- Page 1 Revision 1.0 TYAN S1572 ATX Pentium Class 75 thru 200MHz 430TX PCI-ISA System Board User's Manual...
-
Page 2: Notice For Canada
Notice for the USA Compliance Information Statement ( Declaration of Comformity Procedure) DoC FCC Part 15: This Device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received including interference that may cause undesired operation. -
Page 3: Table Of Contents
Table Of Contents 1. Introduction... 3 1.1 Overview...3 1.2 Hardware Specifications...4 1.3 Software Specifications... 5 1.4 Environment... 5 2. Board Installation... 6 2.1 Unpacking... 6 2.2 Installation... 6 3. S1572 On Board Resource Settings... 7 3.1 S1572 Board Layout & Jumper Locations... 7 3.2 Quick Reference for Jumpers... -
Page 4: Introduction
1. Introduction 1.1 Overview The S1572 is a quality, high performance mainboard designed for Intel Pentium microprocessors. This mainboard utilizes the Intel 430TX chipset and can support CPU speeds of 75MHz through 200MHz. The S1572 will also support the CyrixM1/6x86 CPU's and the Intel multimedia Pentium with MMX processor, both the P55C and P54CTB Overdrive versions. -
Page 5: Hardware Specifications
1.2 Hardware Specifications/Features w CPU Intel Pentium 75 MHz thru 200 MHz (Socket 7) Intel Pentium P55C/P54CTB Overdrive (MMX) Cyrix/IBM/SGS M1/6x86 P120+, P150+, P166+, and AMD K5 PR90 through PR166. w Speed 50/60/66 MHz system bus 25/30/33 MHz PCI bus w DRAM 3 banks of 72 pin SIMM and 2 DIMM sockets Supports 5V or 3.3V memory... -
Page 6: Software Specifications
1.3 Software Specifications w BIOS Award or AMI BIOS AT CMOS setup, BIOS/CHIPSET setup, and hard disk utility included. Support for easy BIOS upgrades with flash EPROM chip. w O.S. Operates with MS-DOS, Windows 3.x, Windows for Work Group 3.x, Windows 95, Windows NT OS/2, Novell Netware,and SCO Unix. -
Page 7: Board Installation
2. Board Installation 2.1 Unpacking The mainboard package should contain the following: w S1572 Mainboard w One IDE 40 pin cable w One 34 pin floppy cable w User's Manual The mainboard contains sensitive electric components which can be easily damaged by static electricity, so the mainboard should be left in its original packaging until it is ready to be installed. -
Page 8: S1572 On Board Resource Settings
3. On Board Resource Setting Figure 3.1 S1572 ATX Board Layout SDRAM Bank 1 SDRAM Bank 0 PS/2 JP18 DRAM Bank 2 JP19 PS/2 DRAM Bank 2 Mouse DRAM Bank 1 DRAM Bank 1 DRAM Bank 0 DRAM Bank 0 CPU 0 PCI Slot 1 USB1... -
Page 9: Quick Reference For Jumpers
3.2 Jumper Settings CPU Speed Settings for Pentium P54C and P55C: CPU Speed Settings for Cyrix/SGS/IBM 6x86/M1/AMD: DIMM Memory Voltage Select: 3V is Default DIMM VCC 3V JP10 Heatsink Fan Power: J18 S1572-001-01 http://www.tyan.com JP23 CPU Speed 1-2,3-4 75MHz 90MHz 100MHz 120MHz 133MHz... -
Page 10: Cmos Reset
BIOS Voltage Select: JP2 (Default is 5V) BIOS 5V J8 Jumper Block: Desc. Soft Power Ext SMI Pri HDD LED 13-14 Sec HDD LED 15-16 PWR LED Reset SW Speaker CPU Select: Default P54C, P55C(MMX), & Cyrix These jumpers need not be changed. The system will auto-detect your CPU type. - Page 11 Reset Connector: J8 pin 22-23 Flash EPROM: JP2 This jumper should be left at the factory default. Keylock Connector: J25 S1572-001-01 http://www.tyan.com Pinout Assignment Power Good Ground Pinout Assignments No Connect Ground Keylock Ground...
- Page 12 I/O Port Setting: J15 and J16 Speaker Connector: J8 pins 24-27 HDD LED: J8 pins 13-14 and pins 15-16 Infra Red Interface: J8 pins 8-11 and J2 S1572-001-01 http://www.tyan.com For Serial Port 1-2 For IR Port Pinout Assignments Speaker out Ground + 5V Pinout Assignments...
