Programming Manual
For Castle/Pyronix Technical Support
please call:
08456 434 999 (local rate) or:
01709 535 225
or visit:
www.pyronix.com
When calling Technical Support, please have
ready your software version number. This will
enable the correct advice to be given for your
panel and can be found in the engineer menu
under 'software revisions'.
Page | 1
RINS1861-4
Security Grade (SG) 3
Environmental Class (EC) II
(Different case sizes available)
For use with EURO 280 software:
Version 9.51 or above
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HIKVISION Pyronix EURO 280
Summary of Contents for HIKVISION Pyronix EURO 280
- Page 1 Security Grade (SG) 3 Environmental Class (EC) II EURO 280 Programming Manual (Different case sizes available) For Castle/Pyronix Technical Support please call: For use with EURO 280 software: Version 9.51 or above 08456 434 999 (local rate) or: 01709 535 225 or visit: www.pyronix.com When calling Technical Support, please have...
-
Page 2: Table Of Contents
Contents Page CHAPTER 1: THE SYSTEM OVERVIEW ................4 CHAPTER 2: THE ENGINEER MENU ................4 ....................5 NTERING THE NGINEERS ......................5 XITING THE NGINEER CHAPTER 3: POWERING UP & KEYPAD OPERATIONS ..........5 ................. 5 EFAULT ODES UMBER OF REAS EVEL ...................... - Page 3 4.1.28 PTS (Push To Set) ......................31 ) ..................32 HANGE ODES URESS UARD 4.1.29 Code Types and Numbers..................... 32 4.1.30 Wireless Keyfobs ......................32 4.1.31 Code Types ........................32 4.1.32 User Set Options ......................33 4.1.33 Flexi Set ......................... 33 ........................
-
Page 4: Chapter 1: The System Overview
C H A P T E R 1 : T H E S Y S T E M O V E R V I E W EURO: WIRELESS End Station ZEM0 9-16 9-16 ZEM1 17-24 17-24 Device A ZEM2 25-32 25-32 ZEM3 33-40... -
Page 5: Entering The Engineers Menu
Entering the Engineers Menu NOTE: You will not be able to access Engineers Mode if Areas or Set levels are set. The system must be fully unset in order to gain access to the Engineer Menu. Access may also be denied if the user has disabled the “Allow Engineer Menu” in the Master Manager Menu. -
Page 6: Number Of Areas/Level Sets
Number of Areas/Level Sets Euro 280: 14 level sets/areas Initial Power Up When powering up the Euro 280 system on mains only, an alarm will be generated. Proceed to keypad addressed as 00, which will display (from power up): The following will be displayed: When the display shows: ‘Battery Fault’... -
Page 7: Text Programming
Text Programming Text may be programmed for input names, for the ‘sign-on’ message, and to identify the Set level being set / unset. Each keypad key is allocated characters as shown below: The EURO 280 system incorporates predictive text, so the system will predict which word is being spelt. -
Page 8: Set / Unset System
Set / Unset System If you do not have access to a user code, setting and unsetting the system can be done using the engineer’s code. Enter Engineer Code (default 1111). “SET / UNSET SYSTEM?” will displayed Press the key Select the Area(s) you would like to set. -
Page 9: Chapter 4:The Engineer Functions
C H A P T E R 4 : T H E E N G I N E E R F U N C T I O N S Please note that any programming done in the Engineers Menu will not be seen by the system until you have exited and the system has saved its data (please see Page: 5). -
Page 10: Inhibit Fire/Hu
Inhibit Fire/HU This function allows you to select if you would like the EURO system to respond to or inhibit Fire and Hold-Up Alarms whilst in the Engineers Menu. Using the and keys, scroll to ‘INHIBIT FIRE/HU?’ Press the key The following will be displayed: Enter : for No (Default) Enter : for Yes... -
Page 11: Choose Mode Options
4.1.4 Choose Mode Options Choose Mode Using the and keys, scroll to ‘CHOOSE MODE?’, Press the key The End of Line Range Enter : 1K/1K. Enter : 4K7/2K2 Enter : 4K7/4K7 Enter : Wide* *The ‘Wide’ setting allows you to connect 2 or 3 devices in series, set in a 4k7/2k2 configuration. -
Page 12: Install Zem
Install ZEM Any wired or wireless zone expander modules (ZEMs) installed on the EURO system must be enabled by the ‘Install ZEM’ function. Install ZEM Using the and keys, scroll to ‘INSTALL ZEM?’ Press the key ZEM Address Select the address for the ZEM you are installing and press the ... -
Page 13: Wireless Device Control
Wireless Device Control 4.1.6 Wireless ZEMs If a wireless ZEM is installed on the EURO panel, the learning (and deleting) procedure for the wireless inputs and bells are performed in this function. It is recommended that all wireless devices are learnt at the wireless expander before any installation /mounting is done. This is so the signal strength (In Diagnostics, see page: 52) can be tested afterwards in order to check the location of the wireless device is acceptable. - Page 14 Learning… The following shows how to learn a wireless PIR or a magnetic contact to the system. During the learning process the ‘LEARN’ button must be held for >5 seconds then released. Upon release, the GREEN LED on the device flashes and the LCD displays “Input Learnt”...
