- Page 1 MODEL CS-41 instructions IMPORTANT: KEEP THIS INSTRUCTION BOOKLET IN THE PLACE PROVIDED ON THE CHILD RESTRAINT...
- Page 2 Smart Design Please keep this Instruction Booklet in the storage area under the seat for future reference. DO NOT USE THIS CHILD RESTRAINT UNTIL YOU HAVE READ AND UNDERSTOOD THE INSTRUCTIONS IN THIS USER GUIDE AND IN YOUR VEHICLE OWNERS MANUAL...
-
Page 3: Table Of Contents
Contents Quick Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 WARNINGS . -
Page 4: Quick Reference
Quick Reference IMPORTANT: Also read the detailed instructions that follow this quick reference Headrest adjusted to Always use the Tether Strap . suit the child’s height . page 22 & 23 page 12 Booster Seat must Always fit the sash sit firmly back belt through the against the vehicle... -
Page 5: Warnings
WARNING • DO NOT LEAVE CHILDREN UNATTENDED IN THE CAR • Use the restraint exactly as shown in the Instructions . • Supervision of children is needed because they may be able to undo buckles . • DO NOT USE WITH JUST A LAP BELT . You must use with a lap-sash seat belt . -
Page 6: Features
Features - Front View Height Adjustable Vehicle Sash Headrest Belt Guide Shoulder Height Labels SIP pod (Side Impact Protection) SIP pod (Side Impact Protection) Armrest Armrest Lower Vehicle Lower Vehicle Belt Path Belt Path Cupholder... - Page 7 Features - Back View Vehicle Sash Headrest Adjuster Belt Guide Vehicle Sash Belt Guide Tether Strap SIP pod (Side Impact Protection) Tether Anchorage Lower Vehicle Belt Path Storage Pocket for Tether End...
-
Page 8: Important Information
IMPORTANT INFORMATION This Child Restraint is: To be used with a lap-sash seatbelt by a child whose shoulders are above the lower shoulder height marker with head restraint in the lowest position (approximately 4 years of age) until the child’s shoulders reach the upper shoulder height marker with the head restraint in highest position (approximately 6 to 8 years of age) . -
Page 9: Installation
Installation Seating Location The safest position for this booster seat is in the centre rear of the back seat provided it is fitted with a lap/sash seat belt and a tether anchorage . DO NOT use the front seating po- sition unless there is no rear seat and there is a tether strap mount- ing position available behind the... -
Page 10: Correct Seat Belt
Correct Seat Belt Use only the vehicle’s lap and shoulder belt when restraining a child in this booster seat . DO NOT use a lap belt only . The centre rear seating position can be used ONLY if there is a lap and shoulder belt seat belt in that seating position . -
Page 11: Select A Stable Position
Select a Stable Position Before using the Booster Seat check the suitability of the seating position . Place the Booster Seat on the vehicle seat . Push it firmly into place . Check that it is stable and if not try another position in the vehicle . -
Page 12: Reclining Backrest
Reclining Backrest Vehicle seats have different shapes and some have a greater backrest angle than others . The backrest of the AACE can be pushed back to better fit a more reclined vehicle seat . Always have the backrest a close fit to the back of the vehicle seat backrest . -
Page 13: Use
Headrest Adjustment Squeeze headrest release lever until locking mechanism disengages, raise or lower headrest as required . As the headrest rises the width of the sides will automatically increase . Headrest should be just above the shoulders . -
Page 14: Seat Bottom Adjustment
Seat Bottom Adjustment The seat bottom can be pulled forward to suit bigger children . To adjust: Reach under the seat pad, locate the release lever, press this upwards . Slide the seat pad forward or back as required . There are three positions for the best fit . -
Page 15: Extra Side Impact Protection
Extra Side Impact Protection There are SIP pods on each side of the backrest . When the booster seat is installed in an outboard position the SIP pod closest to the door can be extended to keep the booster further away from the door in an impact . -
Page 16: Correct Vehicle Belt Placement
Correct Vehicle Belt ALWAYS USE THE Placement SASH GUIDE Place child on seat . Check headrest height and adjust if necesssary . See page 12 . Pass sash belt through the guide under the headrest . Connect the vehicle belt . Check that it is securely engaged . -
Page 17: Vehicle Belt Checklist
