Safety Instructions & Operators Manual
®
Zero Turn Radius Mower
SR-125
Congratulations for buying a Country Clipper product. Your Country Clipper Zero Turning Radius
Riding Mower was designed and built to provide long and trouble free service. Keep in mind that it, like
any other mechanical device, can be potentially dangerous if used improperly, and hazard control and
accident prevention are dependent upon the awareness, concern, prudence, and proper training of
personnel involved in the operation, transport, maintenance, and storage of the equipment. Study this
manual and pay special attention to the important Safety Precautions on pages 3-5. Following these
instructions will help you continue to enjoy the trouble-free performance expected of the Country Clipper
product.
P-12733# (03/11)
Advertisement
Table of Contents
Related Manuals for Country Clipper WRANGLER SR-125
Summary of Contents for Country Clipper WRANGLER SR-125
- Page 1 Study this manual and pay special attention to the important Safety Precautions on pages 3-5. Following these instructions will help you continue to enjoy the trouble-free performance expected of the Country Clipper product.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY ............................3 ACCIDENT PATTERNS TO AVOID ....................... 3 SAFETY INSTRUCTIONS AND RECOMMENDATIONS ................3 SAFETY INTERLOCK SYSTEM ........................5 START UP AND OPERATION ....................6 CHECKLIST BEFORE OPERATION ......................6 CONTROL LOCATIONS ..........................6 OPERATION ............................... 7 MOWING RECOMMENDATIONS ......................... -
Page 3: Safety
PEOPLE WHO OPERATE, SERVICE, CONTACT WITH THE ROTATING OR ARE OTHERWISE ASSOCIATED BLADE -- This accident usually with the Country Clipper Zero Turning happens when the operator is clearing Radius Mower should be trained in its the discharge chute of grass, (especially proper use and warned of its dangers. - Page 4 DO NOT MOVE CONTROL LEVER(S) several minutes after running. Always from forward position to reverse position make sure the gas cap is in place. rapidly. The speed and/or direction of travel is affected instantly by movement NEVER CARRY PASSENGERS. of the Control Lever(s). DO NOT SMOKE AROUND THE DO NOT ALLOW CHILDREN TO MOWER or the gasoline storage...
-
Page 5: Safety Interlock System
BLADE CLUTCH when transporting. SAFETY INTERLOCK SYSTEM KEEP ALL SAFETY LABELS IN LEGIBLE CONDITION. Remove Your Country Clipper Zero Turning Radius grease, dirt, grass, etc. that may cover Mower is equipped with switches interlocked for safety labels. Replace any safety label your safety. -
Page 6: Start Up And Operation
IMPORTANT: Before cutting grass, clutch must be broken-in as follows: With engine at START UP AND OPERATION full RPM engage deck until blades come to full speed and then disengage until CHECKLIST BEFORE OPERATION blades come to a complete stop. Repeat 10 times to “break-in”... -
Page 7: Operation
Blade Clutch Switch to the “ON” IMPORTANT: Until the operator is familiar with position. The engine will not start if the the Country Clipper Zero Turning blade clutch is engaged. If the operator is Radius Mower, he/she should follow... -
Page 8: Mowing Recommendations
TO STOP: NOTE: The tractor should never be pulled at Move Joystick Control Lever to neutral more than 2 miles per hour or for any position and then to the “DOWN” appreciable distance. position. Disengage the mower blade clutch by moving the clutch to the “OFF”... -
Page 9: Maintenance
MAINTENANCE CAUTION BEFORE PERFORMING ANY MAINTENANCE, TURN OFF ENGINE REMOVE KEY AND DISCONNECT SPARK PLUGS. USE EXTREME CARE WHEN WORKING ON MACHINERY. DO NOT WEAR WATCHES OR JEWELRY. DO NOT WEAR LOOSE FITTING CLOTHES, AND OBSERVE ALL COMMON SAFETY PRACTICES WITH TOOLS. MAINTENANCE SCHEDULE SERVICE WHEN... -
Page 10: Maintenance Instructions
Model Front tires Rear tires included in your Country Clipper Zero 12 psi 12 psi Turning Radius Mower information Models packet. Lug nuts should be torqued to 75 ft/lbs NOTE: Air intake screen must be kept and checked regularly for tightness. - Page 11 All belts should be checked every 50 With the engine running, if the machine hours. Replace any belts found to be in travels in either direction when the poor condition. All belts are equipped Joystick Control Lever is in the neutral with spring loaded belt tighteners and do “DOWN”...
