -
Page 3: Technical Specification
LEDS SIGNALS State Meaning of the LEDS Power supply present (Green) Blinking The device in powered off FAIL Blinking Settings error (Yellow) Faul/Failure Blinking Data from RS485 received (Red) Check the connection. Blinking Data to RS485 received (Red) Check the connection TECHNICAL SPECIFICATION EN61000-6-4 Electromagnetic emission, industrial environment STANDARDS... -
Page 4: Technical Specifications
The module may only be used by qualified and skilled technicians in the field of electric installation. Specific documentation is available for download at website: www.seneca.it/products/z-8ntc. Only the Manufacturer is authorized to repair the module or to replace damaged parts. -
Page 5: Installation Rules
MODBUS CONNECTION STANDARDS 1) Install the modules on the IEC EN 60715 rail. 2) Connect the remote modules using cables of proper length. On the table the following data about the cables length are provided: -Bus Length: Modbus network maximum length as a function of the Baud rate. It is the length of the cables which connect the two bus terminators modules (see Scheme 1). -
Page 6: Electrical Connections
USE OF Z-PC-DINAL ACCESSORY Don’t turn upside down the module and don’t force the insertion f the IDC10 connector into Z-PC-DIN bus. The IDC10 connector located on the rear of the module will be inserted on a free slot of Z-PC-DIN accessory. In the figure you can see the meaning of the various pins of the rear IDC10 connector if you want to provide the signals directly through this connector. -
Page 7: Electrical Connection
Detailed information about the list of MODBUS registers and their functions can be found within USER MANUAL CONFIGURATIONS EASY SETUP configuration software, allows the parameter setting. This software is available for free on the Internet site: www.seneca.com. Some parameters can also be set using DIP-switches. MI004950-E ENGLISH - 7/8... -
Page 8: Factory Settings
38400 8,N,1 Addr. 1 For any variation of the parameters are available in the download area of the website: www.seneca.it Z-NET and EASY-Z-PC communication software. For more information about the list of registers and their functions, see the USER manual.
