- Page 1 Revision 1.2 TYAN S1668 Dual Pentium Pro ATX 440FX PCI-ISA System Board User's Manual...
-
Page 2: Table Of Contents
1.4 Environment............5 2. Board Installation.............. 6 2.1 Unpacking.............. 6 2.2 Installation.............. 6 3. S1668 On Board Resource Settings......... 7 3.1 S1668Board Layout & Jumper Locations....7 3.2 Quick Reference for Jumpers........8 3.3 CMOS RTC............11 3.4 Speaker Connector..........1 1 3.5 Turbo Switch............ -
Page 3: Introduction
With eight SIMM sockets, the S1668 can provide a very flexible memory configuration of 8MB to 1024MB of RAM. With the S1668's support for dual Pentium Pro processors, you can start a system with just one CPU, and later add another, when more processing power is required. -
Page 4: Hardware Specifications
Support for an IrDA compliant InfraRed inter- face. On-board floppy controller. On-board USB(Universal Serial Port). wMouse On-board PS/2 mouse connector. wI/O Bus Slots 5 Master/Slave PCI-Bus 3 ISA Bus (One ISA and one PCI shared slot) S1668-ATX-001 http://www.tyan.com... -
Page 5: Software Specifications
Award BIOS/Flash are trademarks of Award Software International Inc. AMI BIOS is a trademarks of American Megatrends Inc. IBM,PC,AT,PS/2 are trademarks of IBM Corporation INTEL,Pentium Pro are trademarks of Intel Corporation. Copyright c 1996 TYAN Computer Corp. S1668, Titan Pro ATX. S1668-ATX-001 http://www.tyan.com... -
Page 6: Board Installation
DAMAGED! 2.2 Installation You are now ready to install your mainboard. The mounting hole pattern of the S1668 matches the ATX system board spec. It is assumed that the chassis is for a standard ATX mainboard form factor. S1668-ATX-001 http://www.tyan.com... -
Page 7: S1668 On Board Resource Settings
3. On Board Resource Setting Figure 3.1 S1668 ATX Board Layout PWR CON. 5V J 5 0 J 4 9 J 4 8 PS/2 CPU 1 PS/2 Mouse 82441FX pin 1 82442FX CPU 0 CON4 PCI Slot 1 pin 1... -
Page 8: Quick Reference For Jumpers
DRAM Voltage: J2, J3, J14, J15, J4, J5, J16 and J17(Default 5V) (Some EDO memory is 3.3V) Voltage 3.3V off off off off off on on Warning, damage to system can result if set incorrectly! S1668-ATX-001 http://www.tyan.com... - Page 9 Keylock Ground Turbo Switch: J47 ( Non-Turbo Mode Not Supported ) HDD LED: J46 Pinout Assignments Cathode Anode Cathode Anode Pins 1 and 2 are for primary IDE channel. Pins 3 and 4 are for secondary IDE channel. S1668-ATX-001 http://www.tyan.com...
- Page 10 Signal In Signal Out Super I/O Type: J26 Type 665IR 669IR This setting depends on what type of SMC I/O chip is installed on the board. This jumper is set at the factory and should not be changed. S1668-ATX-001 http://www.tyan.com...
-
Page 11: Cmos Rtc
XT days. The Intel 44FX chipset doesn't support a de-turbo mode, but the S1668 has a connector (J47) for the cable that may come has a connector (J47) for the cable that may come with the case.with the case. -
Page 12: Reset Connector
J32 determines which type of EPROM is used. This jumper has been set to match the on board BIOS chip. The factory default for the S1668 is on pins 1-2. Refer to chapter 6 for Flash EEPROM upgrade procedures. -
Page 13: Dram Installation
3.10 DRAM Installation The S1668 uses a 64-bit data path from memory to CPU and can accommodate up to 1024 MB of RAM. The mainboard supports standard, EDO (Extended Data Out) and ECC(Error Correcting Code) 72 pin SIMMS . All installed memory will be automatically detected so there is no need to set jumpers. - Page 14 768MB 128MB x2 128MB x2 64MB x2 64MB x2 768MB 128MB x2 128MB x2 128MB x2 32MB x2 832MB 128MB x2 128MB x2 128MB x2 64MB x2 896MB 128MB x2 128MB x2 128MB x2 128MB x2 1024MB S1668-ATX-001 http://www.tyan.com...
