INSTALL GUIDE
Covers All 430, 440, 441 and CJ Series
Advanced Security Systems
www.ultrastarters.com
Technical Support: 866-698-5872 ext 0
support@ultrastarters.com
FCC/ID Notice
This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
CAUTION: Changes or modifications not expressly approved by the part responsible for compliance
void the user's authority to operate this devise.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 430 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Ultra Start 430 Series

Summary of Contents for Ultra Start 430 Series

  • Page 1 INSTALL GUIDE Covers All 430, 440, 441 and CJ Series Advanced Security Systems www.ultrastarters.com Technical Support: 866-698-5872 ext 0 support@ultrastarters.com FCC/ID Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 2 Car Jack Mode (CJ series Only) System Operation Page 11 Relay Diagrams Page 12 COMPONENTS - Three Button Remote transmitter’s (430 Series) -Control Module - Four Button Remote transmitter’s (440 Series) - Plug-in Led - Plug-in Valet Switch (Program Switch) - Multi-Tone Siren...
  • Page 3 INSTALL MANUAL REMOTE VEHICLE SECURITY PAGE 3 For modules with 10 pin connector only. See page 4 for 11 pin connector. *500ma negative output Orange (-) When Armed Gray *500ma negative output Trunk Release Yellow Connect to vehicles ignition wire Ignition Input Connect to constant power.
  • Page 4 INSTALL MANUAL REMOTE VEHICLE SECURITY PAGE 4 For modules with 11 pin connector only. Orange *500ma negative output (-) When Armed Gray *500ma negative output Trunk Release Connect to constant power. 20amp input 12 Volt Input Brown Connect to Siren wire. 2amp Maximum Siren Output Black Connect to chassis ground...
  • Page 5 INSTALL MANUAL REMOTE VEHICLE SECURITY PAGE 5 Wiring Descriptions 10 Pin / *11 Pin Connector White (+) Park lights Park light output. Orange* (-) When Armed Negative output when system is armed. Grey* (-) Trunk Release Negative output for trunk release. Yellow (+) Ignition Input Input from vehicles ignition wire.
  • Page 6 INSTALL MANUAL REMOTE VEHICLE SECURITY PAGE 6 Recommended Installation Procedures Installing the LED- Choose a location that will be highly visible when the LED is installed. Most vehicles are equipped with knock out panels in the dashboard, these panels are easily removable and can be easily replaced if necessary.

  • Page 7: Table Of Contents

    INSTALL MANUAL REMOTE VEHICLE SECURITY PAGE 7 Programming To Enter Program Mode 1) Make sure ignition is in the off position. 2) Within three seconds turn the key ON the OFF. 3) Press and release the Program Button two times. 4) The siren will chirp and the lights will flash once to confirm.

  • Page 8: Shock Sensor Disable #3-#3-#1

    INSTALL MANUAL REMOTE VEHICLE SECURITY PAGE 8 Enter Program Mode Entering program mode is done by the following steps: 1) Make sure ignition is in the off position. 2) Turn the ignition key ON - OFF, leaving key in the OFF position. 3) Press and release the Valet button two times.

  • Page 9: Passive / Active Locks #3-#3-#2

    INSTALL MANUAL REMOTE VEHICLE SECURITY PAGE 9 Voltage / Door Pin Sensing 1 - Enter Program Mode - (Ignition ON-OFF, followed by Valet 2 times) 2 - Press & release transmitter buttons in the following sequence #1 - #1 then #3 3 - The siren will respond with the following: 1 Chirp Voltage Sensing- No Door Pin Connection Needed...

  • Page 10: Car Jack Mode* #2-#1-#3

    INSTALL MANUAL REMOTE VEHICLE SECURITY PAGE 10 Transmitter Programming Follow the steps below to program the transmitters to the system s memory Step 1 - Turn the Ignition key ON then OFF - Leaving Key Off. Step 2 - Press and release the Program Button twice then press and hold. Step 3 - The siren will respond with five chirps to confirm Transmitter Program Mode.
  • Page 11 INSTALL MANUAL REMOTE VEHICLE SECURITY PAGE 11 Alarm Functions 1. Press and release the button. 2. The park lights will flash and the siren will chirp one time. 3. The doors will lock (optional). NOTE: The LED will start flashing within five seconds. If installed, the starter disable will activate.
  • Page 12 INSTALL MANUAL REMOTE VEHICLE SECURITY PAGE 12 Relay Wiring Diagrams Negative Type Door Locks Positive Type Door Locks 5 Wire / Reverse Polarity Type Door Locks Negative Park Lights- In some cases the park lights may flash erratically after installing the negative park light relay. To correct this issue add a diode between the coil pins of the relay as shown.