- Page 15 Delete All Inputs can be deleted either individually or all at once. To delete all wireless devices press the key (the code 2000 will need to be entered). Alternatively, press the key to delete inputs individually. Control Bells To learn/delete bells, press the key, or press to program keyfob buttons.
- Page 16 If the GREEN LED on the wireless bell momentarily flashes and the display shows ‘Bell Learnt’ the device has been learnt successfully. Press the key. If the RED LED flashes, the device has not correctly learnt. Repeat the procedure to re-learn.
-
Page 17: Change Inputs
Change Inputs By default, all inputs are pre-set as ‘unused’ so you will need to program each individual input you require. The input will not be ‘live’ (and hence cannot be walk tested) until you have exited the Engineer Menu (please see Page: 5) 4.1.8 Input Types Number &... -
Page 18: Entry Shock Input Type (21)
Number & Type Operation Accepts input from keyswitch (or equivalent) to Set/Unset the Set modes Keyswitch assigned to it. Setting includes normal exit time, etc. Requires latching Latched action switch. NOTE : DOES NOT COMPLY WITH GRADE 2 or GRADE 3 Entry Shock Active when system set. -
Page 19: Creating A Common Area
4.1.10 Creating a Common Area In certain situations, a ‘common’ area may be needed. A common area is an area that only sets if other specific areas are set. For example, a reception in a building will only need to be set if the offices and warehouse are set. -
Page 20: Masking Response
4.1.12 Masking Response When unset, a masking event will generate an audible “alert” that requires response in the normal way. There will be NO signal transmitted to the ARC. When set, a masking event will generate an ‘intrusion’ response including “intruder” or “unconfirmed” output, but will NOT result in a confirmed alarm if paired with a activation of the same detector. -
Page 21: Shunt Inputs
Chime Enter : for No. (Default) Enter : for Single. Enter : for Follow. Press the key Omittable Enter : for No. (Default) Enter : for Yes. Press the key. Repeat for Double Knock, Dual Trip, Normally Open, Walk Test, Monitor Activity;... - Page 22 Action Status Outputs Shunt Input closed Inputs within the Shunt Group The ‘Follow Input’ output is live (shunted) are inactive Shunt Group Input No response triggered The ‘Follow Input’ output clears. Shunt Input opened The ‘Shunt Fault’ output is live for (unshunted) 10 seconds.
-
Page 23: Assign Keypads/Readers
Input Area Enter the areas/level sets you would like the input to be active in (To select level setting instead of areas please refer to Site Options “Use Level Set”, see page 45). NOTE: The primary Areas are A, B, C and D. Press the key. - Page 24 Assign Keypads/Readers Using the and keys, scroll to ‘ASSIGN KEYPADS/READERS?’ Press the key Address Enter the address of the keypad/reader you wish to assign. Press the key Type Enter : for Keypad Enter : for Reader Enter : for Not Used Press the ...
-
Page 25: Access Control/Door Entry Control
4.1.19 Access Control/Door Entry Control The following programming shows how to set up the Access Control facility if you are using it. The same programming process applies to ‘Door Entry Control’ which allows a tag reader to control an entry point. Assign Keypads/Readers Using the and keys, scroll to ‘ASSIGN KEYPADS/READERS?’... -
Page 26: Ward Control
To enter a name for the access control, press the key. Use the text programming to enter this, see page: 7. Press the key, you will be returned to the engineer menu. 4.1.20 Ward Control A Ward is sub-division of an area, providing a degree of independent control that can be used as a separate partition. - Page 27 Assign Keypads/Readers Using the and keys, scroll to ‘ASSIGN KEYPADS/READERS?’ Press the key Address Enter the address of the keypad/reader you wish to assign. Press the key Type Enter : for Reader Press the key Reader Is Enter : for Ward Control Press the key Enter the Ward Inputs.