-
Page 15: Cpu Installation
3.11 CPU Installation Many types of Pentium Pro (150 thru 200 MHz) CPUs can be used on the S1668. Please refer to the previous pages for the correct CPU jumper settings for your board. w The CPU is a sensitive electronic component and it can be easily damaged by static electricity. -
Page 16: Vrm Installation
CPU that is being installed. The VRM can only fit in the socket one way so there is no danger of installing it incorrectly. Not all VRM's will work in the S1668. Make sure you purchased a qualified VRM. w VRM socket 0 is for CPU socket 0. -
Page 17: Bios Configuration
Figure 4.1 will appear on the sceen. The Main Menu allows you to select from the 8 setup functions and 2 exit choices. Use the arrow keys to select among the items and press <Enter> to accept or enter each sub-menu. S1668-ATX-001 http://www.tyan.com... -
Page 18: Control Keys
Calendar, only for Status Page Setup Menu F4 key Reserved F5 key Restore the previous CMOS value, only for Option Page Setup Menu F6 key Load defaults F8 key Reserved F9 key Reserved F10 key Save all CMOS changes, only for Main Menu S1668-ATX-001 http://www.tyan.com... -
Page 19: Getting Help
USER PASSWORD POWER MANAGEMENT IDE HDD AUTO DETECT PNP/PCI CONFIGURATION SAVE AND EXIT LOAD BIOS DEFAULTS EXIT WITHOUT SAVING ESC : Save & Exit Setup :Select Item F10 : Quit (Shift)F2 :Change Color Time, Date, Hard Disk Type,..S1668-ATX-001 http://www.tyan.com... - Page 20 I/O options. w w IDE HDD auto detection Automatically configure hard disk parameters. w w Save and exit setup Save changes to CMOS and exit setup w w Exit without saving Abandon all CMOS changes and exit setup. S1668-ATX-001 http://www.tyan.com...
-
Page 21: Standard Cmos Setup Menu
The day, from Sun to Sat, Determined by the BIOS date, month and year entries. Date The date, from 1 to 31 (or maximum allowed in a month) Month The month, Jan to Dec. Year The year, from 1900 to 2099 S1668-ATX-001 http://www.tyan.com... - Page 22 1.2M,5.25 5-1/4 inch AT-type high-density drive; 1.2 megabyte capacity 720K, 3.5 in. 3-1/2 inch double-sided drive; kilobyte capacity 1.44M, 3.5 in. 3-1/2 inch double-sided drive; 1.44 megabyte capacity 2.88M, 3.5 in. 3-1/2 inch double-sided drive; 2.88 megabyte capacity S1668-ATX-001 http://www.tyan.com...
- Page 23 The value of the base memory is typically 640K. Extended Memory The BIOS determines how much extended memory is present during the POST. This is the amount of memory located above 1MB in the CPU's memory address map. S1668-ATX-001 http://www.tyan.com...
-
Page 24: Bios Features Setup
Typematic Rate Setting :Disabled Typematic Rate (Chars/sec) ESC :Quit :Select Item Typematic Delay (msec) :250 Security Option :Setup PS/2 mouse function :Disabled :Help PU/PD/+/- :Modify PCI/VGA Palette Snoop :Disabled :Old Values (Shift)F2 :Color :Load BIOS Defaults :Load Setup Defaults S1668-ATX-001 http://www.tyan.com... - Page 25 Swap Floppy Drive Default value is Disabled E n a b l e d Floppy A & B will be swapped under DOS D i s a b l e Floppy A & B will be normal definition. S1668-ATX-001 http://www.tyan.com...
- Page 26 The selected character is displayed when a key is held down after a delay set by the Typematic Rate Delay. It then repeats at a rate set by the Typematic Rate. S1668-ATX-001 http://www.tyan.com...
