  • Page 1 DDW-142/242-12VDC-BP Industrial Ethernet Extender...
  • Page 2 6642-22541...

  • Page 3: General Information

    Under no circumstances shall Westermo be responsible for any loss of data or income or any special, incidental, and consequential or indirect damages howsoever caused.

  • Page 4: Product Disposal

    If the product is used in a manner not according to specification, the protection provided by the equipment may be impaired. If the product is not working properly, contact the place of purchase, nearest Westermo distributor office or Westermo technical support.

  • Page 5: Warning Levels

    During installation, ensure a protective earthing conductor is first connected to the protective earthing terminal (only valid for metallic housings). Westermo recommends a cross-sectional area of at least 4 mm2. If the product does not have a protective earthing terminal, then the DIN-rail must be connected to protective earth.
  • Page 6 The power supply wiring must be sufficiently fused. It must be possible to disconnect manually from the power supply. Ensure compliance to national installation regulations. Replacing the internal fuse must only be performed by Westermo qualified personell. Warning - Reduce the risk of fire To reduce the risk of fire, use only telecommunication line cords with a cable diameter of AWG 26 or larger.

  • Page 7: Simplified Eu Declaration Of Conformity

    Simplified EU declaration of conformity Hereby, Westermo declares that the equipment is in compliance with EU directives. The full EU declaration of conformity and other detailed information are available at available www.westermo.com/support/product-support. Agency approvals and standards compliance Type Approval / Compliance...

  • Page 8: Type Tests And Environmental Conditions

    Type tests and environmental conditions Electromagnetic Compatibility Environmental Basic Description Test levels phenomena standard EN 61000-4-2 Enclosure contact ± 6 kV Enclosure air ± 8 kV Fast transients EN 61000-4-4 Power port ± 2 kV Ethernet ports ± 2 kV SHDSL ports ±...
  • Page 9 Environmental Temperature EN 60068-2-1 Operating -40 to +74°C (-40 to +165°F) EN 60068-2-2 Storage & Transport -40 to +85ºC (-40 to +185ºF) Humidity EN 60068-2-30 Operating 5 to 95% relative humidity Storage & Transport 5 to 95% relative humidity Altitude Operating 2 000 m / 70 kPa Service life...

  • Page 10: Functional Description

    Description Functional description The Wolverine DDW-142/242-12VDC-BP with bypass relay allows effective Ethernet networks to be created over long distances up to 15 km (9.3 mi) at data rates up to 15.3 Mbit/s on a single twisted pair cable. By using two pairs “bonded” this rate can be doubled up to 30.6 Mbit/s.

  • Page 11: Interface Specifications

    Interface specifications Power Rated voltage 12 to 48 VDC Operating voltage 9.8 to 60 VDC Rated current 475 mA (765 mA) @ 12 VDC (with 500 mA USB load)* 245 mA (405 mA) @ 24 VDC (with 500 mA USB load) 124 mA (200 mA) @ 48 VDC (with 500 mA USB load) Rated frequency Inrush current, I²t...
  • Page 12 Data format 8 data bits, none parity, 1 stop bit, no flow control Circuit type SELV Connection 2.5 mm jack, use Westermo cable 1211-2027 Electrical specification USB 2.0 host interface Data rate Up to 12 Mbit/s (full-speed mode) Circuit type...
  • Page 13 I/O / Relay output Maximum voltage/current 60 VDC / 80 mA Max 30 Ω Connect resistance Isolation to All other Connection Detachable screw terminal Connector size 0.2 – 2.5 mm² (AWG 24 – 13) I/O / Digital in Maximum voltage / load current 60 VDC / 2 mA Voltage levels Logic one >12 V, Logic zero <1V...
  • Page 14 Location of interface ports and LED’s RS-232 Connection Power connection Position Signal Direction* Description No. 1 Data Set Ready No. 2 Data Carrier Detect LED Indicators No. 3 Data Terminal Ready No. 4 – Signal Ground, not chassis ground No. 5 Receive Data No.

  • Page 15: Power Connection

    The following steps needs to be taken Bottom view 1. Connect the serial diagnostic cable to the console port (use only Westermo cable 1211-2027). 2. Connect cable to your computer (USB port, if drivers are needed they can be downloaded from our Web page).
  • Page 16 SHDSL Position Direction* Description No.1 In/Out 2-wire Receive/Transmit SHDSL No. 2 In/Out 2-wire Receive/Transmit SHDSL * Direction relative this product. I/O connection 4-position Product marking Direction Description No. 1 Status + Output Alarm relay (status) contact No. 2 Status – Output Alarm relay (status) contact No.

  • Page 17: Led Indicators

    LED indicators Status Description Product has no power. GREEN All OK, no alarm condition. Alarm condition, or until product has started up. (Alarm conditions are configurable, see WeOS Management Guide). FLASH Location indicator ("Here I am!"). Activated when connected to IPConfig Tool, or upon request from Web or CLI. Product has no power.
  • Page 18 Mounting These products should be mounted on 35 mm DIN-rail, which is horizontally mounted inside an apparatus cabinet or similar. It is recommended that the DIN-rail is connected to ground. Snap on mounting, see figure. Mounting the product with integrated DIN-clip: Removal Removing the product with integrated DIN-clip: Press down the support at the back of the product...
  • Page 19 Cooling This product uses convection cooling. To avoid obstructing the airflow around the product, use minimum spacing 25 mm (1.0") above/below and 10 mm (0.4") left/right the product. Note that this product can be connected to two different power sources. 10mm 10mm Spacing is recommended for the use of the product in full operating temperature range...

  • Page 20: Getting Started

    This product runs Westermo Operating System (WeOS) which provides several management tools that can be used for configuration of the product. • IPConfig tool This is a custom Westermo tool used for discovery of attached Westermo products. • Web Configuration of the product using the web browser.

  • Page 21: Referring Documents

    Referring documents Type Description Document number Management Guide Westermo OS management guide 6101-3201 Cable factory reset It is possible to set the product to factory default settings by using a standard Ethernet RJ-45 cable. 1. Power off the product and disconnect all cables.
  • Page 22 Westermo • SE-635 35 Stora Sundby, Sweden Tel +46 16 42 80 00 Fax +46 16 42 80 01 E-mail: info@westermo.com www.westermo.com REV. D 6642-22541 2020-06 Westermo Network Technologies AB, Sweden...
