Summary of Contents for Frico ICSR Series

  • Page 1 ICSR ..6 ..22 ..30 ..38 ..14 ..46 ..54 ..62 ..70...
  • Page 2 ICSR ICSR Type ICSR20 ICSR30 1070...
  • Page 3 ICSR Accessories ICPP20 ICPB ICAP ICUB ICAB Type E-nr [SE] EL-nr [NO] ICPP20 L: 2 m ICPB 85 701 55 L: 1,5 m ICAP15 ICAP20 85 701 56 L: 2 m ICUB 85 701 57 ICAB 85 701 58...
  • Page 4: Wiring Diagrams

    ICSR Wiring diagrams ICSR...
  • Page 5: Technical Specifications

    ICSR Technical specifications Carboninfra ICSR with directed heat distribution, remote, installation height 1,8 – 3,5 m Type E-nr (SE) EL-nr (NO) Heat Voltage Amperage Max. filament Weight output temperature [°C] [kg] ICSR20 85 701 59 2000 230V~ 1200 +/-100 ICSR30 85 701 60 3000 230V~...
  • Page 6 ICSR Assembly and operating instructions General Instructions Read these instructions carefully before installation and use. Keep this manual for future reference. The product may only be used as set out in the assembly and operating instructions. The guarantee is only valid if the product is used in the manner intended and in accordance with the instructions.
  • Page 7: Remote Control

    ICSR Control Remote control Yellow Yellow Display Green Description Red L1 Standby Red L2 Lower heating element ON Red L3 Upper heating element ON Red L2 + red L3 Both elements ON Yellow L4 Timer active Red L5 Temperature in °C Green L6 Indication Automatic mode...
  • Page 8 ICSR Start up Manual mode 1. Connect the plug (standby mode). In manual mode the electronic thermostat is not used. Select manually if upper element, The heater can be controlled using the remote lower element or both elements should be control or the control panel on the heater.
  • Page 9 ICSR Bracket Rotating to horizontal or vertical position on wall or stand Rip for horizontal Rip for position vertical position Rotating from The heater must Rotating from horizontal to vertical be off and the plug vertical to horizontal position, 90°. pulled from the position, 90°.
  • Page 10 ICSR Mounting Wall or ceiling mounting with the bracket 74 mm ø8 mm Screw DIN 7505 D 5 x 60 Plug D 8 PE 8 x 40 Wall or ceiling mounting with the bracket and aluminium profile ICAP 250 mm After assembly and after the radiation angle is set, tighten the screws.
  • Page 11: Fixed Installation

    ICSR Electric installation Cable and plug Cover must be used. ICSR20: 3x1,0 mm ICSR30: 3x1,5 mm Should only be replaced by a qualified electrician. Fixed installation The installation, which should be preceded by an omnipolar switch with a contact separation of at least 3 mm, should only be wired by a competent electrician and in accordance with the latest edition of IEE wiring regulations.
  • Page 12: Ceiling Mounting

    ICSR Minimum mounting distance Wall mounting ICSR20: min 30 cm, Min 10 cm ICSR30: min 50 cm 40 cm Adjustable radiant angle 50 cm min 1,8 m Min 1,8 m from floor Horizontal mounting Vertical mounting Ceiling mounting Adjustable radiant 40 cm angle 50 cm...
  • Page 13 ICSR Maintenance Safety Note! When using for the first time or when • During operation the surfaces of the unit starting up after a long period of disuse, a are hot! small amount of smoke and a slight odour • The unit must not be fully or partially may occur temporarily, which is completely covered with inflammable materials, as normal.
  • Page 14 Main offi ce Frico AB Tel: +46 31 336 86 00 Box 102 Fax: +46 31 26 28 25 SE-433 22 Partille mailbox@frico.se Sweden www.frico.se For latest updated information and information about your local contact: www.frico.se...

This manual is also suitable for:

Icsr20Icsr3085 701 5985 701 60