-
Page 27: Chipset Features Setup
:Enable DRAM Read Burst(B/E/F) :x1/2/3 More Information on these settings DRAM Write Burst(B/E/F) :x2/2/3 ISA Bus Clock :PCICLK/4 can be found at Tyan's web site. DRAM Refresh Queue :Disable http://www.tyan.com DRAM RAS# Only Refresh :Disable ECC Checking/Generation :Disable Fast DRAM Refresh... -
Page 28: Power Management Setup
Video Off Method The "Blank Screen" option will let the system BIOS blanks the screen when disabling video. V/H SYNC+Blank will let the BIOS turn off the V-SYNC and H-SYNC signals from the VGA card to the monitor. S1668-ATX-001 http://www.tyan.com... - Page 29 Standby Mode Defines the continous idle time before the system enters Standby mode. w w Power Down Activities Defines the the activities that can cause the PM timers to reload. (Break- ing out of PM Mode) S1668-ATX-001 http://www.tyan.com...
-
Page 30: Pci Slot Configuration
PCI Slot3 INTC INTA PCI Slot3 INTD INTB PCI Slot4 INTA INTD PCI Slot4 INTB INTA PCI Slot4 INTC INTB PCI Slot4 INTD INTC PCI Slot5 INTA INTA PCI Slot5 INTB INTB PCI Slot5 INTC INTC PCI Slot5 INTD INTD S1668-ATX-001 http://www.tyan.com... - Page 31 Primary IDE INT# Select the PCI INT# that the Primary IDE controller will use. Default value is A. w w Secondary IDE INT# Select the PCI INT# that the Secondary IDE controller will use. Default value is B S1668-ATX-001 http://www.tyan.com...
-
Page 32: Integrated Peripherals
On-Board Parallel Port :378/IRQ7 Parallel Port Mode :Normal The Settings in the Integrated Peripherals lets the user enable or disable on-board device. You can also configure the I/O and IRQ settings of the on-board serial and parallel ports. S1668-ATX-001 http://www.tyan.com... -
Page 33: Load Setup Defaults
If any problem has occurred, loading the SETUP DEFAULTS is recommended. 4.10. PASSWORD SETTING When you select this function, the following message will appear at the center of the screen to assist you in creating a password. ENTER PASSWORD S1668-ATX-001 http://www.tyan.com... - Page 34 If you select Setup at Security Option of BIOS Features Setup Menu, you will be prompted only when you try to enter setup. S1668-ATX-001 http://www.tyan.com...
-
Page 35: Ide Hdd Auto Detection
ESC : Save & Exit Setup :Select Item F10 : Quit (Shift)F2 :Change Color Type "Y" and you will quit the Setup Utility and save the user setup values to RTC CMOS SRAM. Type "N" to return to Setup Utility. S1668-ATX-001 http://www.tyan.com... -
Page 36: Flash Writer Utility
You cannot upgrade an Award BIOS to a AMI BIOS or a AMI BIOS to an Award BIOS. *This file name is subject to change and can have either a "bin" or a "rom" extension. S1668-ATX-001 http://www.tyan.com... - Page 37 To reprogram the System BIOS, you must first do the following: 1. Check jumper J32 The S1668 uses a 5V Flash EPROM so jumper J32 should be left in the default postion on pins 1 and 2. This jumper should never be moved.
-
Page 38: The Flash Memory Writer Utility Screen
Mainboard, your system may not be able to boot. If this happens, it will require service by your system vendor. Follow the requirements and instructions in this section precisely to aviod inconvenience. S1668-ATX-001 http://www.tyan.com... -
Page 39: System Resources
4 SERIAL port 1 5 PARALLEL port 2 6 FLOPPY DISK adapter 7 PARALLEL port 1 8 RTC clock 9 Available 10 Available 11 Available 12 Available 13 MATH co-processor 14 Primary IDE Channel 15 Secondary IDE Channel S1668-ATX-001 http://www.tyan.com...
