EMC Disk Library DL4106 Setup And Cabling Manual page 7

The following DL4106 Disk Library components are rackmounted and cabled in the
EMC-supplied 40U-60 cabinet(s):
One CX3-80 storage processor enclosure (SPE) with:
Two storage processors (SPs) each with two I/O modules
Two management modules
Two power supplies
Four blower modules
Two standby power supplies (SPSs)
Power supply A
Blower modules
Front
A B C
One 4-gigabit disk-array enclosure (DAE3P) with six Fibre Channel (FC) boot
disk drives and one FC hot spare disk drive
Power/cooling module B
B
A
Power/cooling module A
Step 3
Verify the parts
Power supply B
I/O module 0, SP A
Management
module B
D
Link control card B
EXP PRI
#
PRI EXP
Link control card A
I/O module 0, SP B
!
!
!
SPS B
Fault LED
(amber)
Disk activity
LED (green)
5
I/O module 1, SP B
I/O module 1, SP A
Rear
!
Management
module A
!
!
Filler
panel
SPS A
EMC3432
Power LED
(green)
Fault LED
(amber)
EMC3437