-
Page 28: System Displays
System Displays Please see page 7, “Text Programming” section for this function, as it requires programming Area text, and sign on messages etc. 4.1.21 Area Texts You may choose how you want each Area/Level Set to be displayed, i.e. “Area A” may be used to fully Set a house therefore you may want to call it “Full House Set”... -
Page 29: Change Timers
Change Timers All the timers can be changed in this function, the table below shows the different timers available and the default values: Timer Function Range Default Entry Time Entry time for each area. (if programmed as the input type 0 –... - Page 30 Timer Function Range Default Input NAT NAT stands for Non-Activity. This is used in conjunction with Days the input attribute ‘Monitor Activity’, and will monitor the 0-14 days chosen input for the selected number of days. Input NAT NAT stands for Non-Activity. This is used in conjunction with Hours the input attribute ‘Monitor Activity’, and will monitor the 00-23 hours...
-
Page 31: Set Time And Date
Set Time and Date All log entries and the system display include the time and date. This may be also programmed in the Master Manager Mode. NOTE: Please note that powering down the system will reset the time and date information. Set Date and Time Using the and keys, scroll to ‘SET DATE AND TIME?’... -
Page 32: Only )
Exit Modes Using the and keys, scroll to ‘EXIT MODES?’ Press the key Area Exit Modes Enter : for Timed. Enter : for Final Door Enter : for Timed/Final Enter : for Push To Set Press the key. Repeat for each Area or press the ... -
Page 33: User Set Options
User Type Functions Operation Dial Out Forces the panel to dial out to UDL software when Programmed by Default: 5555 entered in “Day Mode” Engineer. (Duress Code 20) 4.1.32 User Set Options The User Codes can be programmed as the following: Unset/Set: The code will set and unset the EURO 280 system (Default) Unset Only: The code will only unset the EURO 280 system once it is set. - Page 34 User Areas (Not shown for ‘Dial Out’ User Type) Select the Areas the code will be valid for. Please note the primary Areas are A,B,C & D. Press the key User Set Options (Not shown for ‘Dial Out’ User Type) Enter : for Unset/Set (Default) Enter : for Unset Only Enter : for Set Only...
-
Page 35: Volume Control
Volume Control The Volume Control function applies to the loudspeaker output only. Volume levels at the keypad are programmed individually – please see page: 6. 4.1.34 Code Stops Sound If this function is enabled, then once an alarm has been generated (even if the code is not programmed for that area) the alarm will be silenced, and a ‘Misoperation (Abort) signal’... -
Page 36: Alarm Response
Alarm Response The Alarm Response function controls how you would like certain activations to perform. 4.1.39 Silent 1st Alarm If this function is selected as ‘confirmed’, then the first alarm to be activated on the system will be silent, but if another input activates (i.e. a confirmed alarm) then the alarm tones will be heard. - Page 37 Alarm Responses Using the and keys, scroll to ‘ALARM RESPONSES?’ Press the key Silent 1 Alarm Enter : for Never Enter : for If Confirm Press the key Disable Confirm On Entry Enter : for No Enter : for Yes. Leave as NO for BS8243 clause 6.4.5 or Change to YES for use with BS8243 clauses 6.4.3 / 6.4.4...
-
Page 38: Change Outputs
Change Outputs Any output type may be programmed to any of the systems outputs, including any outputs for wireless bells. Outputs must be used within their rated capacity. Please see the installation manual. NOTE: Only the ATE outputs can be inverted. 4.1.42 Output Types Type Active... - Page 39 Type Active Restore 0031 Entry Live during any entry time 0032 Exit Live during any exit time 0033 Entry/Exit Live during any entry or exit time 20 seconds after set/unset 0034 Lights When exit or entry timer starts procedure completed Follow Input 0035 When input triggers...
- Page 40 Type Active Restore If an input with NAT timer active Monitor 0065 does not trigger in the defined Next valid code entry Activity Fail period 0066 ATE not used Makes the ATE pin 5V or 0V depending if ATE outputs are inverted Can be used to trigger outputs via the keyfob.
