Safety Instructions & Operators Manual
®
Zero Turn Radius Mower
™
™
Congratulations for buying a Country Clipper product. Your Country Clipper Zero Turning Radius
Riding Mower was designed and built to provide long and trouble free service. Keep in mind that it, like
any other mechanical device, can be potentially dangerous if used improperly, and hazard control and
accident prevention are dependent upon the awareness, concern, prudence, and proper training of
personnel involved in the operation, transport, maintenance, and storage of the equipment. Study this
manual and pay special attention to the important Safety Precautions on pages 4-6. Following these
instructions will help you continue to enjoy the trouble-free performance expected of the Country Clipper
product.
P-12485 (8/08)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the jazee SR210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Country Clipper jazee SR210

Summary of Contents for Country Clipper jazee SR210

  • Page 1 Study this manual and pay special attention to the important Safety Precautions on pages 4-6. Following these instructions will help you continue to enjoy the trouble-free performance expected of the Country Clipper product.

  • Page 2: Table Of Contents

    Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu TABLE OF CONTENTS SAFETY ............................3 ACCIDENT PATTERNS TO AVOID .......................3 SAFETY INSTRUCTIONS AND RECOMMENDATIONS ................3 SAFETY INTERLOCK SYSTEM ........................5 START UP AND OPERATION ....................6 CHECKLIST BEFORE OPERATION ......................6 CONTROL LOCATIONS JOYSTICK MODELS...................6 OPERATION JOYSTICK MODELS.......................7...

  • Page 3: Safety

    BLADE -- This accident usually happens OR ARE OTHERWISE ASSOCIATED when the operator is clearing the with the Country Clipper Zero Turning discharge chute of grass, (especially Radius Mower should be trained in its when the grass is wet), or when the proper use and warned of its dangers.
  • Page 4 Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu DO NOT MOVE CONTROL LEVER(S) several minutes after running. Always from forward position to reverse position make sure the gas cap is in place. rapidly.

  • Page 5: Safety Interlock System

    SAFETY INTERLOCK SYSTEM KEEP ALL SAFETY LABELS IN LEGIBLE CONDITION. Remove grease, dirt, grass, etc. that may cover Your Country Clipper Zero Turning Radius safety labels. Replace any safety label Mower is equipped with switches interlocked for that is missing or damaged.

  • Page 6: Start Up And Operation

    Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu IMPORTANT: Before cutting grass, clutch must START UP AND OPERATION be broken-in as follows: With engine at full RPM engage deck until blades come CHECKLIST BEFORE OPERATION to full speed and then disengage until blades come to a complete stop.

  • Page 7: Operation Joystick Models

    Height Stop Pin. NOTE: Pushing on the Cut Height Foot Assist Lever will make IMPORTANT: Until the operator is familiar with the Cut Height Adjustment Lever easier the Country Clipper Zero Turning to operate. Radius Mower, he/she should follow these recommendations: Disengage the 12.

  • Page 8: Control Locations Twinstick Models

    Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu Cut Height Adjustment Lever Cut Height Foot Left Hand Steering Assist Lever Control Lever CAUTION AVOID HILL AND SLOPES. USE EXTREME CAUTION WHEN MOWING UP OR DOWN SLOPES.
  • Page 9 Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu NOTE: When mowing, always run engine at left to clear top cut height latch. Lower Cut full throttle. Height Adjustment Lever until it rests on Cut Height Stop Pin.

  • Page 10: Mowing Recommendations

    Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu TO FREE WHEEL MACHINE: UNLOCK MOWING RECOMMENDATIONS TRANSMISSION: Pull the Transmission Release Chains out away from the Keep mower blades sharp. Hydrostatic Drive Axle and then down into the retaining slot (each side must Make sure deck and discharge are individually be pulled out and down into...

  • Page 11: Maintenance

    Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu MAINTENANCE CAUTION BEFORE PERFORMING ANY MAINTENANCE, TURN OFF ENGINE REMOVE KEY AND DISCONNECT SPARK PLUGS. USE EXTREME CARE WHEN WORKING ON MACHINERY. DO NOT WEAR WATCHES OR JEWELRY. DO NOT WEAR LOOSE FITTING CLOTHES, AND OBSERVE ALL COMMON SAFETY PRACTICES WITH TOOLS.