Vehicle Belt Checklist CORRECT VEHICLE BELT PATH The cover has labels marking the correct vehicle belt path . Sash belts must pass through the red guide in the headrest Belts must pass under the armrests Engage vehicle buckle securely WARNING DO NOT LEAVE CHILDREN UNATTENDED... -
Page 18: Removing And Refitting Cover
Removing and Refitting Cover Seat Pad Remove the Cup Holder . Release the bottom edges of the seat pad by releasing the 6 snaps and remove . Seat Back Release the 2 snaps at the lower back, unhook the 4 elastic bands on the back side and remove the cover by lifting it over the head- rest . -
Page 19: Fitting And Removing Cupholder
Fitting and Removing Cupholder To fit: insert cupholder clip through opening in cover and into matching slot in the base . To remove: hold cupholder firmly and pull upwards . IMPORTANT: the cupholder must be securely fitted into the slot in the base, if not it may dislodge . -
Page 20: Shoulder Height Labels
Shoulder Height Label Shoulder Height Label: this booster seat is rated as suitable for children from approximately 4 years to 8 years . The exact sizing is determined by the shoulder height label When a child is sitting on the booster seat with their back firmly up against backrest, the top of their shoulders must be... -
Page 21: After This Booster Seat
After this Booster Seat After your child has outgrown this booster seat they will be big enough to sit on a vehicle seat without a child restraint . THIS LINE WHEN IMPORTANT: if when sitting on the vehicle seat, the child’s lower legs are not able to bend at the knees they should remain in the WEST POSITION booster seat... -
Page 22: Tether Strap Warnings
TETHER STRAP WARNINGS THIS RESTRAINT MUST BE ATTACHED TO A CHILD RESTRAINT UPPER ANCHORAGE POINT IN THE CAR . REFER TO CAR OWNERS HANDBOOK FOR LOCATION OF ANCHORAGE POINTS . REFER TO A CHILD RESTRAINT FITTING STATION IF NO ANCHORAGE POINTS ARE IN THE MOTOR CAR . Always secure the loose end of the top tether strap to prevent it hanging out of the car or being accessible by the child . -
Page 23: Tether Strap Use
Tether Strap Use This booster seat has a tether strap permanently attached to the backrest . This is an essential part of the booster seat’s safety systems and must always be used . Tether Strap Tether Anchorage Storage Pocket for unused webbing IMPORTANT: Even when the booster seat is not occupied ensure the tether strap is connected so that in the event of a sudden stop or accident the booster seat will not move about and possibly... - Page 24 Always connect the snap hook securely to the anchorage fitting . Pull to increase tension Adjust the tether as shown . The anchor fitting must be aligned as shown unless stated otherwise in the vehicle owners handbook . If drilling a new hole, select a position on the centre line of the seating position, and no closer than 100 mm from the front edge...
-
Page 25: Tether Strap Anchorage - Installation
Tether Strap Installation Attachment If the car is fitted with a child Bolt restraint anchorage point: Locate the anchorage point Lock Washer behind the rear seating position (consult the vehicle owners hand- Anchor book for location of the anchor- Fitting age point) . - Page 26 Tether Strap Installation If the car is not fitted with Attachment a child restraint anchorage Bolt point: Anchor For sedans only—drill a 9 mm Fitting hole in the parcel shelf on the centre line of the seating posi- Spacers tion as shown on page 23 . (if required) Install the anchor bolt as shown opposite .
-
Page 27: Care, Maintainance And Storage
Care, Maintenance and Storage Seat Cover Wash with warm water (under 30°C) and mild detergent . Do not iron . Do not bleach or dry clean . Do not twist the soft goods to dry with great force . It may leave the seat cover with wrinkles . -
Page 28: Accessories And Spare Parts
Accessories DO NOT add accessories, toys, padding or other items to the child restraint unless provided by Nuna . Aftermarket accessories (i .e . items not provided in the box with the child restraint), may not have been tested for use with this child restraint and if used, may lower the level of protection offered possibly leading to injury or death . - Page 29 Babyhood 132 Compton Road, Woodridge, 4114 Brisbane, Australia Tel: 07 3208 3555 Fax: 07 3208 8691 email: sales@babyhood .com .au web: www .babyhood .com .au...