-
Page 41: Ate Pin Output (Defaults)
4.1.43 ATE Pin Output (Defaults) Any communicating device that is to be connected to the ATE pins/socket on the PCB will have the following default output types: (For the diagram of the communication loom please see the Installation Manual): ATE OUPUTS EURO 280 1 (Blue) Fire (0001) - Page 42 ATE Pins When the display shows “ATE pin” you can decide what you would like the ATE pins to be programmed as. Select the output type for the ATE pin and press the key. Repeat for each pin. ZEM Ouputs? Once you return to the sub-menu ‘Endstation Output’...
-
Page 43: The 'Follow Input' Output
User Outputs? Use this menu to program the type (Latched or Timed), time in seconds (if Timed), and name of User Outputs. Use this menu in conjunction with programming of keyfob buttons and user defined output types to setup custom User Outputs Press the ... -
Page 44: Intelligent Set
Follow What? Enter : for Input (Default) Enter : for Shunt List Enter : for Ward Enter : for Area Press the key. Follow When? Enter : for When Set Enter : for When Unset Enter : for Always (Default) Press the ... -
Page 45: Site Options
Site Options A full range of site options is available to tailor the operation of the system. 4.1.46 Site Option Types Option Function Default If ‘YES’: Allows setting with the following faults active: Device fail, Set With Fault Mains fail, Battery faults, Fuse faults, SMS failure, relay sirens 1&2, relay Strobe faults. - Page 46 None: Inactive. Silent: Silent Hold Up. Bells Only: Bells Only (No signalling). Both: (Signalling and Bells) 2 Key HU EURO 280 keypads do not comply with ACPO requirements for this cont... facility to be used for police calls. Permits selection of inputs to ATE pins to suit ‘ATE’ (including Red Care Reset), ‘DigiCom’...
-
Page 47: Engineer Reset Options
Engineer Reset Options The Engineer Reset Options are used so that once an alarm has occurred; the system can only be reset by an engineer code, anti-code or red care reset from the alarm-receiving centre. Option Function Following an intruder alarm, an engineer must reset the system before it Engineer can be used again. -
Page 48: Review Logs
Review Logs There are two logs available on the EURO 280 system: The Panel Log: Includes all Set, Unset and Alarm events. The code holder performing any operation may be identified by pressing the key. The panel log also includes all system faults, details of engineer access etc. -
Page 49: Engineer Tests
The log will be displayed. Use the and keys to scroll through the log. For more information on an event (such as alarm silenced for example), press the key. Press the key to exit. Access Log Repeat the above for the Access log. When you wish to exit, press the ... -
Page 50: Test Outputs
Battery Load Test EURO 280 Systems may be programmed to perform an automatic battery load test at every power supply at 7.00am each day. This will drop the power supply voltage below the battery voltage, whilst monitoring the system diagnostics. The test will NOT take place if: ... - Page 51 be tested. To remove an input from the list, enter its number again. Press Soak Days Left Enter the number of days the soak test will last. Press the key. Initial Soak: Enter the number of days the soak test will revert to in the event a soak input is triggered during testing.
-
Page 52: Diagnostics
Diagnostics The system diagnostics are available for all parts of the system, including any remote power supplies if fitted. The diagnostic resolution is: Voltage: 0.1V Current: 0.01A The diagnostics that can be viewed are: System voltage and current at the control panel and at each individual power supply. System voltage at each keypad / tag reader. - Page 53 The status of wired and wireless ZEM inputs will also be shown in the below format. C = Closed. O = Open. F = Fault T = Tamper* B = Battery* S = Supervision* *Wireless inputs only Press the key again to view the resistance readings.
- Page 54 3 = Excellent 2 = Good install position 1 = Weak install position (reposition and retest) 0 = Missing (reposition & retest) ? = Waiting for information Press the key for more information Excellent [50-100] = OK to Install Good [30-49] = OK to Install Weak [0-29] = Bad installation position (reposition and retest) Missing [-] = Bad installation...
- Page 55 Inputs, Bells & Arming Stations Follow the same procedure as the signal strength steps mentioned previously. The battery levels shown on the display will be as follows: Good = At least 1 month of battery life remaining Replace = Battery will need replacing immediately Testing = Waiting for the battery result.
- Page 56 Wireless Dual Frequency Menu? Press the key to enter this sub-menu. Select the hub (by looking at the input range) to see the following menus: Channel: Displays which channel your control panel is operating on (either 01 or 02) Channel Reason: Displays the reason why the panel last switched from one channel to another.