  • Page 12: Maintenance Instructions

    Model Front tires Rear tires included in your Country Clipper Zero 12 psi 12 psi Turning Radius Mower information Models packet. Lug nuts should be torqued to 75 ft/lbs NOTE: Air intake screen must be kept and checked regularly for tightness.
  • Page 13 Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu V-BELTS: A. Move Parking Brake Lever to the “OFF” All belts should be checked every 50 position. hours. Replace any belts found to be in B.
  • Page 14 Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu JOYSTICK CONTROL LEVER JOYSTICK CONTROL LEVER NEUTRAL ADJUSTMENT: SENSITIVITY ADJUSTMENT To change the sideways turning With the engine running, if the machine response adjust as follows: travels in either direction when the Joystick Control Lever is in the neutral A.
  • Page 15 Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu D. Loosen the locknuts tightened against JOYSTICK CONTROL LEVER the rod end ball joints in the Upper DETENT ADJUSTMENT: Linkage Assembly. (Note: One of these is a left hand nut and will have to be If the Joystick Control Lever does not turned backwards.)
  • Page 16 Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu Setscrew to Upper Linkage Assembly Access Hole to Access Hole to adjust forward Control Lever Control Lever tracking “Forward” Stop “Outward” Stop Loosen Nut Control Lever HYDROSTATIC TRANSMISSIONS: “Reverse”...

  • Page 17: Procedure For Raising And Lowering The Deck For Servicing

    C. It may be necessary to repeat Steps 1 Use Part # H-2256 when reordering from and 2 until all air is completely purged Country Clipper. When tightening filter from the system. When the transaxle insure proper torque value 20-50 in-lbs moves forward and reverse at normal is applied.
  • Page 18 Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu C. On the right side of the mower, lift and A. Push the bottom (back) of the deck hold up on the hook keeper. Lift up on towards the rear of the tractor.

  • Page 19: Leveling The Deck

    4. Measure from the ground to the front blade tip of each outside blade. These measurements should be Within 1/8” of each other. (NOTE: To simplify this measuring, an optional Blade Measuring tool, part Number 629-374A is available from your local “Country Clipper” Dealer) Deck hanger bolt Part # F-1936 1/2"...

  • Page 20: Adjusting The Latch Plate

    Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu 6. Once the side to side cut height is within tolerance, measure from the ground to the blade tip At the rear of each outside blade. This measurement should be between 1/8” and ¼” higher from the ground than the front of the blade from the ground on the corresponding side of the deck.

  • Page 21: Trouble Shooting Check List

    Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu TROUBLE SHOOTING CHECK LIST ENGINE WON’T TURN OVER: Mower blades engaged ------------------------------------------------- disengage blades Drive not in neutral ------------------------ move Control Lever(s) to neutral position Blown fuse ------------------------------------------------------------------------ replace fuse Dead battery --------------------------------------------------------------- charge or replace Solenoid ------------------------------------------------------------------------- consult dealer...
  • Page 22 Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu ENGINE SOMETIMES SKIPS AT HIGHER SPEEDS: Incorrect Ignition Timing ---------------------------------------------------- consult dealer Carburetor maladjusted ----------------------------------------------- readjust carburetor Faulty spark plugs -------------------------------------------------------- check spark plug condition and reset gap* Bouncing off seat safety switch -------------------------- slow down on rough terrain ENGINE OVER HEATED:...

  • Page 23: Belt Routings

    Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu BELT ROUTINGS Hydrostatic Transmission Drive Belt (Viewed from ground looking up) Left Hand Hydrostatic Right Hand Hydrostatic Transmission Pulley Transmission Pulley Belt P/N D-3524 Motor Pulley "V"...

  • Page 24: Wiring Schematic For Briggs Joystick (E-6405)

    Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu WIRING SCHEMATIC FOR BRIGGS JOYSTICK (E-6405)

  • Page 25: Wiring Schematic For Kohler Joystick (E-6415)

    Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu WIRING SCHEMATIC FOR KOHLER JOYSTICK (E-6415)

  • Page 26: Wiring Schematic For Briggs Joystick (E-6415 Plus E-6417 Adapter)

    Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu WIRING SCHEMATIC FOR KAWASAKI JOYSTICK (E-6415) (PLUS E-6417 ADAPTER)

  • Page 27: Wiring Schematic For Kohler Twinstick (E-6416)

    Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu WIRING SCHEMATIC FOR KOHLER TWINSTICK (E-6416)

  • Page 28: Wiring Schematic For Kawasaki Twinstick (E-6416 Plus E-6417 Adap)

    Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu WIRING SCHEMATIC FOR KAWASAKI TWINSTICK (E-6416) PLUS (E-6417) ADAPTER...

  • Page 29: Wiring Schematic For Briggs Twinstick (E-6416 Plus E-6436 Adapter)

    Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu WIRING SCHEMATIC FOR BRIGGS TWINSTICK (E-6416) PLUS (E-6436) ADAPTER...

  • Page 30: Notes / Service Records

    Return to Main Menu Return to Main Menu Return to Manuals Menu Return to Manuals Menu NOTES / SERVICE RECORDS: DATE SERVICE WORK COMPLETED...
  • Page 31 WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. Country Clipper Division Shivvers Manufacturing Inc. 613 W. English St. Corydon, IA 50060-0467 Ph. 641-872-2544 Fax. 641-872-1593...
