Brush Mulcher MX230 and MX330
OPERATOR'S MANUAL
Issue Date: June 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX230 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Baumalight MX230

  • Page 1 Brush Mulcher MX230 and MX330 OPERATOR’S MANUAL Issue Date: June 2019...
  • Page 2: Table Of Contents

    5�4 Check Belt Tension������������������������������������������������������������������������������������������������������������������� 16 5�5 Replace Belt ������������������������������������������������������������������������������������������������������������������������������ 17 5�6 Rotate Cutting Teeth MX330 ���������������������������������������������������������������������������������������������������� 18 5�7 Replace Cutting Teeth MX230�������������������������������������������������������������������������������������������������� 18 5�8 Replace Cutting Teeth MX330�������������������������������������������������������������������������������������������������� 19 5�9 Replace Tooth Holder MX330 �������������������������������������������������������������������������������������������������� 19 6 TROUBLESHOOTING ������������������������������������������������������������������������������������������������������������������������ 20 7 STORAGE �������������������������������������������������������������������������������������������������������������������������������������������...
  • Page 3: Introduction

    1 INTRODUCTION 1.1 Overview Congratulations on your choice of a Baumalight Brush Mulcher to complement your mulching operation. This equipment has been designed and manufactured to meet the needs of a discriminating buyer. The rotor is hydraulic powered by the hydraulic...
  • Page 4: 1�2 Intended Use And Foreseeable Misuse

    1.2 Intended Use And Foreseeable Misuse The brush mulcher is designed to be used by experienced operators, trained in the safe operation of a excavator and trained in the hazards related to using the brush mulcher and the safe use of the mulcher for the intended purpose.
  • Page 5: Safety

    2 SAFETY 2.1 Safety Alert Symbol And Safety Words You must read, understand and follow the ^ CAUTION instructions given operating unit CAUTION - Indicates a hazardous manufacturers, as well as the instructions in this situation, which, if not avoided, could manual.
  • Page 6: 2�2 Operational Hazards

    Additional information applications� may be found at: www.asae.org or www.osha.gov. If you do not understand any part of this manual, Any other use may result in personal contact Baumalight at 866-820-7603. injury, damage to equipment and may void the warranty�...
  • Page 7: Prepare For Emergencies

    Safety signs are identified in Section 3 of this ^^ DANGER manual. • Replacement safety signs are available from Prevent electrocution� your Baumalight dealer. Death or serious injury can result if equipment comes near or contacts Do Not Allow Riders power lines� •...
  • Page 8: Detach Brush Mulcher Safely

    Detach Brush Mulcher Hazards From Modifying Safely Equipment Do not make any alterations to your brush Detach brush mulcher on a firm and level surface. mulcher. Altering the equipment may cause unsafe Brush mulcher may fall over if detached on sloping conditions and may void the manufacturer’s or soft surface.
  • Page 9: 2�3 Maintenance Hazards

    Entanglement hazard� Do not make unauthorized modifications. Contact Keep clear of moving components� Baumalight at 866-820-7603 before you weld, cut/ drill holes, or make any other modifications. Wear proper protective equipment appropriate for the job�...
  • Page 10: Safety Signs

    3 SAFETY SIGNS Dashed line indicates item hidden from view unless cover is removed. A. MTB-178 Safety Sign B. MTB-176 Safety Sign...
  • Page 11 C. MTB-177 Safety Sign E. MTB-185 Safety Sign F. MTB-182 Safety Sign D. MTB-175 Safety Sign...
  • Page 12: Operation

    4 OPERATION 4.1 Preparation For Use 4.2 Machine Components A. Operators Manual Storage Tube ^ WARNING B. Mounting Plate Wear an approved respirator (N95 Type C. Safety Push Bar as a minimum)� D. Cutting Teeth Follow local, state federal regulations� E.
  • Page 13: 4�3 Pre-Operation Check List

