Levelflex FMP55 HART

Fixed current

Navigation
Prerequisite
Description
User entry
Factory setting

Damping output

Navigation
Description
User entry
Factory setting
Additional information

Failure mode

Navigation
Prerequisite
Description
Selection
Factory setting
Endress+Hauser
 Setup → Advanced setup → Current output 1 to 2 → Fixed current
Current span (→  168) = Fixed current
Define constant value of the output current.
4 to 22.5 mA
4 mA
 Setup → Advanced setup → Current output 1 to 2 → Damping output
Reaction time of the output signal on fluctuation in the measured value.
0.0 to 999.9 s
0.0 s
Fluctuations of the measured value affect the output current with an exponential delay,
the time constant τ of which is defined in this parameter. With a small time constant the
output reacts immediately to changes of the measrued value. With a big time constant the
reaction of the output is more delayed. For τ = 0 (factory setting) there is no damping.
 Setup → Advanced setup → Current output 1 to 2 → Failure mode
Current span (→  168) ≠ Fixed current
Defines which current the output assumes in the case of an error. 'Min.': < 3.6mA 'Max.': >
21.95mA 'Last valid value': Last valid value before occurrence of the error. 'Actual value':
Output current is equal to the measured value; error is ignored. 'Defined value': User
defined value.
• Min.
• Max.
• Last valid value
• Actual value
• Defined value
Max.
Operating menu



169