- Page 12 NOTE: Use 2 wrenches (one on the Rod End Ball Joint and one on the locknut) when tightening locknuts to prevent Locknut damage to Rod End Ball Joints. Upper Rod End K. Shut off engine before removing from Ball Joint Adjusting Coupler blocks.
- Page 13 10. JOYSTICK CONTROL LEVER DETENT E. Readjust neutral according to previously ADJUSTMENT: outlined procedures. If the Joystick Control Lever does not F. Test drive unit and repeat procedure as lock in the “UP” position, turn the detent required. adjustment screw clockwise until a desirable locking action is obtained.
-
Page 14: Leveling The Deck
Within 1/8” of each other. (NOTE: To simplify this measuring, an optional Blade Measuring tool, part Number 629-374A is available from your local “Country Clipper” Dealer) 5. If adjustment is necessary slightly loosen the locknuts that secure the Deck Hanger mounting bolt. -
Page 15: Procedure For Raising And Lowering The Deck For Servicing
PROCEDURE FOR RAISING AND LOWERING THE DECK FOR SERVICING (see next page for illustrations) 2. LOWERING THE DECK: 1. RAISING THE DECK: A. While firmly holding the Deck Lift Handle push the bottom (back) of the deck A. Push Height Adjustment Foot Pedal towards the rear of the tractor. - Page 16 MOWER SHOWN IN OPERATION POSITION. Height Latch Handle Latch Plate / Retaining Notch Height Adjust Pin Remove Height Adjust Foot Pedal Deck Lift Handle Front Caster Wheels Pointed away from Deck Rear Deck Hanger Drag Bar Rotate “over-center” to release Belt Tension Lever Pull BACK to release MOWER SHOWN IN SERVICING...
-
Page 17: Trouble Shooting Check List
TROUBLE SHOOTING CHECK LIST ENGINE WON’T TURN OVER: Mower blades engaged ------------------------------------------------- disengage blades Drive not in neutral ----------------- move Joystick Control Lever to neutral position Blown fuse ------------------------------------------------------------------------ replace fuse Dead battery --------------------------------------------------------------- charge or replace Solenoid ------------------------------------------------------------------------- consult dealer Ignition switch ------------------------------------------------------------------ consult dealer Starter ---------------------------------------------------------------------------- consult dealer ENGINE WILL TURN OVER BUT WON’T START:... - Page 18 Incorrect Ignition Timing ---------------------------------------------------- consult dealer Carburetor maladjusted ----------------------------------------------- readjust carburetor Faulty spark plugs -------------------------------------------------------- check spark plug condition and reset gap* Bouncing off seat safety switch -------------------------- slow down on rough terrain ENGINE OVER HEATED: Air intake screen or fins clogged ------------------------ clean intake screen and fins Fuel mixture too lean ------------------------------------------------- readjust carburetor* Oil level too low or too high ------------------------------------------------ adjust oil level Improper ignition timing ----------------------------------------------------- consult dealer...
-
Page 19: Belt Routings
BELT ROUTINGS Hydrostatic Transmission Drive Belt (Viewed from ground looking up) Left Hand Hydrostatic Right Hand Hydrostatic Transmission Pulley Transmission Pulley Belt P/N D-3524 Motor Pulley 41” DECK BELT P/N D--3796 "V" IDLER... -
Page 21: Notes / Service Records
NOTES / SERVICE RECORDS: DATE SERVICE WORK COMPLETED... - Page 22 WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. Country Clipper Division Shivvers Manufacturing Inc. 613 W. English St. Corydon, IA 50060-0467 Ph. 641-872-2544 Fax. 641-872-1593...