    4.3 Pre-Operation Check List Check-mark Check these items: Frequency Verify that mulcher is properly attached to excavator. Each operation. Verify that hydraulic hoses are connected to excavator Each operation. hydraulic couplers. Verify the cutting tips on the rotor are tight. Every 4 hours.
  • Page 14: 4�6 Transporting

    4.6 Transporting 4.7 Carbide Teeth Break-In ^ DANGER During the first few hours of use, avoid hitting stones as much as possible to allow the carbide Prevent electrocution� teeth to wear slightly. This can be done by keeping the cutting wheel above ground level. Death or serious injury can result if Brand new carbide tips are razor sharp and can equipment comes near or contacts...
  • Page 15: 4�8 First Time User Tips

    4.8 First Time User Tips 4.9 Field Operation • First, operate all functions in a clear area with ^ WARNING the excavator at idle speed to get a good feel for the controls before you actually move into Prevent serious injury or death caused any brush.
  • Page 16: 4�10 Clearing Jams

    4.10 Clearing Jams If the rotor stalls, stop rotor motion, raise slightly ^ WARNING and try again. Never operate brush mulcher when 1. MX330 Only: If still stalled, lower unit so teeth other people are in the vicinity� Debris tips dig slightly into sod, a log or stump. can be thrown several feet from cutting area�...
  • Page 17: Service And Maintenance

    Inspect the unit for any buildup of contamination (dirt, stones, etc.). Order replacement seal kit from Baumalight and follow instructions provided with kit. Check cutting teeth every 4 hours of use. Keep cutting teeth in good condition. Unit will cut faster...
  • Page 18: 5�4 Check Belt Tension

    5.4 Check Belt Tension 1. Lower mulcher to ground. 8. Close inspection cover (A). Do not operate mulcher with cover (A) open or removed. 2. Set parking brake, stop engine and remove key. ^ WARNING Moving parts can crush and cut� Keep clear of moving components�...
  • Page 19: 5�5 Replace Belt

    5.5 Replace Belt 1. Lower mulcher to ground. 11. Align pulley holes with non threaded holes in hub (F) and install bolts (D). 2. Set parking brake, stop engine and remove key. 12. Place a straight edge (I) on drive pulley and rotor pulley.
  • Page 20: 5�6 Rotate Cutting Teeth Mx330

    9. Rotate D ring so slot is under mounting strap. 6. Install spacer (A) and locknut. Tighten ⅜ inch Note: Parts breakdown can be found on locknut to 65 lb/ft (88 Nm) of torque. Baumalight’s website. www�baumalight�com Note: Parts breakdown can be found on Baumalight’s website. www�baumalight�com...
  • Page 21: 5�8 Replace Cutting Teeth Mx330

    7. Install tooth into new tooth holder and tighten locknut to 65 lb/ft (88 Nm) of torque. ⅜ inch locknut to 65 lb/ft (88 Nm) of torque. Note: Parts breakdown can be found on Note: Parts breakdown can be found on Baumalight’s website. www�baumalight�com Baumalight’s website. www�baumalight�com...
  • Page 22: Troubleshooting

    6 TROUBLESHOOTING PROBLEM CHECK SOLUTION Rotor does not spin. Rotor jammed. Remove material from rotor. See Clearing Jams. Low oil level. Check oil level in excavator. Add if necessary. Low oil flow. Check flow control on excavator. See your dealer. Rotor rotates slow or sluggish.
  • Page 23: Warranty

    8 WARRANTY This product is warranted to be free of defects in materials and workmanship under normal use and service, for a period of one year from the date of purchase, when operated and maintained in accordance with the Operating and Maintenance Instructions supplied with this unit. This warranty does not cover misuse or negligence.
  • Page 24 For parts, specifications and the latest machine information please visit our website. www�baumalight�com MTB MFG INC. CORPORATE HEADQUARTERS 4575 Powell Rd., Wallenstein, Ontario Canada N0B 2S0 Phone - 519.698.9864 Toll Free - 866.820.7603 Fax - 519.698.1087 www�baumalight�com...