-
Page 57: Set Up Downloading
Set Up Downloading The EURO 280 system has uploading and downloading capability. The UDL Software allows you to monitor the status of each input, alter programming, and review the logs. There are three ways that the panel communicates with the PC, one is remotely; via the telephone line,(thus requiring a DIGI modem card) then there is direct connection;... - Page 58 Security Mode Enter : for Auto Answer. Enter : for Panel Dials. Enter : for Dial Back (Default) Press the key. Telecom Line Enter : for Dedicated Enter : for Shared Press the key. Number of Rings To Prime Only available if ‘Modem’ has been selected and shared line option used.
-
Page 59: Program Arc
Signal Alarms Enter : for No Enter : for Yes Press the key. Repeat for Signal Faults, Signal Open/Close and Signal Access C. Press the key. ‘Program PCs’ will be displayed. Repeat for further PCs or press the key. If required, enter a text password, this protects the EURO 280 system from anyone dialling in. - Page 60 Program ARC? Using the and keys, scroll to ‘SET UP ARC/SMS?’ Press the key To program in an ARC number, press the key Disable ARC Enter : for Enabled Enter : for Disabled Press the key. Active Use the numeric keys to select the ARC details to program (up to 4 can be selected).
- Page 61 ARC Account Use the numeric keys to program the account number of the central station (this will be given to you by your ARC). Press the key. Select the DIGI channels you require to be sent to the ARC. Please see the table on page 59 for the default channels.
-
Page 62: Programming Contact Id, Sia, Sms, Webwayone And Chiron
The first Digi Channel will be shown, once you have checked this is correct, press the key to move to the next. To change this channel please see page 38 for the output types. All default values are shown on page 59. Once you have completed all the Digi Channels, ‘Program Digi Channels will be... -
Page 63: Pabx Systems (Only Relevant To Sms)
System Changes/Resets: Clock Set From/To, Added/Deleted/Changed Code, System Restart, Twin Device, Excess Current, Logs Cleared, Engineer Reset, Clean Start, Site Changed, CHC Call Failed, Logs nearly full, PC Clock Set to, Manager Info: Unset System Engineer Info: Engineer Access/Exit Access Control Alarm: Door Left Open/Forced Access Control Info: Tag at Reader Access Control Ref: Invalid Tag Special Log Switcher On: Input Special Log Switcher Open... - Page 64 Active : No : Yes (Enables ARC Details) Press the key Choose Format Select the format to be used: 000 = Fast 4.8.1 001 = Fast 6.8.1 002 = Fast 4.16.1 003 = Fast 6.16.1 004 = RS232 Tx 005 = Scope Pager 128 = SIA Level 1 129 = SIA 3 130 = Contact ID...
- Page 65 Area Accounts If you require a different ARC account code for each area, set this option as ‘Yes’. ARC Account Use the numeric keys to program the account number of the central station (this will be given to you by your ARC). Press the key.
- Page 66 ‘Program Digi Channels’ will be displayed and Press the key. ‘Program SMS Details’ will be displayed and Press the key if you are not using the SMS signalling protocol. If you are press the key Setup GPRS (future use) Programs: GPRS APN, GPRS User ID, and GPRS Password.
-
Page 67: Dial Out Menu
Dial Out Menu The Dial-Out Menu can be used to dial to a remote PC (rather than the PC dialling the control panel). The modem telephone numbers can be programmed in ‘Set Up Downloading’ – see page: 57. The following actions can be performed: Connect to PC, Test Dial, Arm Service (You must use the ARM software for this), Data from PC, Data to PC, Diagnostics and Commissions. - Page 68 F A U L T S A P P E N D I X A : D e v i c e F a i l If a device on the EURO 280 system is not installed correctly or has lost its communication with the panel, “DEVICE FAIL”...
- Page 69 POWER SUPPLY PROBLEMS Fault Description Solution Battery Fuse failed, Note: This indication should be expected OR Battery not present, during recharge after a mains failure. OR Battery volts low The top line displays ‘Control Panel’ if it is a fault Battery on the endstation, if the Battery fault is on a Fault xxx...
- Page 70 COMMUNICATION FAULTS Fault Description Solution Control End Station unable to If modem not present, ensure that “Disable Panel communicate with Digi Digi” option is set to ‘YES’ and “DOWNLOAD Modem Fault Modem MODE” is set to ‘NONE’ or ‘RS232’. If present, but not detected, check Digi Modem is inserted correctly (remove and reinsert, ensuring it ‘clicks’...
-
Page 71: Chapter 5: Contact Information