-
Page 13: Cmos Rtc
3.3 CMOS RTC CMOS RTC includes an internal battery and Real Time Clock circuit. It provides the date and the time for the system. Normally the life span of a RTC internal battery is 10 years. This function is built onto the Intel TX chipset and cannot be field upgraded. -
Page 14: Reset Connector
Refer to chapter 5 for Flash EPROM upgrade procedures. 3.9 Hardware CMOS & Password Reset If you have been locked out of your system because you forgot your pass- word or set the CMOS incorrectly, follow the instructions below. a. Power off the system b. -
Page 15: Dram Installation
3.10 DRAM Installation The S1572 uses a 64-bit data path from memory to CPU and can accommodate up to 256MB of RAM. The mainboard supports Fast Page Mode, and EDO (Extended Data Out) 72 pin SIMMs. SDRAM(Synchronous) are also supported in the DIMM slots. DIMM's must be of the unbuffered variety. -
Page 16: Cpu Installation
3.11 CPU Installation Several types of CPUs (75 thru 200MHz) can be used on S1572. Please refer to section 3.2 for the correct CPU jumper settings for your board. w The CPU is a sensitive electronic component and it can be easily damaged by static electricity. -
Page 17: Upgrading Cache Memory
3.12 Upgrading Cache Memory The S1572's 512kb of on-board pipelined burst SRAM and cannot be field upgraded. The TX chipset can cache a maximium of 64MB of RAM. 3.13 Peripheral Device Installation After all the jumpers on the mainboard have been set, then it can be mounted into the case. -
Page 18: Bios Configuration
4. BIOS Configuration Award's BIOS has a built in setup program that allows the user to modify the basic system configuration. This type of information is stored in the battery-backed CMOS NVRAM. Entering incorrect information or for- getting your password can lock you out of your system.(refer to 3.9 for resetting of CMOS) 4.1. -
Page 19: Control Keys
4.2. Control Keys PgUp key Increases the numeric value or make changes PgDn key Decreases the numeric value or make changes F1 key General help, only for Status Page Setup menu and Option Page Setup Menu F2 key Change color from a total of 16 colors F3 key Calendar, only for Status Page Setup Menu F4 key... -
Page 20: Getting Help
4.3. Getting Help 4.3.1. Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. 4.3.2. Setup Page menu/Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted items. -
Page 21: Pnp/Pci Configuration
w Standard CMOS setup This setup page includes all the items in a standard compatible BIOS. w BIOS features setup This setup page includes all of the enhanced features of Award's BIOS. w Chipset features setup This setup page includes all the items of the 430TX chipset features. w Power Management setup Change, set, or disable system power management options. -
Page 22: Standard Cmos Setup Menu
4.5. Standard CMOS Setup Menu The items in Standard CMOS Setup Menu (Figure 4.2) are divided into 9 categories. Each category includes one or more setup items. Use the arrows to highlight the item and use the <PgUp> or <PgDn> keys to select the value you want for each item. - Page 23 w Primary/Secondary Drive Type This category identifies the types of hard disk drives that have been in- stalled in the computer. There are 46 predefined types and a user definable type. Press PgUp or PgDn to select a numbered hard disk type or type a number and press <Enter>.
-
Page 24: Base Memory
w Video This category detects the type of graphics adapter used for the primary display system. It must match your video display card and monitor. Al- though secondary monitors are supported, you do not have to select that type in setup. EGA/VGA Enhanced Graphics Adapter/Video Graphics Array. -
Page 25: Expanded Memory
Expanded Memory Expanded Memory (EMS) defines a 64K page frame in the area between 640K and 1Mb containing four 16K pages that are windows into the EMS memory. Programs issue requests to the EMS manager to switch the page to any part of EMS memory. -
Page 26: Virus Warning
w Virus warning This category flashes on screen. During and after the system boot up, any attempt to write to the boot sector or the partition table of the hard disk drive will halt the system and the following error message will appear. -
Page 27: Boot Up Floppy Seek
w Boot Up Floppy Seek During POST, the BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. 360K type is 40 tracks while 720K, 1.2M and 1.44M are all 80 tracks. Default value is Enabled Enabled BIOS searches for floppy disk drive to determine if it is 40 or 80 tracks. -
Page 28: Security Option
w Security Option This category allows you to limit access to the system setup, or just setup. Default value is Setup System The system will not boot and access to Setup will be denied if the correct password is not entered at the prompt Setup The system will boot, but access to setup will be denied if the password is not entered at the prompt... -
Page 29: Power Management Setup
4.7.1 Power Management Setup ROM ISA BIOS POWER MANAGEMENT SETUP AWARD SOFTWARE, INC Power Management :Disabled PM Control By APM Video Off Method :Blank Screen Video Off After :N/A Doze Mode :Disabled Standby Mode :Disabled Suspend Mode :Disabled HDD Power Down :Disabled Throttle Duty Cycle :62.5%... -
Page 30: Reload Global Timer Events
wDoze Mode Defines the continous idle time before the system enters Doze mode. w Standby Mode Defines the continous idle time before the system enters Standby mode. w Reload Global Timer Events Defines the the activities that can cause the PM timers to reload. (Break- ing out of PM Mode) S1572-001-01 http://www.tyan.com... -
Page 31: Pci Slot Configuration
4.8 PCI Slot Configuration ROM ISA BIOS PCI SLOT CONFIGURATION AWARD SOFTWARE, INC. Resource Controlled by :Manual Reset Configuration :Disabled IRQ3 assigned to :legacy ISA IRQ4 assigned to :legacy ISA IRQ5 assigned to :PCI/PnP IRQ7 assigned to :legacy ISA IRQ9 assigned to :PCI/PnP IRQ10 assigned to :PCI/PnP... - Page 32 wResources Controlled By The Award Plug and Play BIOS can automatically configure all the boot and Plug and Play compatible devices. If you select Auto, all the interrupt request and DMA assignment fields disappear, as the BIOS automatically assigns them. w IRQ n assigned to When resources are controlled manually, assign each system interrupt as one of the following types, depending on the type of device using...
