INSTALL GUIDE
430 and 440 Series Vehicle Security Systems
WWW.ULTRASTARTERS.COM
Technical Support 866-698-5872 ext 0
Support@ultrastarters.com
FCC/ID Notice
This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
CAUTION: Changes or modifications not expressly approved by the part responsible for compliance
void the user's authority to operate this devise.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 430 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Ultra Start 430 Series

Summary of Contents for Ultra Start 430 Series

  • Page 1 INSTALL GUIDE 430 and 440 Series Vehicle Security Systems WWW.ULTRASTARTERS.COM Technical Support 866-698-5872 ext 0 Support@ultrastarters.com FCC/ID Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 2 System Service Mode Service Mode- By remote Diagnostics COMPONENTS - Three Button Remote transmitter’s (430 Series) - Four Button Remote transmitter’s (440 Series) - Plug-in Valet Switch (Program Switch) - 10 Pin Main Harness - 2 pin Keyless Entry harness...

  • Page 3: Wiring Diagram

    *500ma negative output *500ma negative output Connect to vehicles ignition wire Connect to constant power. 20amp input Connect to Siren wire. 2amp Maximum Connect to chassis ground Connect to door pin. (+) when opened Connect to door pin. (-) when opened Connect to hood and / or trunk pin WIRING DIAGRAM Orange...

  • Page 4: Pin Connector

    10 Pin Connector White (+) Park lights Orange (-) When Armed Grey (-) Trunk Release Yellow Ignition Input RedMain Power Input Brown (+) Siren Output Black Ground Input Purple (+) Door Input Green (-) Door Input Blue (-) Hood Input 3 Pin Connector Red Green Door Lock...

  • Page 5: Basic Installation

    Step 1 - Connect All Of the Following Wires 10 Pin Power Connector Black Ground Input Yellow Ignition Input Power Input Brown (+) Siren Output White (+) Park lights Green* (-) Door Input Purple* (+) Door Input *Test for door pin type (+ or -) then connect the appropriate wire (Green or Purple) Step 2- Plug-In The Module When all the connections are done, the control module can be plugged in.

  • Page 6: Entering Program Mode

    PROGRAM OVERVIEW Program mode allows you to adjust the settings and options of your system. Your system has been intelligently designed by installers with years of experience. The system’s default settings do not require any program changes in most cases. However, this system does incorporate a advanced programming system with settings that can be easily adjusted Entering Program Mode To Enter Program Mode...

  • Page 7: Ignition Auto Locks

    Enter Program Mode Entering program mode is done by the following steps: 1) Make sure ignition is in the off position. 2) Turn the ignition key ON - OFF, leaving key in the OFF position. 3) Press and release the Valet button two times. 4) The siren will chirp one time to confirm entering program mode.

  • Page 8: Chirp Delete

    Double Pulse Unlock To change settings: 1 - Enter Program Mode - (Ignition ON-OFF, followed by Valet 2 times) 2 - Press & release transmitter buttons in the following sequence #2 - #2 then #1. 3 - The siren will respond with the following: Voltage / Door Pin Sensing To change settings: 1 - Enter Program Mode - (Ignition ON-OFF, followed by Valet 2 times)

  • Page 9: Transmitter Programming

    Transmitter Programming Follow the steps below to program the transmitters to the system s memory Step 1 - Turn the Ignition key ON then OFF - Leaving Key Off. Step 2 - Press and release the Program Button twice then press and hold. Step 3 - The siren will respond with five chirps to confirm Transmitter Program Mode.

  • Page 10: Silent Arm And Disarm

    Lock Doors & Arm The Alarm 1.Press & release the LOCK button on the remote transmitter. 2.The park lights will flash and the siren will chirp once. 3.The doors will lock. 4.The LED will start flashing within five seconds. Unlock Doors & Disarm The Alarm 1.Press &...

  • Page 11: Starter Disable

    Service Mode 1. The system must be disarmed and the ignition is turned OFF. 2.Press and release the lock and unlock buttons at the same time, then press and hold the lock button for five seconds. 3.The system will respond with five chirps and park light flashes to confirm that the system is in Valet mode.
  • Page 12 Negative Type Door Locks Positive Type Door Locks 5 Wire / Reverse Polarity Type Door Locks Negative Park Lights- installing the negative park light relay. To correct this issue add a diode between the coil pins of the relay as shown. Add IN4001 Diode as shown White...