-
Page 33: Integrated Peripherals
4.9 Integrated Peripherals Integrated Peripherals Award Software, Inc. IDE HDD Block Mode IDE Primary Master PIO IDE Primary Slave PIO IDE Secondary Master PIO IDE Secondary Slave PIO IDE Primary Master UDMA IDE Primary Slave UDMA IDE Secondary Master UDMA :Auto IDE Secondary Slave UDMA On-Chip Primary PCI-IDE On-Chip Secondary PCI-IDE :Enable... -
Page 34: Loading Setup Defaults
4.10. LOAD SETUP DEFAULTS ROM ISA BIOS CMOS SETUP UTILITY AWARD SOFTWARE INC. STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP Load Setup Defaults (Y/N)? N PCI SLOT configuration LOAD SETUP DEFAULTS ESC : Save & Exit Setup F10 : Quit Load SETUP Defaults except standard CMOS SETUP w Load SETUP defaults To load SETUP default values to CMOS NVRAM, enter "Y". - Page 35 ROM ISA BIOS CMOS SETUP UTILITY AWARD SOFTWARE, INC. STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP Enter Password PCI SLOT CONFIGURATION LOAD SETUP DEFAULTS ESC : Save & Exit Setup F10 : Quit Change/Set/Disable Password Type the password, up to eight characters, and press <Enter>. The password typed now will clear the previously entered password from CMOS memory.
-
Page 36: Ide Hdd Auto Detection
4.12. IDE HDD AUTO DETECTION ROM ISA BIOS CMOS SETUP UTILITY AWARD SOFTWARE, INC. Drive C: (202 Mb) Do you want to accept this as drive C (Y/N)? Type "Y" to accept the H.D.D parameter reported by BIOS. Type "N" to keep the old H.D.D parameter info. -
Page 37: Flash Writer Utility
5.0 Flash Writer Utility You can upgrade the BIOS of your mainboard by using a "Flash Memory Writer"(FMW) utility. This utility can be downloaded from the factory's BBS(Consult your system vendor for the phone #). The system BIOS is stored on a 'flash' EPROM ROM chip on the mainboard which can be erased and reprogrammed by the FMW. - Page 38 To reprogram the System BIOS, you must first do the following: 1. Check jumper JP2.(Default pins 1-2) The S1572 uses a 5V Flash EPROM so jumper JP2 should be left in the default postion on pins 1 and 2. This jumper should never be moved.
-
Page 39: The Flash Memory Writer Utility Screen
Once you have satisfied the two requirements mentioned above, you can run FMW. You can copy the contents of the “Flash” directory to your hard drive, or you can run the utility from a backup of the support floppy disk. Make sure the new BIOS file is in the same directory as the FMW utility. -
Page 40: System Resources
6.0 System Resource 6.1. TIMER & DMA CHANNEL MAP TIMER MAP: TIMER Channel-0 system timer interrupt TIMER Channel-1 DRAM REFRESH request TIMER Channel-2 SPEAKER tone generator DMA CHANNELS: DMA Channel-0 Available DMA Channel-1 Available DMA Channel-2 FLOPPY DISK adapter DMA Channel-3 Available DMA Channel-4 Cascade for DMA controller 1 DMA Channel-5 Available DMA Channel-6 Available...
